11Mbps High Rate 802.11b WLAN USB Adapter
■ Specifications
Model Name
System Interface
Frequency Band
Operating Voltage
Current Consumption
Data Rate
Spreading
Output Power
Receive Sensitivity
Security
Antenna
Available Drivers
Standards
Media Access
Protocol
Temperature Range
Humidity
Operating Range
(1024 bytes file
transfer)
Dimensions
Weight
Certifications
&
Regulatory Approvals
Copyright Samsung Electro-Mechanics Co., Ltd. All Rights Reserved.
USB Spec 1.1 Compliant
2.400 ~ 2.4835GHz(Subject to local regulations)
Receive : 250mA (Typical), Transmit : 350mA (Typical)
Power Save: 10mA (Typical)
DSSS(Direct Sequence Spread Spectrum)
40mW(16dBm) for 22MHz Bandwidth, 7mW/MHz
-84dBm(Typical) at 11Mbps
40-bit/104(128)-bit WEP Encryption
2 Printed on PCB Antennas (supporting Rx Diversity)
Microsoft Windows 98SE/ME/2000/XP/XPSP1
CSMA / CA (Carrier Sense Multiple Access with Collision Avoidance)
Operating : 0~45 (32~113 ), Storage : -25~70 (-13 ~158 )
10% to 90% Non-condensing
Open Space : 150m(500ft) at 11Mbps, 200m(660ft) at 2Mbps
Office: 30m(100ft) at 11Mbps, 50m(160ft) at 2Mbps
*Range differs by environment
114mm×52mm×15mm & 1.2M Cable with USB A-type Connector
40g(Except 1.2m Cable)
Wi-Fi certified, USA(FCC), Canada(IC)
R&TTE Approval(CE) and 15 EU & 4 EFTA Countries Notifications
SWL-2300U
5V±5% from Host PC
1, 2, 5.5 or 11Mbps
IEEE 802.11b
completed,
Korea will be planned
