  • Page 1 R292-4S0 R292-4S1 2U Quad 3rd Generation Intel® Xeon® Scalable Processors Rack-mount Server User Manual Rev. 1.0...
  • Page 2 GIGABYTE's prior written permission. Documentation Classifications In order to assist in the use of this product, GIGABYTE provides the following types of documentation:  User Manual: detailed information & steps about the installation, configuration and use of this product (e.g.
  • Page 3 Conventions The following conventions are used in this user's guide: NOTE! Gives bits and pieces of additional information related to the current topic. CAUTION! Gives precautionary measures to avoid possible hardware or software problems. WARNING! Alerts you to any damage that might result from doing or not doing specific actions.
  • Page 4 Server Warnings and Cautions Before installing a server, be sure that you understand the following warnings and cautions. WARNING! To reduce the risk of electric shock or damage to the equipment: • Do not disable the power cord grounding plug. The grounding plug is an important safety feature.
  • Page 5 Electrostatic Discharge (ESD) CAUTION! ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE, PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP AT- TACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR SERVER WHEN HANDLING PARTS.
  • Page 6 CAUTION! Risk of explosion if battery is replaced incorrectly or with an incorrect type. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used bat- teries according to the manufacturer’s instructions.

  • Page 7: Table Of Contents

    Table of Contents Chapter 1 Hardware Installation ...................10 Installation Precautions .................. 10 Product Specifications ..................11 System Block Diagram ................... 14 Chapter 2 System Appearance ..................16 Front View ...................... 16 Rear View ....................... 17 Front Panel LED and Buttons ................ 18 Rear System LAN LEDs .................
  • Page 8 Chapter 5 BIOS Setup ....................52 The Main Menu ....................54 Advanced Menu ..................... 57 5-2-1 Trusted Computing ....................58 5-2-2 Serial Port Console Redirection ................59 5-2-3 SIO Configuration ....................63 5-2-4 PCI Subsystem Settings ..................64 5-2-5 USB Configuration ....................66 5-2-6 Network Stack Configuration ..................67 5-2-7 Post Report Configuration ..................68 5-2-8...
  • Page 9 Boot Menu .....................111 Save & Exit Menu ..................113 BIOS POST Codes ..................115 5-8-1 AMI Standard - PEI ....................115 5-8-2 AMI Standard - DXE .....................115 5-8-3 AMI Standard - ERROR ..................117 5-8-4 Intel UPI POST Codes ..................118 5-8-5 Intel UPI Error Codes ...................118 5-8-6 Intel MRC POST Codes ..................119 5-8-7...

  • Page 10: Chapter 1 Hardware Installation

    Chapter 1 Hardware Installation Installation Precautions The motherboard/system contain numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the user manual and follow these procedures: • Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or warranty sticker provided by your dealer.

  • Page 11: Product Specifications

    Intel® SATA RAID 0/1/10/5 Š Expansion Slot R292-4S0 Total 6 x PCIe x16 slots Supports 4 x FHFL double slot GPU Cards or 6 x FHFL PCIe HBAs Riser Card CRS202A: 2 x PCIe x16 slot ( Gen3 x16), FHFL Š...
  • Page 12 Expansion Slot R292-4S1 Total 8 x PCIe x16 slots Riser Card CRS202A: 2 x PCIe x16 slot ( Gen3 x16), FHFL Š Riser Card CRS2040: 4 x PCIe x16 slot ( Gen3 x16), FHFL Š Riser Card CRS2029: 2 x PCIe x16 slot ( Gen3 x16), FHFL Š...
  • Page 13 Power Supply 2+0 3200W 80 PLUS Platinum Power Supply (R292-4S0) Š 1+1 3200W 80 PLUS Platinum Redundant Power Supply (R292-4S1) Š Input: Š - 100-127V~/ 14A - 180-219V~/ 16A - 220-239V~/ 16A - 240-264V~/ 16A 50/ 60Hz or 240V 16A Output: Š...

  • Page 14: System Block Diagram

    System Block Diagram Hardware Installation - 14 -...
  • Page 15 - 15 - Hardware Installation...

  • Page 16: Chapter 2 System Appearance

    Chapter 2 System Appearance Front View HDD0 HDD2 HDD4 HDD6 HDD8 HDD1 HDD3 HDD5 HDD7 HDD9 Description Front Panel LEDs and Buttons 2.5" HDD Bays Front USB 3.0 Ports Mezzanine Card Connector (OCP 3.0/ SFF Type) 2-3 Front Panel LED and Buttons •...

  • Page 17: Rear View

    Rear View PCIe Slot 7 PCIe Slot 1 PCIe Slot 3 PCIe Slot 8 PCIe Slot 2 PCIe Slot 4 PCIe Slot 5 PSU2 PSU1 PCIe Slot 6 Description Serial Port VGA Port USB 3.0 Port x 2 10/100/1000 Server management LAN port 10GbE BASE-T LAN Port x 2 USB 3.0 Port x 2 2-7 Expansion PCIe Slot Configuration...

