ECG Cables and Accessories

ECG Cables and Accessories
Accessories
Leadwires with Snaps IEC
Leadwires with Snaps AHA
Leadwires with Clips IEC
Leadwires with Clips AHA
Black belt for 1200W acquisition unit
USB cable 3m for 1200WR Receiver
BNC cable 3m for 1200WR Receiver

Technical Specifications

ECG
Communication
Power
Mechanical
Environmental
Auxiliary output
Communication
Power
Mechanical
Environmental
Regulatory
Page 12
Part Number
2102322-011
2102322-012
2102322-013
2102322-014
2102322-015
2102322-053
2102322-054
1200W (Acquisition unit)
Lead system
Patient Leads
Defibrillation protection
Patient leakage current
Input impedance
CMMR
Frequency range
Dynamic range
Resolution
Sample Rate Internal
Sample Rate Recording
Lead OFF Detection
Digital RF
Battery
Operation time
Size
Weight
Operating Temp. Range
Storage Temp. Range
Relative Humidity
1200WR (Receiver)
ECG Out Bandwidth (-3db)
ECG Out Gain
ECG Out Sample Rate
TTL Trigger width
TTL Trigger delay
USB
Digital RF
USB 5V
Size
Weight
Operating Temp. Range
Storage Temp. Range
Relative Humidity
Safety Standards
Classification
Certification
Standard 12 Lead
Detachable 10 Lead wires conform to AAMI
Protected against 360J discharge
< 10 uA
> 10 MOhm
> 90dB
0.05 – 150Hz
+/- 2.4V
24 bits (0.286 uV/LSB)
8000
500
Yes
2400 – 2483 MHz,
0.4mW, conform to FCC Part 15.249
Size AA x 2, Alkaline or NiMH
Up to 40 hours with Alkaline Batteries
140 x 95 x 50 mm
350g
10 to 40 °C
-20 to 60 °C
10 to 95 % (non-condensing)
0.5 to 150 Hz
1000
500
16-128ms
<11ms (delay from R-wave)
USB2.0 Full Speed
2400 – 2483 MHz,
0.4mW, conform to FCC Part 15.249
100mA max at 5V input
100 x 54 x 30 mm
80g
10 to 40 °C
-20 to 60 °C
10 to 95 % (non-condensing)
IEC 60601-1, 60601-1-2, 60601-2-25
Type CF with defibrillation proof. Internally powered
CE, FDA
2102322-111 REV 1
