4.
Overview
The VMA307 is an RGB LED module with on-board current limiting resistors.
voltage ..................................................................................................................... 5 VDC
connection ............................................................................................... 4-pin male header
pins names .................................................................................... GND, RED, GREEN, BLUE
dimensions ............................................................................................... 24 x 16 x 16 mm
weight .......................................................................................................................... 2 g
5.
Programming Code
V. 01 – 28/11/2016
Arduino®
D11
D10
D9
GND
VMA307
3
VMA307
R
G
B
-
©Velleman nv
