- Page 1 Core Health & Fitness INSTALL MANUAL...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING! Before using this product, it is essential to read the ENTIRE Owner’s Manual and ALL installation instructions. The Owner’s Manual describes equipment setup and instructs members on how to use correctly and safely. Read all warnings posted on the machine. Health related injuries may result from incorrect or excessive use of exercise equipment. -
Page 3: Product Spotlight
PRODUCT SPOTLIGHT 9-5285 SKU: Desc: Overall Weight Width Length Height User Weight 646 lbs (293 kg) 34.9 in (88.6 cm) 69.5 in (176 cm) 82.3 in (209 cm) 80-400 lbs (36-181 kgs) Page 2... -
Page 4: Part Identification
PART IDENTIFICATION Console Leveling Foot UP/DOWN Keypad Shrouds / Housing Handrail STOP Keypad Main Frame Stair Transport Wheel Heart Rate Grips Page 3... -
Page 5: Required Tools
ASSEMBLY Required Tools: • 12” Ratchet Wrench • Dead Blow Mallet • 19mm or 3/4” Socket • Knife • 19mm Open-Ended Wrench • Crowbar • 9/16 Open-Ended Wrench Carefully cut and remove any plastic wrap and cardboard around the unit. Cut any straps holding the unit to the pallet. - Page 6 With the help of another person, carefully lower the front end of the 10G off the pallet. Move the unit into the gym or facility. Once inside, remove the mobility wheel locking pin by pulling outwards on the pin. Use a 12” ratchet wrench with a 19mm or 3/4” socket and attach the wrench to the exposed nut on the inner left shroud near the bottom step.
- Page 7 Once the mobility wheel has been deployed, insert the mobility wheel pin into the second, lower hole on the frame. CAUTION: Unit can tip to the right when mobility wheel is deployed. Move the unit to its fi nal install location using the mobility wheel.
-
Page 8: Support And Service
SUPPORT & SERVICE CORE Get world class support for all brands with our new support portal, Core Connect. Get help with your general inquiries, warranty registration, preventative maintenance, service requests and parts orders. You can CONNECT also make seamless service requests, get real time updates, manage your assets and intuitively order parts for all brands direct from the site. - Page 9 © 2019 CORE HEALTH & FITNESS, LLC PART NUMBER 620-8763, REV A...
