Congratulations on owning a Scag mower! This manual contains the operating
instructions and safety information for your Scag mower. Reading this manual
can provide you with assistance in maintenance and adjustment procedures to
keep your mower performing to maximum efficiency. The specific models that
this book covers are listed on the inside cover. Before operating your machine,
please read all the information enclosed.
© 2016
Scag Power Equipment
Division of Metalcraft of Mayville, Inc.
OPERATOR'S
MANUAL
Models:
STCII-48V-22FX
STCII-48V-23CV
STCII-52V-22FX
STCII-52V-25CV-EFI
STCII-61V-23FX
STCII-61V-29CV-EFI
PART NO. 03406 Rev.01
PRINTED 9/2016
PRINTED IN USA
