- Page 1 USER’S MANUAL • AGHR-100 • ASHR-100 • AGHR-130 • ASHR-130 • AGHR-150 • ASHR-150 SINGLE-ROOM REVERSIBLE ENERGY REGENERATION VENTILATOR...
-
Page 2: Table Of Contents
CONTENTS Safety requirements Purpose Delivery set Main technical parameters Design and operating logic Mounting and set-up Connection to power mains Ventilator control Maintenance Troubleshooting Storage and transportation regulations Manufacturer's warranty Acceptance certificate Seller information Installation certificate Warranty Card... -
Page 3: Safety Requirements
The user’s manual consisting of the technical details, operating instructions and technical specification applies to the installation and mounting of the single-room energy regeneration reversible ventilator (hereinafter «the unit» as mentioned in the «Safety Requirements» and «Manufacturer’s Warranty» sections as well as in warnings and information blocks). SAFETY REQUIREMENTS •... - Page 4 UNIT MOUNTING AND OPERATION SAFETY PRECAUTIONS • Disconnect the unit from power mains prior to • Do not allow children to operate the unit. any technical maintenance. • When the unit generates unusual sounds, • Do not store any explosive or highly flammable odour or emits smoke disconnect it from substances in close proximity to the unit.
-
Page 5: Purpose
The ventilator is designed for through-the-wall mounting. The telescopic ventilator design enables its installation in the walls with various thickness, see the table below: Wall thickness Ventilator model • AGHR-100 300 mm - 570 mm (11 13/16’’ - 22 7/16”) • ASHR-100 •... -
Page 6: Main Technical Parameters
Ingress Protection (IP) rating from solid objects and liquids IP 24. The ventilator design is regularly improved, so some models may slightly differ from those ones described in this manual. VENTILATOR OVERALL DIMENSIONS, MM (INCHES) 300-570 AGHR-100 (5 ¼") (11 ⁄ "-22 ⁄ ") (1 ⁄ ") (9 ⁄... - Page 7 250-470 ASHR-130 (5 ¼") (9 ⁄ "-18 ½") (3 ⁄ ") (11") 3 1/8" ( 9 ⁄ ") 5 ⁄ " 5 ⁄ " (11 ⁄ ") 250-470 (11") (5 ¼") (9 ⁄ "-18 ½") (2 ¼") AGHR-130 ( 8 ⁄ ") 5 ⁄...
- Page 8 VENTILATOR TECHNICAL DATA AGHR-100, ASHR-100 Speed Supply Voltage, 50-60 Hz [V] 1~100-230 Air Capacity [m /h] (CFM) 7 (4) 15 (9) 24 (14) Power [W] 3,50 3,95 5,32 Current [A] 0,023 0,026 0,036 RPM [min 1190 1330 2420 Noise Level, 1 m [dB(A)] (Sones)
-
Page 9: Design And Operating Logic
The ventilation unit is lator. The lters prevent regener- equipped with automatic shutters open- ator soiling. ing when the ventilator is on and clos- ing when it is o , thus preventing back air ow. AGHR-100 ASHR-100 AGHR-130 ASHR-130 AGHR-150 ASHR-150 Ceramic regenerator... - Page 10 VENTILATOR OPERATING MODES The ventilator has four ventilation modes: • Natural air supply - the automatic shutters are opened, the fan does not run • Supply - the ventilator supplies fresh air to the premise no matter of CN7 jumper position. •...
-
Page 11: Mounting And Set-Up
A stated below: Inside Outdoors ( 4 ⁄ ") Ventilator model A, mm (inches) AGHR-100 While mounting several connected in series ventilators cut out a 10 ( ’’) ASHR-100 cavity for the cable layout during the hole preparation to enable series connection of several ventilators. - Page 12 5. Remove the screw in the bottom part of the ventilator. 6. Remove the front panel of the ventilation unit. AGHR-100 ASHR-100 AGHR-100 ASHR-100 7. Prepare four fastening holes and fix the back cover of the ventilation unit on the wall with fours 4x40 screws and 6x40 dowels from the delivery set.
- Page 13 AGHR-130, AGHR-150 VENTILATOR MOUNTING 1. To mount the ventilator prepare a thorough hole in the wall. The 2. After preparing a through hole in the wall cut out a 25 mm (1’’) deep hole size and profile are shown in the figure below. recess for laying of the cables and the contact sockets connected to the mounting plate.
- Page 14 4. Connect the mounting plate following the Wiring Diagram section, page 20. Prepare four fastening holes and fix the mounting plate on the wall with fours 4x40 screws and 6x40 dowels from the delivery set. Align the telescopic air duct with respect to the mounting plate and fill the gaps between the wall and the telescopic air duct with a mounting foam.
