- Page 1 NV354Q Series OWNER’S GUIDE...
- Page 2 ALWAYS BE OBSERVED, INCLUDING THE SHOCK OR INJURY: FOLLOWING: GENERAL ELECTRICAL SAFETY: READ ALL INSTRUCTIONS BEFORE USING 1. Unplug from electrical outlet when not in use YOUR SHARK NAVIGATOR LIFT-AWAY ® ® and before servicing. POLARIZED PLUG: 2. DO NOT use vacuum with a damaged cord or To reduce the risk of electric shock, this plug.
- Page 3 HOSE ATTACHMENTS: DUST CUP/FILTERS/ACCESSORIES: 1. DO NOT use if air flow is restricted; if the air Before turning on the vacuum: paths, the hose, or the accessories become 1. Make sure that all filters are thoroughly dry blocked, turn the vacuum cleaner off. Remove all after routine cleaning.
- Page 4 THIS MANUAL COVERS MODEL NUMBERS: NV354QBK 31 NV354QGN 31 NV354QRD 31 TECHNICAL SPECIFICATIONS Voltage: 120V., 60Hz Watts: 1200W Amps: 1-800-798-7398...
-
Page 5: Table Of Contents
Contents Thank you for Getting Started ..................... 5 purchasing Mode 1: Upright Vac ..................... 7 the Shark Mode 2: Detachable Canister ................9 Navigator ® Above-Floor Cleaning ..................10 Lift-Away ® Storing ........................11 Maintenance .......................11 Emptying the Dust Cup ...................12 Cleaning the Pre-Motor Filters .................12 Cleaning the Post-Motor HEPA Filter ..............13... -
Page 6: Getting Started
Getting Started Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 ACCESSORIES: CREVICE TOOL Reach deep into narrow spaces and clean between cushions, under radiators and baseboards and in hard to reach crevices and corners. (Fig. 1) DUSTING BRUSH FIRST THING’S FIRST, YOU NEED TO KNOW WHAT’S Dust shelves, lamp shades, window blinds, books, IN THE BOX YOU JUST OPENED:... - Page 7 Your new Shark Navigator Lift-Away vacuum cleaner can easily be configured into different cleaning ® ® modes to meet all your cleaning needs: upright vacuum and detachable canister - both with constant suction power. Fig. 6 Fig. 7 MODES: DETACHABLE CANISTER...
-
Page 8: Mode 1: Upright Vac
Mode 1: Upright Vac WARNING: The On/Off switch is on the top of the detachable canister. Always ensure the power is OFF (“O” position) before plugging and unplugging. To reduce the risk of electric shock, unplug the unit before assembling, adding or removing attachments or converting modes. - Page 9 Cord Suction Hook Release Collar Release suction for easier push & pull on high pile carpets and area rugs. Fig. 11 Fig. 12 TO USE: Gently press the floor nozzle down with your foot while you grasp the handle and tilt it back towards Rotate the cord release to quickly release the power you.
-
Page 10: Mode 2: Detachable Canister
Mode 2: Detachable Canister You can carry your vacuum cleaner in both modes by the carry handle located on top of the dust cup. Fig. 14 Fig. 13 LIFT AWAY DETACHABLE CANISTER FOR Attach desired accessory onto the end of either the extension wand or the handle. -
Page 11: Above-Floor Cleaning
Above-Floor Cleaning Release suction for easier push & pull on high pile carpets and area rugs. Fig. 15 Suction Release Collar CLEAN ABOVE THE FLOOR IN UPRIGHT VAC Press the On/Off switch to the “I” position to turn the vacuum on for above-floor cleaning. OR DETACHABLE CANISTER MODE IMPORTANT: Ensure vacuum is in upright Press the handle release button and pull the handle... -
Page 12: Storing
Storing Maintenance WARNING: Never insert sharp objects into any opening to clear an obstruction. IMPORTANT: Make sure all filters are completely dry before inserting back into vacuum. IMPORTANT: Damages caused while clearing or attempting to clear blockages are not covered under your product’s limited warranty. To reduce the risk of electric shock, unplug the unit before performing any cleaning, maintenance, or troubleshooting checks. -
Page 13: Emptying The Dust Cup
COMPONENT MAINTENANCE SCHEDULE Dust Cup Empty each time you vacuum. Pre-Motor Foam Filter Rinse and air dry every 3 months under normal use. Pre-Motor Felt Filter Rinse and air dry every 3 months under normal use. Post-Motor HEPA Filter Clean once every 2 years or as needed. Screen Pre-Motor Filter... -
Page 14: Cleaning The Post-Motor Hepa Filter
Maintenance - cont’d Fig. 21 Fig. 24 Fig. 22 Fig. 23 Fig. 25 CLEANING THE POST-MOTOR HEPA FILTER CLEANING THE PET HAIR POWER BRUSH Slide the locking latch (a) forward and gently tilt Remove the filter cover from the front of the vacuum brush housing upward to open. -
Page 15: Cleaning The Motorized Floor Brush
Make sure you are working in a well lit area and use a flashlight to help search for blockages. Rotating Brush Fig. 26 Fig. 27 CHECKING FOR BLOCKAGES CLEANING THE MOTORIZED FLOOR BRUSH Blockages may cause your vacuum to overheat and shut When your motorized floor brush needs cleaning or locks down. -
Page 16: Ordering Parts
Maintenance - cont’d Ordering Parts Fig. 28 Fig. 29 • Remove the dust cup and extension wand and PART PART NO. separate the detachable canister from the Pre-Motor Filter Set XHF350 motorized floor brush. Look in all 4 openings for any blockages. -
Page 17: Troubleshooting Guide
Troubleshooting Guide PROBLEM POSSIBLE REASONS & SOLUTIONS Check filters to see if they need cleaning. Follow instructions for rinsing and drying the filters before re-inserting back into the vacuum. (See “Maintenance” sections for instructions.) Vacuum is not Dust cup may be full; empty dust cup. picking up dirt. - Page 18 Notes 1-800-798-7398...
-
Page 19: Warranty
(as damage in shipping is not covered by your warranty). Mark the outside of your package “ATTENTION CUSTOMER SERVICE”. Product Registration Please visit www.sharkclean.com or call 1-800-798-7398 to register your new Shark product within ten (10) days of ®... - Page 20 1-800-798-7398 www.sharkclean.com COPYRIGHT © 2015 SHARKNINJA OPERATING LLC Euro-Pro, Lift-Away, Navigator, and Shark are registered trademarks of SharkNinja Operating LLC. NV354Q_31_IB_160420 PRINTED IN CHINA. Illustrations may differ from actual product. We are constantly striving to improve our products, therefore the specifications contained herein are subject to change without notice.
