Install Digitizer
Install Feed Tray
A. Look for two sets of the Feed Tray
Holes at both ends of the front-top of
the digitizer.
B. Insert and push down both sides of the
Feed Tray into its compartment holes,
making sure the Feed Tray snaps into
place.
Install either Output Guide or Output Basket
A. Look for two sets of Output Tray Holes at both ends of the front-bottom of the
digitizer.
B. Insert and push down both sides of the Output Guide into its compartment holes,
making sure the Output Guide snaps into place.
Or, Insert and push down both sides of the Output Basket into its compartment holes,
making sure the Output Basket snaps into place.
Output Tray Holes
Feed Tray Holes
Output Guide
2
Feed Tray
Output Tray Holes
Output Basket
