OCCUPATIONAL HEALTH WARNINGS:
1. Construction equipment frequently operates at very high sound levels. Such sound levels
can be harmful to the human hearing system. Sustained exposure to such high sound
levels can permanently impair one's hearing. Hearing protection should be worn by
anyone and everyone within close proximity to a Vibratory Pile Driver/Extractor
System.
2. Do not start or operate the V-22/HP-365A until having thoroughly read this manual and
having received instructions from an MKT factory authorized service representative or
properly trained, experienced operator.
MANUFACTURING, INC.
1198 PERSHALL RD.
ST. LOUIS, MO 63137
OPERATING, MAINTENANCE AND
PARTS MANUAL FOR
V-22/HP-365A
HYDRAULIC VIBRATORY PILE
DRIVER/EXTRACTOR SYSTEM
WITH CUMMINS ENGINE
CALIFORNIA
PROPOSITION 65 WARNING
DIESEL ENGINE EXHAUST AND
SOME OF ITS CONSTITUENTS
ARE KNOWN TO THE STATE OF
CALIFORNIA TO CAUSE
CANCER, BIRTH DEFECTS, AND
OTHER REPRODUCTIVE HARM.
Manual No. 140602
