Subaru 2010 Legacy Specifications

2010 Legacy Specifications
®
ENGINE AND DRIVETRAIN
Engine
Power
Torque
Manual transmission
Automatic transmission
SYMMETRICAL ALL-WHEEL DRIVE
Continuous All-Wheel Drive
Active All-Wheel Drive
Variable Torque Distribution (VTD)
All-Wheel Drive
STABILITY AND TRACTION
Vehicle Dynamics Control (VDC)
Traction Control System (TCS)
CHASSIS
Steering
Suspension
Brakes
WHEELS AND TIRES
Wheels
Tires
ExTERIOR DIMENSIONS
Length/Width/Height
Wheelbase
Specifications are subject to change
* SPORTSHIFT is a registered trademark of Prodrive, LTD.
2.5i, 2.5i Premium and 2.5i Limited
SOHC 4-cylinder, horizontally opposed
(Boxer); aluminum cylinder block and heads,
i-Active Valve Lift System (AVLS)
170 hp @ 5,600 rpm
170 lb.-ft. @ 4,000 rpm
Standard fully synchronized 6-speed manual
Lineartronic TM CVT (Continuously Variable
Transmission) includes 6-speed manual mode
and steering wheel-mounted paddle shifters.
2.5i and 2.5i Premium: Optional.
2.5i Limited: Standard.
Models equipped with 6-speed manual transmissions utilize a viscous-type locking center differential with torque distribution normally configured at a
50/50-split front-to-rear. If wheel speed differs between front and rear axles, the system helps distribute power to the wheels with the most traction.
Models equipped with Lineartronic™ CVT utilize an electronically controlled variable transfer clutch to distribute power to where traction is needed.
Sensors monitor parameters such as wheel slippage, throttle position and braking, to help determine torque distribution and direct it to the wheels
with optimum traction.
Models equipped with 5-speed automatic transmission utilize an electronically controlled variable transfer clutch in conjunction with a planetary-type
center differential and a viscous-type limited-slip rear differential. Torque distribution is normally configured at a performance-oriented rear-wheel-biased
45/55-split front-to-rear. Sensors monitor parameters such as wheel slippage, throttle position and braking to help determine torque distribution and
direct it to the wheels with optimum traction.
VDC electronic stability control utilizes sensors which constantly monitor wheel speeds, steering angle, brake pressure, vehicle yaw rate and lat-
eral g-forces. If VDC detects a difference between the driver's intended path and the one the vehicle is actually taking, VDC applies braking power
and/or reduces engine torque to help correct vehicle path. Standard on all models
VDC also incorporates an all-wheel, all-speed traction control system which senses a loss of traction and applies braking force to the slipping wheel
or wheels as necessary to maintain vehicle motion.
Rack-and-pinion with engine-speed controlled variable power assist
Front: MacPherson-type struts with internal rebound springs, lower L-arms,
coil springs and stabilizer bar
Rear: Double wishbone with subframe
Power-assisted 4-wheel disc with Electronic Brake-force Distribution (EBD), 4-channel / 4-sensor ABS and Brake Assist
2.5i: 16-in. Steel with full wheel covers
2.5i Premium: 16-in. Aluminum-Alloy
2.5i Limited: 17-in Aluminum-Alloy
2.5i: 205/60R16
2.5i Limited: 215/50R17
186.4 in./71.7 in./59.3 in.
108.3 in.
2.5GT Premium, 2.5GT Limited
DOHC 4-cylinder, horizontally opposed (Boxer),
aluminum cylinder block and heads; Dual Active
Valve Control System (DAVCS) variable valve tim-
ing, turbocharged/intercooled
265 hp @ 5,600 rpm
258 lb.-ft. @ 2,000-5,200 rpm
Standard fully synchronized 6-speed
manual
Not available
18-in. Aluminum-Alloy
215/45R18
3.6R, 3.6R Premium and 3.6R Limited
DOHC 6-cylinder, horizontally opposed
(Boxer); aluminum cylinder block and heads;
Dual Active Valve Control System (DAVCS)
variable valve timing
256 hp @ 6,000 rpm
247 lb.-ft. @ 4,400 rpm
Not available
5-speed electronic control automatic with
SPORTSHIFT®* manual mode
17-in. Aluminum-Alloy
225/50R17