- Page 15 VENTILATION HOOD MOUNTING 1. Mark the fastening holes for the outer ventilation hood and drill holes for the dowel 6x40. For marking convenience use the ventilation hood back part. AGHR-100 ASHR-100 180 mm Ø6 mm (¼") (7 ⁄ ") 4 holes 160 mm (6 ⁄...
- Page 16 VENTILATION HOOD MOUNTING 2. Insert the dowels 6x40 from the delivery set into the holes. 3. Disassemble the outer ventilation hood to enable access to the fastening holes. Take off the front part of the outer ventilation hood. 4. Fix the back part of the ventilation hood on the wall with 4x40 screws from the delivery set. 5.
-
Page 17: Connection To Power Mains
CONNECTION TO POWER MAINS DISCONNECT THE VENTILATOR FROM POWER MAINS PRIOR TO ANY ELECTRIC INSTALLATION OPERATIONS. CONNECTION TO POWER MAINS SHALL ONLY BE PERFORMED BY A PROFESSIONAL ELECTRICIAN QUALIFIED FOR UNASSISTED OPERATIONS WITH ELECTRICAL INSTALLATIONS UP TO 1000 V AFTER CAREFUL STUDY OF THE PRESENT USER’S MANUAL. - Page 18 CONNECTION OF SEVERAL VENTILATORS IN SERIES AGHR-130 ASHR-130 AGHR-150 ASHR-150 Connection of the ventilators enables controlling all the connected ventilators by the first ventilator and the common remote control. To connect the ventilators in series connect the Output contact socket of the first ventilator mounting plate with the Input contact socket of the second ventilator mounting plate.
- Page 19 CONNECTION OF MORE THAN 10 VENTILATORS IN SERIES In case of connection above 10 ventilators the ventilator 11 is energized not though the previous ventilator but from power mains (L and N terminals). The control signals G and D from the 10th ventilator are transferred through the cable 2 x 0.5 mm The ventilators no.
-
Page 20: Ventilator Control
VENTILATOR CONTROL The ventilator is operated with a remote controller or the buttons on the ventilator casing, see the figure below. The operation buttons on the ventilator casing have limited functionality and include activating the second and third speed and setting three of four ventilation modes. - Page 21 REMOTE CONTROL Set the speed switch to position and the ventilation mode switch to position to enable remote control of the ventilation unit. 1. Turning ventilator ON/OFF. ON/OFF 2. Night mode. ON/OFF If Night mode is activated, the ventilator switches to the first speed in the night, when the light is turned off. Activation of the night mode is confirmed by a long sound signal.
-
Page 22: Maintenance
MAINTENANCE DISCONNECT THE VENTILATOR FROM POWER SUPPLY PRIOR TO ANY MAINTENANCE OPERATIONS. Maintenance of the ventilator means regular cleaning of the ventilator surfaces of dust and cleaning or replacement of the filters. MAINTENANCE 1. Fan maintenance (once per year). Take off the ventilation unit and clean the fan blades. - Page 23 Even regular technical maintenance may not completely prevent dirt accumulation on the regenerator assemblies. • Subject the regenerator to regular cleaning to ensure high heat recovery efficiency. • Clean the regenerator with a vacuum cleaner at least once in a year. To reset the motor meter install the filters and the regenerator into the ventilator and then press and hold the button for 10 sec.
-
Page 24: Troubleshooting
TROUBLESHOOTING POSSIBLE FAULTS AND TROUBLESHOOTING Fault Possible reasons Fault handling Make sure that the ventilator is properly connected No power supply. to the power mains and make any corrections, if The fan does not start up necessary. during the ventilator start- Turn the ventilator off. -
Page 25: Manufacturer's Warranty
MANUFACTURER’S WARRANTY The manufacturer hereby warrants normal operation of the unit for 24 months after the retail sale date provided the user’s observance of the transportation, storage, mounting and operation regulations. Should any malfunctions occur in the course of the unit operation through the Manufacturer’s fault during the guaranteed period of operation the user is entitled to elimination of faults by the manufacturer by means of warranty repair at the factory free of charge. -
Page 26: Acceptance Certificate
ACCEPTANCE CERTIFICATE Unit Type The single-room reversible energy regeneration ventilator Model _________________ Serial Number Manufacture Date Is compliant with the technical specifications and is recognized as serviceable. We hereby declare that the product complies with the essential protection requirements of Electromagnetic Council Directive 2004/108/ EC, 89/336/EEC and Low Voltage Directive 2006/95/EC, 73/23/EEC and CE-marking Directive 93/68/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. -
