Oreck XL PRO FMH Series Manual

ORECK XL
New Equipment Warranty
Limited Warranty
The manufacturer gives you the following limited warranty for this product if it was originally
purchased for use, not resale, from Oreck or an Oreck Authorized Retail Dealer.
The manufacturer will repair or replace, free of charge, to the original purchaser, any part which is
found to be defective in material or workmanship within six (6) months of the date of purchase;
five (5) years on the motor and gear box.
Drive belts, brushes, and other parts subject to normal wear are not covered by this limited
warranty.
This limited warranty does not apply to any part subjected to accident, abuse, or alteration, misuse,
damage caused by fire or act of God, the use of voltages other than indicated on the serial number
plate of this product or service of this product by other than a trained service technician.
The manufacturer does not authorize any person or representative to assume or grant any other
warranty obligation with the sale of this product.
The manufacturer's limited warranty is valid only if you retain proof of purchase from Oreck or an
Oreck Authorized Retail Dealer for this product. If you purchase this product from any other
source, your purchase is "AS IS," which means the manufacturer grants you no warranty, and that
you, not the manufacturer, assume the entire risk of the quality and performance of this product,
including the entire cost of any necessary servicing or repairs of any defects.
The manufacturer's liability for damages to you for any costs whatsoever arising out of this
statement of limited warranty shall be limited to the amount paid for this product at the time of
original purchase, and the manufacturer shall not be liable for any direct, indirect, consequential or
incidental damages arising out of the use or inability to use this product.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you.
ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS PRODUCT, INCLUDING IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
ARE LIMITED IN DURATION TO THE WARRANTY PERIOD, AND NO WARRANTIES,
WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THIS PERIOD.
Some states do not allow limitations on the duration of implied warranties, so the above limitation
may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state.
PROFESSIONAL GRADE
©2010. Oreck Holdings, LLC. All rights reserved.
All word marks, logos,product configurations and
registered trademarks are owned and used under
the authority of Oreck Holdings, LLC.
®
®
Oreck Corporation
100 Plantation Road
New Orleans, LA 70123
Commercial Sales: (800) 242-1378
PROFESSIONAL GRADE
Safety enhanced
Safety enhanced
interlock switch /
non-conductive dual
both hands are
triggers / eliminates
conveniently
shock potential
in control
Fully adjustable handle
position / comfortable
Precision balanced,
for all operators
heavy-duty 66-frame
motor / for
Motor plugs in at
easier operation
handle base / for
easy maintenance
Non-marking, fixed
6" wheels / for easy
transport
Non-marking full
wrap bumpers /
protects floors,
walls and
baseboards
SPECIFICATIONS
Part Number XLH-15E
Machine Size 15"
Weight 104 lbs
Brush Speed 175 RPM
Motor 1.5 HP
Motor Type AC 2 capacitor
Amp Draw 13-15 amps
Chassis Polished aluminum
Cord 50' Safety red14/3 Ga.
Drive "B" style clutch
Wheels 6" non-marking
Warranty 5 years motor and gearbox
XL PRO™ FMH Series
Heavy-Duty Floor Machine
175 RPM - 1.5 HP
15", 17", 19", and 21"
First
choice for spray
buffing, scrubbing
stripping,
shampooing
and bonnet
cleaning
Triple-planetary high torque
transmission / handles
the most demanding
applications
All metal
chassis / added
weight for
faster results
XLH-17E XLH-19E XLH-21E
17" 19" 21"
106 lbs 107 lbs 108 lbs
175 RPM 175 RPM 175 RPM
1.5 HP 1.5 HP 1.5 HP
®
