Packing List - EarthWise CVPS43010 Owner's Manual

UNPACKING
This product requires assembly.
Carefully remove the product and any accessories from the box.
Make sure that all items listed in the packing list are included.
Inspect the product carefully to make sure no breakage or damage
occurred during shipping.
Do not discard the packing material until you have carefully inspected
and satisfactorily operated the product.

PACKING LIST

−
Chain Saw Cutting Head
−
Blade Cover
−
Telescopic Pole w/Should Strap
−
Rear Handle
−
Owner's Manual
WARNING: If any parts are damaged or missing, do not operate this
product until the parts are replaced. Failure to heed this warning
could result in serious personal injury.
If any parts are damaged or missing, please call 1-800-313-5111 for
assistance.
CONVERTING FROM CHAIN SAW TO POLE SAW
1. Lift the quick release button. Pull to remove the handle from the
cutting head. (Fig. 1)
Quick release button
FIG. 1
2. Insert the telescopic pole into the chain saw cutting head. Press
down the quick release button. Make sure the release button
snaps firmly to lock the parts securely. (Fig. 2)
Pole
FIG. 2
3.
Insert the rear handle into the end of the telescopic pole. (Fig. 3)
Press down the quick release button. Ensure the release button
snaps firmly into position to lock the handle securely.
Pole
Rear
Handle
ASSEMBLY
CONVERTING FROM POLE SAW TO CHAIN SAW
1. Disconnect rear handle and cutting head from ends of
telescopic pole by lifting the quick release button and pulling
straight out. (Fig. 4-5)
2. Insert the rear handle directly into the chainsaw cutting head .
When fully inserted, press down the quick release button.
Make sure the button snaps in firmly and securely, locking the
parts together.
ADJUSTING THE LENGTH OF THE TELESCOPIC POLE (FIG.6 )
1. To adjust the telescopic pole, disconnect the product from
the power supply. Rotate the collar counterclockwise to
loosen, Extend the pole to the desired length.
NOTE: Only extend the pole to minimum length required to
reach the limb or shrub to be cut.
2. Lock the pole in position by turning the collar clockwise
firmly to secure.
WARNING: Failure to lock the telescopic pole collars as directed
could result in personal injury.
Rear handle
FIG.6
Locking
Collar
Quick Release
Button
FIG. 3
6
Model CVPS43010
