Geokon GeoNet 8900 Series Quick Start Manual

Wireless data hosting system
Hide thumbs Also See for GeoNet 8900 Series:
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
Model 8900 Series
GeoNet Wireless Data Hosting System
Quick Start Guide
A network must include a single Gateway and at least one Logger that is within radio range of
the Gateway. Below is a general outline of the set-up process:
1.
2.
1.
1.1 PREPARE THE GATEWAY AND LOGGERS
1.1.1 INSTALL THE ANTENNAS ON ALL DEVICES
Remove the rubber caps from the antenna mounts. Position the antennas on the mounts and
then rotate the antennas in a clockwise direction until tightened.
Note: Be sure not to cross-thread the cellular antennas; they must sit snug against the housing.
1.1.2 REMOVE THE COVERS FROM ALL DEVICES
Remove the cover by unscrewing the four captive screws on the front of the enclosure. Ensure
that no dirt, water, or other contaminants are allowed to enter the enclosure.
Repeat this for each device.
1.1.3 CONFIGURE THE CHANNEL ON ALL DEVICES
GEOKON
no specific network channel configuration is needed and you can skip to Section 1.2 below.
If multiple networks are within radio range of each other, then each network (up to a limit of 12)
must be configured to use a different channel. Devices of each network must be set to their
respective channel.
Document Revision: F | Release date: 07/26/21
recommends that you configure your network with all devices at the same
GEOKON
location, in close proximity to each other, before you deploy them to their respective
on-site positions.
Skipping or omitting steps, or performing them out of order, could complicate the
installation of your network.
For more detailed information than is provided in this Quick Start Guide, please refer to
the
Model 8900 Series GeoNet Wireless Data Hosting System Instruction
Configure the network
■
Prepare the Gateway and Loggers
■
Configure the Gateway
■
Activate the network
Deploy the network
■
Mount the devices
■
Connect the Loggers to sensors
■
Link the Cellular Gateway to the Cloud (if used)
CONFIGURE THE NETWORK
configures all devices to use Channel 1; if no other networks operate in the area, then
MODEL 8900 SERIES GEONET WIRELESS DATA HOSTING SYSTEM | QUICK START GUIDE | 1
Manual.

Advertisement

loading

Related Manuals for Geokon GeoNet 8900 Series

Summary of Contents for Geokon GeoNet 8900 Series

  • Page 1 GeoNet Wireless Data Hosting System Quick Start Guide recommends that you configure your network with all devices at the same GEOKON location, in close proximity to each other, before you deploy them to their respective on-site positions. Skipping or omitting steps, or performing them out of order, could complicate the installation of your network.

  • Page 2: Configure The Gateway

    Sub Polar Temperate Power Source Mains or solar with external battery EXT BATTERY INT BATTERY Solar without external battery TABLE 2: Cellular Gateway Battery Switch Options Cellular Gateway Local Gateway FIGURE 2: Battery Switch 2 | QUICK START GUIDE | GEOKON...
  • Page 3 A Cellular Gateway will set the network time automatically when they connect to the cellular network. A Local Gateway must have its time set manually using ’s "Agent" data GEOKON collection software. Connect the Local Gateway to the computer using the -supplied USB cable.
  • Page 4 Keep in mind that loggers communicate with each other, not just with the gateway. ■ A high Received Signal Strength Indicator (RSSI) level does not guarantee trouble-free communication. ■ Mount devices such that their antennas are on top, pointing upward. 4 | QUICK START GUIDE | GEOKON...
  • Page 5 2.1.2 GROUND THE GATEWAY AND LOGGERS Install a grounding rod and cable, or other suitable ground, at a location near each device. Cellular Gateways and multiple-channel loggers come equipped with a copper grounding lug to which you can connect the grounding cable. Ground Local Gateways and Loggers by connecting the grounding cable to the mounting bracket.
  • Page 6 15. Paste the token into ’s data collection software, "Agent", to commission the Cellular GEOKON Gateway and retrieve data. For more information, refer to the Model 8900 Series GeoNet Wireless Data Hosting System Instruction Manual. 6 | QUICK START GUIDE | GEOKON...
