Multi Channel Amplifier
Owner's Manual
570-AZR170X2
570-AZR400X4
570-AZR700X5

Advertisement

Table of Contents
loading

Related Manuals for Kaption Audio 570-AZR170X2

Summary of Contents for Kaption Audio 570-AZR170X2

  • Page 1 Multi Channel Amplifier Owner’s Manual 570-AZR170X2 570-AZR400X4 570-AZR700X5...

  • Page 2: Warranty

    We always recommend you have these amplifiers installed by an authorized Kaption Audio dealer. Kaption audio amplifiers come with a One-yeAR pARTs And lAbOuR liMiTed WARRAnTy. Features: • 570-AZR170X2 - 2 CH Class Ab, 2Ω stable • 570-AZR400X4 - 4 CH Class Ab, 2Ω...

  • Page 3: Pre-Installation

    Multi Channel Amplifiers ArNINg NvEsTIgATE ThE lAyOUT Of yOUr AUTOmOBIlE ThOrOUghly BEfOrE drIllINg Or CUTTINg ANy hOlEs sE ExTrEmE CArE WhEN yOU WOrK NEAr ThE gAs TANKs gAs Or hydrAUlIC lINEs ANd ElECTrICAl WIrINg lWAys mAKE sUrE ThE mplIfIEr Is sECUrEly mOUNTEd OUNTINg ThE mplIfIEr sECUrEly TO ThE AUTOmOBIlE WIll prEvENT dAmAgE TO ThE CAr Or INjUry TO A pErsON...
  • Page 4 Multi Channel Amplifiers 570-AZR170X2 Parts List • 2-Channel, 170w Amplifier • High level-in wire adapter • Hardware pack 7.99 2.40 9.15 6.06 570-AZR400X4 Parts List • 4-Channel, 400w Amplifier • High level-in wire adapter • Hardware pack 10.57 2.40 11.73 6.06...
  • Page 5 Multi Channel Amplifiers 570-AZR700X5 Parts List • 5-Channel, 700w Amplifier • High level-in wire adapter • Wired bass remote control • Hardware pack 15.57 2.40 16.73 6.06 Controls and wiring locations 570-AZR170X2 - 4 -...

  • Page 6: Speaker Terminals

    Multi Channel Amplifiers 570-AZR400X4 570-AZR700X5 1. Speaker Terminals 2-Channel or 4-Channel Terminals (depending on model purchased) outputs to co-axial speakers. see wiring diagrams. 2. Sub-Woofer Terminal (570-AZR700X5 only) Terminal output for sub-woofer channel. see wiring diagrams. 3. +12 Volt power connection. Th amplifier must be connect to the positive terminal on the vehicle’s battery.
  • Page 7 The distance to the ground should be as short as possible and no more than 18”. dO NOT CONNECT ThE AmplIfIEr TO ’ ThE vEhIClE s BATTEry grOUNd TErmINAl 570-AZR170X2 570-AZR400X4 570-AZR700X5 16 17 - 6 -...
  • Page 8 Multi Channel Amplifiers 6. RCA Input Jacks RCA Input jacks are for use with source units having RCA or low level output. source units with an output signal level of minimum 200mV may be used. (see installation wiring diagram) 7. Sub-Woofer RCA Input Jacks (570-AZR700X5 only) sub-Woofer jack are for use with the source unit with an RCA or low level output.

  • Page 9: Wire Connections

    17. Wired Bass Remote Jack (570-AZR700X5 only) provides a wired remote control to the drivers seated location. The Bass Remote controls the amplifier’s volume adjustment. 18. RCA Pre-Amp Pass Through (570-AZR170X2 only) provides line level output from RCA input (item 6) Wire Connections...
  • Page 10 8” from the battery. Model 570-AZR170X2 570-AZR400X4 570-AZR700X5 Cable size 4ga AWG...
  • Page 11 Multi Channel Amplifiers • REM (Item 4): This connection turns the amplifier on and off. REM connection is used based upon the amplifier input source (high level or low level) and if the source unit has current sensing technology. Low level input: Use the REM connection if the amplifier is connected to the low level inputs (RCA). Connect the ReM to the source unit’s remote- turn-on output.
  • Page 12 Multi Channel Amplifiers Speaker wiring connections 570-AZR170X2 2 Channel Amp 2 Speaker setup X-OVER X-OVER - 11 -...
  • Page 13 Multi Channel Amplifiers 570-AZR400X4 4 Channel Amp 4 Speaker setup X-OVER X-OVER X-OVER X-OVER - 12 -...
  • Page 14 Multi Channel Amplifiers 570-AZR700X5 5 channel Amp 4 Speaker + Sub-Woofer setup X-OVER X-OVER X-OVER X-OVER SUB-WOOFER - 13 -...
  • Page 15 Multi Channel Amplifiers 570-AZR170X2 / 570-AZR400X4 / 570-AZR700X5 Power and ground setup FUSE SOURCE UNIT - 14 -...

  • Page 16: Troubleshooting Guide

    Multi Channel Amplifiers Troubleshooting Guide Problem Causes and solutions power indicator is not lit A. Check +12 volt wire fuse blown and replace if needed B. Check remote turn on +12V and GND connections ensure the ground is secured to clean metal on the vehicle chassis. C. source unit not functioning properly power indicator is lit / A.

  • Page 17: Specifications

    Multi Channel Amplifiers Specifications Model 570-AZR170X2 570-AZR400X4 570-AZR700X5 description 170W Multi 400W Multi 700W Multi Channel Amp Channel Amp Channel Amp Continuous 4Ω stereo 85W X2 RMs 70W X4 RMs 85W X4 RMs + power @ 275W sub-Woofer 14.4V, 4Ω bridged 260W X1 RMs...

  • Page 18: Limited Warranty Information

    Kaption Audio’s discretion. What is not covered 1.

  • Page 19: Warranty Registration Card

    KAPTION AUDIO PRODUCTS COME WITH A ONE-YEAR PARTS AND LABOUR LIMITED WARRANTY. This warranty covers the original purchaser of a Kaption Audio product, purchased from an authorized Kaption Audio dealer. In order to receive service, proof of purchase is required stating the customers name, dealer name, product purchased and date of purchase.
  • Page 20 Kaption Audio 95 Cousins drive Aurora, Ontario Canada, L4G 1B5 www.KaptionAudio.com 866-Kaption (527-8466) designed in Canada; Made in China R1 (04/17)
