Assembly Instructions
& User's Manual
Triton Chargriddle Combo
Model #: FSOGBG2200
Please keep this instruction manual for future reference
Customer Service: (888) 922-2336, 7:00 am to 12:00 am daily CST
Live Chat on Academy Website (www.academy.com) 24/7 or email
customerservice@academy.com
(Made in China)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Outdoor Gourmet Triton FSOGBG2200
Summary of Contents for Outdoor Gourmet Triton FSOGBG2200
- Page 1 Assembly Instructions & User’s Manual Triton Chargriddle Combo Model #: FSOGBG2200 Please keep this instruction manual for future reference Customer Service: (888) 922-2336, 7:00 am to 12:00 am daily CST Live Chat on Academy Website (www.academy.com) 24/7 or email customerservice@academy.com (Made in China)
-
Page 2: Table Of Contents
Table of Contents Warnings…………………………………………………………………..3-7 Tools and Parts…………………………………………………...………8-9 Exploded View…………………………………………………………..10 Hardware…………………………………………………………………...11 Assembly Instructions………………………………………….……..12-18 Operating Instructions……………………………………………..19-22 Trouble Shooting……………………………………………………..…...22 Care and Maintenance…………………………………………..…...23-24 Frequently asked questions……………………………………...…..….25 Warranty Information………………………………………....26 Page 2 of 26... - Page 3 Page 3 of 26...
-
Page 4: Warnings
Warnings Page 4 of 27... - Page 5 Warnings Page 5 of 26...
- Page 6 Warnings Page 6 of 27...
- Page 7 Warnings Page 7 of 26...
-
Page 8: Tools And Parts
Tools Required Adjustable wrench （not included） Screwdriver （not included） Page 8 of 26... - Page 9 Parts List Page 9 of 26...
-
Page 10: Exploded View
Exploded View Page 10 of 26... -
Page 11: Hardware
Hardware Page 11 of 26... -
Page 12: Assembly Instructions
Assembly Instructions Step 1: Assemble the bottom shelf (1) to the legs (2),(3) using BOLT M6X50 (CC)-4PCS. Step 2: Assemble the long fence rails (4)-2PCS to both legs using BOLT M6X12 (AA)- 8PCS. Page 12 of 26... - Page 13 Assembly Instructions Step 3: Assemble the threaded casters (5)X4 to legs by twisting clockwise until tight. Turn over the bottom assembly when completed and lock all casters to prevent from moving. Step 4: Align and place body (6) on top of the legs.Using BOLT M6X12 (AA)- 10 PCS, attach the triangular bracket left (8) and right (9) to back of body...
- Page 14 Assembly Instructions Step 5: Install side shelf support (10) between the lower connecting slice (12 &13) using PIN ROLL (FF)-2PCS and COTTER PIN (GG)-2PCS. Assemble the side shelf (11) between the upper connecting slice (12&13) using PIN ROLL (FF)-2PCS and COTTER PIN (GG)-2PCS.
- Page 15 Assembly Instructions Step 7: Screw in BOLT M6X12 (AA)- 2 PCS halfway on the upper corner of side shelf-R (14) as shown IMAGE 1. Slide the two screws into the opening as shown in IMAGE 2.Using BOLT M6X12 (AA)- 4PCS, fasten the right side shelf in place and tighten all screws.
- Page 16 Assembly Instructions Step 9: Remove the screw pre-assembled on the thermometer (26) IMAGE 4. Assemble it to the charcoal lid (16) and secure with the screw Image . Align and place charcoal lid on top of the body (right side). Place PIN ROLL (EE)-2PCS as shown IMAGE 5 through the hinges and screw with COTTER PIN (GG)-...
- Page 17 Assembly Instructions Step 11: Place cooking grates (21)-2PCS into body Place griddle top (22) onto body. Step 12: Assemble gas tank hold (24) and gas tank hook (25) on left leg using BOLT M6X12 (AA)-4PCS. Assemble "S" hooks (23)-4PCS to control panel on griddle side. Page 17 of 26...
- Page 18 FULLY ASSEMBED Page 18 of 26...
-
Page 19: Operating Instructions
Operating Instructions General Information and Instructions Your new Griddle has been designed and manufactured to high quality standards. It will provide you with many years of enjoyment with a minimal amount of maintenance. Please keep in mind the following FOR YOUR SAFETY. - Page 20 Operating Instructions Page 20 of 26...
- Page 21 Operating Instructions Page 21 of 26...
-
Page 22: Trouble Shooting
Operating Instructions & Trouble shooting Page 22 of 26... -
Page 23: Care And Maintenance
Care and Maintenance Griddle Surface- 1.Immediately after using the griddle turn heat to “Low” position. While hot, the griddle top should be washed with water and a lint-free cloth. 2.Keep the griddle on “Low” heat until the griddle is completely dry. 3.Now turn off the griddle and allow to cool before proceeding. - Page 24 Care and Maintenance Page 24 of 26...
-
Page 25: Frequently Asked Questions
Frequently Asked Questions Can I restore my griddle if it has gotten rusty? It is important to maintain griddles and keep them seasoned to minimize rusting. There are numerous suggested guides to bring a griddle cooking surface back to cooking grade. If the rust is not to extensive, it usually takes a fine brush. -
Page 26: Warranty Information
Warranty Information This product has been manufactured under the highest standards of quality and workmanship. We warrant to the original consumer purchaser that all aspects of this product will be free of defects in material and workmanship for one year from the date of purchase. A replacement for any defective part will be supplied free of charge for installation by the consumer.
