3BE390723NI
OPTIMUM 700 & 900
ELECTRIC
PASTA COOKERS
BUILDER'S SPECIFICATIONS
Part A: Technical characteristics
Part B: Technical instructions for the installer
Installation and repairs must be carried out by personnel approved by the manufacturer and in
accordance with current regulations and standards.
•
If any modifications are made the manufacturer can accept no responsibility whatsoever.
•
These appliances must be used in a well-ventilated area.
•
Read the notice carefully before installation.
•
When handling it, it is imperative to leave the appliance on its base till final installation.
- WARNING -
Advertisement
Table of Contents
Related Manuals for Bonnet OPTIMUM 700
Summary of Contents for Bonnet OPTIMUM 700
- Page 1 OPTIMUM 700 & 900 ELECTRIC PASTA COOKERS BUILDER’S SPECIFICATIONS Part A: Technical characteristics Part B: Technical instructions for the installer - WARNING - • Installation and repairs must be carried out by personnel approved by the manufacturer and in accordance with current regulations and standards.
-
Page 2: Table Of Contents
ASSEMBLY OF APPLIANCES ON A MASONRY BASE ……………………..……………..……… 11 INSTALLATION: CONNECTIONS ……………………………………………...….………………. 13 ELECTRIC CONNECTION ……….……………..…...……...………..…….………………………….. 13 WATER CONNECTION .………...……...……………………..…..……………………………….…... 14 DRAINAGE CONNECTION ….……….……………………………..………………………………..14 BONNET GRANDE CUISINE Registered Office: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex... -
Page 3: A) Technical Characteristics
Page 2 3BE390723NI – 11/09 A: TECHNICAL CHARACTERISTICS OPTIMUM 700, Electric pasta cooker P075755 ELECTRIC connection (Foresee a cable with 1.5 m free length) HOT WATER DRAINAGE MODEL B-B709.CP400 DIMENSIONS (mm) Width Depth x Height 730 x 959 Basket 90 x 280 x 160... - Page 4 Back to the wall or another appliance ELECTRIC CONNECTION This document is not contractual; Edition 11/2009 – 3BE0585FT Electric outlet at 390 mm above the floor. BONNET GRANDE CUISINE Registered Office: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex...
-
Page 5: Firm Plates
1.2 LOCATION OF THE FIRM PLATE The firm plates are fixed on the control board (see the diagrams hereafter). Location of the firm plate BONNET GRANDE CUISINE Registered Office: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex... -
Page 6: Installation: Generalities
Before installation, remove the strapping from the appliance. The individual parts are not bolted down. Remove the protective plastic film from the stainless steel parts before heating. BONNET GRANDE CUISINE Registered Office: Rue des Frères Lumière - Z.I Mitry Compans... -
Page 7: Access To The Components Placed Behind The Fascia
- Tilt the fascia: Slightly pull downwards then to yourself - Put the fascia in locking position: clamp both lugs into the apertures foreseen in the fascia. BONNET GRANDE CUISINE Registered Office: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex... -
Page 8: Installation: Putting In Place
- Fix the lower bearing beam of the appliances against the wall. Warning! Check this bearing beam is properly horizontal. - Fix the template supplied by two ∅ 5 screws to the wall. Check horizontality. BONNET GRANDE CUISINE Registered Office: Rue des Frères Lumière - Z.I Mitry Compans... - Page 9 - Put the appliances in place on the brackets and lock them. Warning! The appliances must rest on the bearing beam. Bracket Bearing beam BONNET GRANDE CUISINE Registered Office: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex...
-
Page 10: Assembly Of Appliances To An Individual Base
- Fix the appliances between themselves at the front after having removed the front fascia (see paragraph 3.4) with one HM5 16 screws + 5 flat washers. Ø BONNET GRANDE CUISINE Registered Office: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex... -
Page 11: Assembly Of Appliances On A Common Base
- Fix the appliances between themselves at the front after having removed the front fascia (see paragraph 3.4) with one HM5 16 screws + 5 flat washers. Ø BONNET GRANDE CUISINE Registered Office: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex... -
Page 12: Assembly Of Appliances On A Masonry Base
Base depth as a wall Base depth as a central Base length completely tiled version version on the front Optimum 700 1040 Lf-50 Optimum 900 1420 Lf-50 The technical compartment is compulsory if the switch-off tap, the shut-off valve, or the reducing valve are in the stove. - Page 13 - Fix the back part (on the end appliances before their final installation) on the base with the hex head screw ( ). - Fix the right and left end trimming kits ( ) (2 front screws and 1 back screw). BONNET GRANDE CUISINE Registered Office: Rue des Frères Lumière - Z.I Mitry Compans...
-
Page 14: Installation: Connections
(all metallic structures to the same voltage) by means of a terminal provided for this purpose and located beside the connecting gland. The builder denies all responsibility in the case where the instructions above are not observed. BONNET GRANDE CUISINE Registered Office: Rue des Frères Lumière - Z.I Mitry Compans... -
Page 15: Water Connection
The drain must include a siphon to fight against any return of bad smells. Recommended solution: 50 mm Ø100 siphon type plug (under the slab) or gutter BONNET GRANDE CUISINE Registered Office: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex...
