Operating & Installation Instructions
Front Loading Washing Machine
Model BD-90XAV / BD-80XAV / BD-90YAV / BD-80YAV
Thank you for purchasing a Hitachi front loading washing machine.
■
Please read these operating & installation instructions carefully for proper
operation of the machine.
■
Please keep these operating & installation instructions for future reference.
Contents
3
4
6
7
9
11
16
18
18
21
23
24
30
31
31
Advertisement
Table of Contents
Related Manuals for Hitachi BD-90XAV
Summary of Contents for Hitachi BD-90XAV
-
Page 1: Table Of Contents
Error Codes How to Install the Washing Machine Customer Service Consumption Values Specifi cations Thank you for purchasing a Hitachi front loading washing machine. ■ Please read these operating & installation instructions carefully for proper operation of the machine. ■... - Page 2 Memo...
-
Page 3: Environmentally Friendly Waste Disposal
Environmentally Friendly Waste Disposal Disposing of the The shipping package has protected your new washing machine on its way to your home. All materials are ecologically harmless and recyclable. packaging Please contribute to a better environment by disposing of packaging materials in an environmentally conscious manner. -
Page 4: Safety Instructions
Safety Instructions Before operating the washing machine, please read these safety instructions carefully. Warning Issues which could cause death or serious injury ■ Do not dismantle, repair or modify the appliance. General safety This could cause malfunction, fi re, electric shock or injury. For repair, please contact your local service center. - Page 5 Safety Instructions ■ Keep packaging out of reach of children and babies. Child safety Danger of suffocation. ■ Do not let children climb onto the washing machine or open the drum door, and do not leave a box or chair near the washing machine which could enable children to climb onto it.
-
Page 6: Product Descriptions
Product Descriptions Detergent Dispenser Softener Cap Dispenser : For fabric softener Dispenser : For prewash Dispenser : For main wash Drain Hose Control Panel Door Handle Door Lock Power Cord Emergency Door Lock Release Drain Tube Drain Filter Filter Cover Adjustable Feet (4 pcs.) Packed-In Accessories Hose Guide... -
Page 7: Control Panel And Display
Control Panel and Display Power button Start/Pause button Jog Dial Temperature button Spin button Prewash button XAV series : BD-90XAV/BD-80XAV Intensive button Extra Rinse button Rinse Hold button (Child Lock) Timer button Memory button LED multi function display YAV series : BD-90YAV/BD-80YAV Auto Self Clean button Press this button to switch power on and off. - Page 8 Control Panel and Display Allows you to store a customized wash cycle which you use frequently. Memory button symbol is shown on the display. Displays all cycle information, remaining time and error codes. LED multi function display Water temperature symbol is on when the heater is off (Cold setting). Spin speed (No Spin) : Final spin is cancelled and last rinse water is drained only.
-
Page 9: Before You Start Washing
Control Panel and Display The following symbols are displayed when washing time is prolonged due to : ● Excessive foam in the drum. Pouring in extra water to remove excessive foam. The symbol on the left lights. ● Imbalance in the drum. Correcting imbalance by rotating the drum. - Page 10 Before You Start Washing ■ Use the amount of detergent recommended on the detergent package. Detergent and The type and amount of detergent depends on the type of fabric, load additives size, degree of soiling and hardness of the water used. Use less detergent if : - you wash a small load.
-
Page 11: How To Use The Washing Machine
How to Use the Washing Machine Sort and load ■ Sort the laundry according to type of fabric, care label symbol, color the laundry and degree of soiling. Page 9 : Preparation of the washing. ■ Do not exceed the maximum load. ■... - Page 12 How to Use the Washing Machine ■ Pausing a program. Press the Start/Pause button. The washing machine switches itself off if it is not restarted within 1 hour. Switch the power on and the program starts again from the beginning. ■...
- Page 13 How to Use the Washing Machine 1. Press the Power button to turn on the power. How to 2. Select a program. use the 3. Press the Auto Self Clean button, and then press the Auto Self Clean Start/Pause button. function ■...
- Page 14 How to Use the Washing Machine 1. Press the Power button to turn on the power. How to use the Memory function 2. Select and adjust the program as desired. 3. Press the Memory button for 3 seconds, then the setting is memorized. 4.
- Page 15 How to Use the Washing Machine Washable Items with the Duvet program : ● Washable Duvets Machine washable duvets stuffed with not more than 1 kg of down or synthetic material (polyester). - Do not wash duvets stuffed with wool or duvets with a silk covering. - Do not add other items in the same wash.
-
Page 16: Program Overview
Program Overview Max Load Program Type of Laundry / Notes 90 type / 80 type For daily washing of cotton and linen items such as shirts, underwear, Cotton 9 kg / 8 kg towels, bed linen and table linen. For cotton and linen items. Eco operation that saves energy and water that Cotton Eco 9 kg / 8 kg provides the same washing performance as the Cotton program. - Page 17 Selectable Options Temperature Auto Spin Setting Setting Prewash Intensive Extra Rinse Rinse Hold Timer Self Clean 400- ※ Max r/min, /30-90ºC No Spin 400- ※ Max r/min, 30-60ºC No Spin 400-800r/min, /30ºC No Spin ◇ r/min, /30-60ºC No Spin ◇ r/min, /30-60ºC No Spin 400-800r/min,...
