CONNECTOR PIN ASSIGNMENT

15-Pin Color Display Signal Cable

PIN NO.
1.
2.
3.
4.
5.
6.
7.
8.
19-pin color display signal cable*
PIN No.
1
TMDS Data2+
3
TMDS Data2–
5
TMDS Data1 Shield
7
TMDS Data0+
9
TMDS Data0–
11
TMDS Clock Shield
13
CEC
15
SCL
17
DDC/CEC Ground
19
Hot Plug Detect
* only for certain models
DESCRIPTION
Red
Green
Blue
Monitor Ground
DDC-return
R-Ground
G-Ground
B-Ground
Description
PIN No.
PIN NO.
9.
10.
11.
Monitor Ground
12.
DDC-Serial Data
13.
14.
15.
DDC-Serial Clock
19
17
18
Description
2
TMDS Data2 Shield
4
TMDS Data1+
6
TMDS Data1–
8
TMDS Data0 Shield
10
TMDS Clock+
12
TMDS Clock–
14
Reserved (N.C. on device)
16
SDA
18
+5V Power
EN-9
DESCRIPTION
+5V
Logic Ground
H-Sync
V-Sync
15
13
11
9
7
5
3
1
16
14
12
10
8
6
4
2
