Blackweb BWA18AA013 User Manual

Status Indicator Light
Volume Down "-" / Previous Track (3s) Button
POWER BUTTON:
Press and hold the button for 2 seconds to turn device ON/OFF.
VOLUME UP " + " BUTTON:
Short press (< 0.5s) the button to turn up volume. Press and hold the button (2s) to go to
the next track.
VOLUME DOWN " – " BUTTON:
Short press (< 0.5s) the button to turn down volume. Press and hold (2s) the button to go
to the previous track.

INDICATOR LIGHT STATUS:

Power ON – When the speaker is turned on, a solid blue light will appear momentarily.
Bluetooth pairing indicator – When the speaker is turned on, a flashing blue and
red light indicates speaker is ready to pair. Once paired, the light will turn solid blue then
turn off.
Power OFF – When the speaker is turned off, the indicator light will momentarily turn
solid blue, then turn off.
Battery charging – While speaker is charging, the indicator light will turn solid red.
Once speaker is fully charged it will turn off.

SPEAKER PAIRING:

To pair the speaker, follow these simple steps:
1. Make sure the smartphone, tablet, or computer you're using with the speaker has
Bluetooth.
2. Turn on the speaker (press and hold the PLAY/PAUSE button for 2 seconds) and look for
the little blinking light.
3. Look for the Blackweb RGD A013 speaker in your device' s Bluetooth list, or click YES.
The device and Bluetooth will find each other every time, so long as the speaker is set
to Bluetooth and your device's Bluetooth is on. If you're connecting to a computer,
you may have some extra steps on that end. You'll have to get that information from the
computer company.
Auto off: If the speaker is on but is not connected to Bluetooth, it will shut down after 2
minutes. Once paired, if the speaker is paused for 15 minutes or more, it will automatically
shut down.
SPEAKER CONTROLS & FEATURES
PLAY/PAUSE Button
Volume Up "+" / Next Track (3s) Button
RUGGED BLUETOOTH® SPEAKER
USB Charging Port (600mA)
DISCONNECTING DEVICE:
Press "+" and "–" buttons at the same time for up to 4 seconds to disconnect the speaker
from the device and enter into Pairing mode.

CALL HANDLING:

INCOMING CALL:
Answering and hanging up a call – When speaker is paired to your phone, short
press the PLAY/PAUSE button to answer the call. To hang up, short press the PLAY/PAUSE
button.
Move call from speaker to device – If you are on the call and wish to move the call
from the speaker to your device, long press the PLAY/PAUSE button.
Reject an incoming call – To reject an incoming call, long press the PLAY/PAUSE
button (3s).
See below table for clarification.
Situation
PLAY/PAUSE Button
First incoming call
On call
USB CABLE:
25 cm Micro USB cable.
BWA18AA013
AUX IN
CHARGE
Line In Port
Short Press Long Press
PLAY/PAUSE Button
Pick up call Reject call
End call Move call from speaker to device