-
Page 18: In Case Of Emergency
In Case of Emergency The washing machine features a Fully Auto Restart function. In the event of a If the power is shut off part way through a wash, the cycle (wash/rinse/ power outage spin) at the time is memorized, and when power is restored, the same cycle automatically restarts from the beginning. - Page 19 Care and Maintenance Cleaning the Drain tube drain fi lter Drain fi lter Filter cover Risk of injury! Hot water may come out from the drain tube and drain fi lter. - Do not open the drain fi lter when a program is running. - Do not clean the drain fi...
- Page 20 Care and Maintenance 1. Remove the detergent dispenser. Cleaning the detergent Push the dent dispenser Pull the detergent dispenser while pushing the dent. 2. Remove dirt or detergent remaining in the detergent dispenser casing with a brush. Detergent dispenser casing 3.
-
Page 21: Troubleshooting
Troubleshooting Problem Possible Cause Solution ● ● Door cannot be There is still some water in the washing Run the Drain program to opened. machine. drain water. ● ● Child lock may be activated. Deactivate the child lock. (See page 8) ●... - Page 22 Troubleshooting Problem Possible Cause Solution ● ● Foam remains You may have used too much detergent. Use the appropriate amount of ● on the door or Laundry is new or not that soiled. detergent. the door seal. ● ● Fabric softener You may have exceeded the max.
-
Page 23: Error Codes
Error Codes Code Description Possible Cause Solution ● Water is not Water tap may not be turned on. Check water tap, water ● supplied. Water inlet fi lter may be clogged. inlet fi lter, water line and ● Water line or water hose may be frozen. water hose. -
Page 24: How To Install The Washing Machine
600 mm H:850 mm (*820 mm) (BD-80XAV / BD-80YAV) *Max. depth when the door is closed: 594 mm (BD-90XAV / BD-90YAV) *Max. depth when the door is closed: 634 mm (*Height without worktop for under-counter installation) ■ Where to install Install the appliance on a fl... - Page 25 How to Install the Washing Machine ■ Remove the four transport bolts and insert the cover caps using the Removing the packed-in 13 mm box spanner. transport bolts ■ The transport bolts must always be removed before using the washing machine for the fi...
- Page 26 How to Install the Washing Machine Water supply hose ● Connecting the water supply ■ Optimum water pressure is 0.03-0.8MPa. ■ Do not connect to the mixer tap of an unpressurised hot-water apparatus. ■ Use a horizontal tap. Horizontal tap Extension tap Square tap Connect the water supply hose to the rear panel of...
- Page 27 How to Install the Washing Machine ■ Make sure that the union nut between the water supply hose and main unit is tightly screwed. ■ Turn the tap on to check if the water supply hose is properly connected before starting. If it is loosely connected, water leakage may occur. ●...
- Page 28 How to Install the Washing Machine ■ Connect the washing machine to an alternating current via a correctly Connecting the installed earthed socket only. power ■ The mains voltage must correspond to the voltage specifi cation on the washing machine. ■...
- Page 29 How to Install the Washing Machine ■ You need a space at least 3 mm of clearance on the sides, above and Under-counter back. installation ■ If the height of the space ranges from 823 mm to 852 mm, use upper plate (sold separately).
-
Page 30: Customer Service
How to Install the Washing Machine 1. Turn on the water tap and close the washing machine door. Checking after installation 2. Press the Power button to switch power on. 3. Select the Cotton program and press the Start/Pause button. 4. -
Page 31: Consumption Values
Consumption Values (BD-90XAV) Consumption value** Time Program Load Temperature Option Spin speed (about) Power Water Cotton 9 kg 40ºC 1200 r/min 0.74kwh 1:33h 40ºC 1200 r/min 0.76kwh 2:39h Cotton Eco 9 kg 60ºC Intensive 1400 r/min 0.80kwh 3:37h Rapid 15 2 kg 30ºC... - Page 32 Consumption Values (BD-80XAV) Consumption value** Time Program Load Temperature Option Spin speed (about) Power Water Cotton 8 kg 40ºC 1200 r/min 0.65kwh 1:33h 40ºC 1200 r/min 0.68kwh 2:39h Cotton Eco 8 kg 60ºC Intensive 1400 r/min 0.69kwh 3:37h Rapid 15 2 kg 30ºC 800 r/min...
- Page 33 Consumption Values (BD-90YAV) Consumption value** Time Program Load Temperature Option Spin speed (about) Power Water Cotton 9 kg 40ºC 1000 r/min 0.74kwh 1:37h 40ºC 1000 r/min 0.76kwh 2:43h Cotton Eco 9 kg 60ºC Intensive 1200 r/min 0.80kwh 3:37h Rapid 15 2 kg 30ºC 800 r/min...
- Page 34 Consumption Values (BD-80YAV) Consumption value** Time Program Load Temperature Option Spin speed (about) Power Water Cotton 8 kg 40ºC 1000 r/min 0.65kwh 1:37h 40ºC 1000 r/min 0.68kwh 2:43h Cotton Eco 8 kg 60ºC Intensive 1200 r/min 0.69kwh 3:37h Rapid 15 2 kg 30ºC 800 r/min...
- Page 35 Memo...
