Panasonic TX-25P80T Service Manual

Specification
Power Source
Power Consumption
Aerial Terminal
Tuning System
Receiving System
Receiving Channels
VHF BAND
UHF BAND
CATV
Intermediate Frequency
AC Auto 110-240 V, 50/60 Hz
138 W
Standby condition : 0.8 W
Impedance : 75Ω, Coaxial type
Frequency Synthesizer
Auto Search Tuning
Pos : 100 Positions
17 Systems
Regular TV
2-12 (PAL/SECAM B, K1)
0-12 (PAL B AUST.)
1-9 (PAL B N.Z.)
1-12 (PAL/SECAM D)
1-12 (NTSC M Japan)
2-13 (NTSC M U.S.A.)
21-69 (PAL G,H,I/SECAM G,K,K1)
28-69 (PAL B AUST.)
13-57 (PAL D,K)
13-62 (NTSC M Japan)
14-69 (NTSC M U.S.A.)
S1-S20 (OSCAR)
1-125 (U.S.A. CATV)
C13-C49 (JAPAN)
S21-S41 (HYPER)
Z1-Z37 (CHINA)
TX-25P80T
MX-10 Chassis
Video
Sound
Colour
Receiving Stereo Sound System
Video/Audio/Terminals
AV 1, 2, 3
Y/PB/PR
Monitor Out
High Voltage
Picture Tube
Audio Output
Dimensions (WxDxH)
Weight (Mass)
Accessories Supplied
Remote Control Transmitter
© 2001 Matsushita Electric Industrial Co., Ltd. All
rights reserved.
distribution is a violation of law.
Order No. MTV0110238C3
Colour Television
38.0 MHz
31.5 MHz (D,K) / 32.5 MHz (B,G)
32.0 MHz (I) / 32.5 MHz (M)
33.57 MHz (PAL) /
33.6 MHz (SECAM)
34.42 MHz (NTSC) /
33.75 MHz (SECAM)
QUADRA STEREO / TEXT
IN S-Video Y:1.0Vp-p 75Ω
DVD IN S-Video C:0.3Vp-p 75Ω
(Phone type) Y:1.0Vp-p 75Ω PB,
PR:0.7Vp-p 75Ω Video 1.0Vp-p
75Ω Audio Approx. 400mV 47KΩ
Video 1,0Vp-p 75Ω
Audio Approx. 400mV 47KΩ
31.0 (+0.7, -1.5kV) at zero beam
A60LUQ085X Type 25 (60 cm)
Measured diagonally, 104°
deflection
16 W speaker
634 mm x 471 mm x 534 mm
37 kg (Net)
1. R6(AA) Battery x 2
Unauthorized copying
current
and
