Panasonic TX-25P92X Service Manual

Specification
Power Source
Power Consumption
Aerial Terminal
Tuning System
Receiving System
Receiving Channels
VHF BAND
UHF BAND
CATV
Intermediate Frequency
AC Auto 110-240 V, 50/60 Hz
Standby condition : 2 W
Impedance : 75Ω, Coaxial type
Frequency Synthesizer
Auto Search Tuning
Pos : 100 Positions
17 Systems
Regular TV
2-12 (PAL/SECAM B, K1)
0-12 (PAL B AUST.)
1-9 (PAL B N.Z.)
1-12 (PAL/SECAM D)
1-12 (NTSC M Japan)
2-13 (NTSC M U.S.A)
21-69 (PAL G, H, I/SECAM G, K, K1)
28-69 (PAL B AUST.)
13-57 (PAL D, K)
13-62 (NTSC M Japan)
14-69 (NTSC M U.S.A.)
S1-S20 (OSCAR)
1-125 (U.S.A. CATV)
C13-C49 (JAPAN)
S21-S41 (HYPER)
Z1-Z37 (CHINA)
38.0 MHz
TX-25P92X
MX-12 Chassis
Video
139 W
Sound
Colour
Receiving Stereo Sound System
Video/Audio/Terminals
AV 1, 2, 3, 4
Y / P / P
B R
Monitor Out
High Voltage
Picture Tube
Audio Output
Dimensions (W x D x H)
Weight (Mass)
Note:
Specifications are subject to change without notice. Mass and
dimensions shown are approximate.
© 2003 Matsushita Electric Industrial Co., Ltd. All
rights
distribution is a violation of law.
Order No. MTV0308233C3
Colour Television
31.5 MHz (D, K) / 32.5 MHz (B, G)
32.0 MHz (I) / 32.5 MHz (M)
33.57 MHz (PAL) /
33.6 MHz (SECAM)
34.42 MHz (NTSC) /
33.75 MHz (SECAM)
QUADRA STEREO
IN S-Video Y:1.0Vp-p 75Ω
DVD IN S-Video C:0.3Vp-p 75Ω
(Phone Type) Y:1.0Vp-p 75Ω PB,
PR:0.7Vp-p 75Ω Video 1.0Vp-p
75Ω Audio Approx. 400mV 47KΩ
Video 1.0Vp-p 75Ω
Audio Approx. 400mV 47KΩ
30.0 ±1.0V at zero
A60LUQ086X Type 25 (60 cm)
Measured diagonally,
650 mm x 471 mm x 530 mm
reserved. Unauthorized
beam current
104° deflection
20 W speaker
37 kg (Net)
copying and
