KI WireWorks Assembly Instructions

off-module panel
top clamp
Figure 1
WireWorks spine wall
Figure 2
off-module
top cap
Figure 3
Assembly Instructions
WireWorks
Off-Module Panel Components
1"
half post
clamping
screw
off-module panel
connector assembly
Detail A
(OMPC)
steel
horizontal
Detail B
top cap
trim
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Panel System
®
July 2016
Off-Module Panel Connector
WireWorks Off-Module Panel Connector
(OMPC) allows a WireWorks panel to
be attached perpendicular at any point
along a WireWorks spine wall.
The OMPC and half post is factory
assembled. By design, the top of the
half post will be approximately 1"
higher than the top of the OMPC
(Figure 1).
1. Position the OMPC assembly at the
2. Loosen the clamping screw to allow
top
3. While holding the OMPC upright,
clamp
4. Check for plumb and tighten
rail
5. Adjust the glide so the post is
6. Install off-module top cap and trim
point where it is to be connected to
the WireWorks spine wall (Figure 2).
Note: The OMPC must be the same
height as the height of the horizontal
rail to which it attaches.
the top clamp to be inserted in the
reveal between tiles (Detail A).
insert the bottom clamp into the
reveal located directly above the
WireWorks raceway door. The clamp
must engage into the slot of the steel
horizontal rail (Detail B).
clamping screw.
appropriately supported.
as shown in Figure 3. Note: Flat
aluminum trim does not have an
off-module top cap.
