Closed Front View - Acer Aspire 7750Z Service Manual

Table 1-1. Top View (Continued)
No Icon
7
8
9

Closed Front View

Figure 1-2. Closed Front View
Table 1-2. Closed Front View
No Icon
1
2
Hardware Specifications and Configurations
Item
Palmrest Comfortable support area for hands when using the
computer.
Speakers Deliver stereo audio output.
Microphone Internal microphone for sound recording.
1
2
Item
Power indicator
Battery indicator
Hard Disk Drive
(HDD) indicator
Communication
key
Multi-in-1 card
reader
Description
Description
Turns the computer On and Off.
Indicates the computer's battery status.
1. Charging: The light shows amber when the
battery is charging.
2. Fully charged: The light shows blue when in
AC mode.
Indicates when the hard disk drive is active.
Enables/disables the computer's communication
devices. (Communication devices may vary by
configuration.)
Accepts Secure Digital (SD), MultiMediaCard
(MMC), Memory Stick PRO (MS PRO),
xD-Picture Card (xD).
NOTE:
Note: Push to remove/install the card. Only
one card can operate at any given time.
0
1-13
