Outlook Tour

Front View

#
# Item
1 Acer Orbicam
2 Display screen
3 Acer FineTouch Keyboard
4 Acer FineTrack
5 Microphone
6 Fingerprint reader
7 Touch pad
8 Status indicators
9 3D sonic speakers
10 11 Click buttons
(left, center and right)
12 Palmrest
6
Item Description
1.3 megapixel web camera for video communication. (for selected
models)
Also called Liquid-Crystal Display (LCD), displays computer output.
Serves to enter data into the computer.
Touch-sensitive pointing device which functions like a computer
mouse when used together with the click buttons.
Internal microphone for sound recording.
Security identification. (for selected models)
Touch-sensitive pointing device which functions like a computer
mouse.
Light-Emitting Diodes (LEDs) that light up to show the status of the
computer's functions and components.
Left and right speakers deliver stereo audio output.
The left and right buttons work like the left and right mouse buttons;
the center button serves as a four-way scroll button.
Comfortable support area for your hands when you use the
computer.