  • Page 18: Front Panel Led And Buttons

    Front Panel LED and Buttons Name Color Status Description Reset Button Press the button to reset the system. Press the button server generates a NMI to the processor NMI button if the multiple-bit ECC errors occur, which effectively halt the server. Green System is powered on Green...

  • Page 19: Rear System Lan Leds

    Rear System LAN LEDs Name Color Status Description Yellow 1 Gbps data rate 1GbE Green 100 Mbps data rate Speed LED 10 Mbps data rate Link between system and 1GbE Green network or no access Link/ Activity Blink Data transmission or receiving is occurring No data transmission or receiving is occurring Yellow 5Gbps, 2.5Gbps, 1Gbps data rate...

  • Page 20: Power Supply Unit (Psu) Led

    Power Supply Unit (PSU) LED PSU LED State Description No AC power to all power supplies 1Hz Green Blinking AC present / only standby on / Cold redundant mode 2Hz Green Blinking Power supply firmware updateing mode AC cord unplugged or AC power lost; with a second power supply in parallel still with AC input power Amber Power supply critical event causing shut down:...

  • Page 21: Hard Disk Drive Leds

    Hard Disk Drive LEDs HDD Present RAID SKU Rebuilding LED1 Locate HDD Fault Access (No Access) Disk LED Green ON(*1) BLINK (*2) (LED on Back Panel) Amber No RAID configuration Green ON(*1) (via PCH, HBA) Removed HDD Slot (LED on Back Panel) Amber Green BLINK (*2)

  • Page 22: Expansion Pcie Slot Configuration

    PCIe Slot 1 PCIe Slot 3 PCIe Slot 8 PCIe Slot 2 PCIe Slot 4 PCIe Slot 5 PSU2 PSU1 PCIe Slot 6 R292-4S0 PCIe Slot 1 GPU1 RAID Card1 PCIe Slot 2 RAID Card2 LAN Card 2 PCIe Slot 3 GPU3...

  • Page 23: Chapter 3 System Hardware Installation

    Chapter 3 System Hardware Installation Pre-installation Instructions Computer components and electronic circuit boards can be damaged by electrostatic discharge. Working on computers that are still connected to a power supply can be extremely dangerous. Follow the simple guidelines below to avoid damage to your computer or injury to yourself.

  • Page 24: Removing Chassis Cover

    Removing Chassis Cover Before you remove or install the system cover • Make sure the system is not turned on or connected to AC power. Follow these instructions to remove the chassis cover: Remove the screw securing the chassis cover. Push button to unlock the handle.

  • Page 25: Removing And Installing The Fan Duct

    Removing and Installing the Fan Duct Please remove the PCIe riser first and then remove Fan Wall before removing the Fan duct. Follow these instructions to remove/install the fan duct: Remove the system front cover and then unlock the latches on both sides of the system. Slide the front hard drive cage to the front of the system.

  • Page 26: Removing The Heat Sink

    Removing the Heat Sink Follow these instructions to remove/install the fan duct: Loosen the captive screws securing the heatsink in place in reverse order (4g3g2g1), then move the rotating wires into the unlatch position. Lift and remove the heat sink from the system. To reinstall the heat sink reverse steps 1-2 while ensuring that you tighten the captive screws in sequential order (1g2g3g4) as seen in the image below.

  • Page 27: Installing The Cpu

    Installing the CPU Read the following guidelines before you begin to install the CPU: • Make sure that the motherboard supports the CPU. • Always turn off the computer and unplug the power cord from the power outlet before installing the CPU to prevent hardware damage.
  • Page 28 System Hardware Installation - 28 -...

  • Page 29: Installing The Memory

    Installing the Memory Read the following guidelines before you begin to install the memory: • Make sure that the motherboard supports the memory. It is recommended that memory of the same capacity, brand, speed, and chips be used. • Always turn off the computer and unplug the power cord from the power outlet before installing the memory to prevent hardware damage.

  • Page 30: Installing The Memory

    3-5-2 Installing the Memory Before installing a memory module, make sure to turn off the computer and unplug the power cord from the power outlet to prevent damage to the memory module. Be sure to install DDR4 DIMMs on this motherboard. Follow these instructions to install the Memory: Insert the DIMM memory module vertically into the DIMM slot, and push it down.

  • Page 31: Installing The Pci Expansion Card

    Installing the PCI Expansion Card • Voltages can be present within the server whenever an AC power source is connected. This voltage is present even when the main power switch is in the off position. Ensure that the system is powered-down and all power sources have been disconnected from the server prior to installing a PCIe card.

  • Page 32: Installing The Mezannine Card

    Installing the Mezzanine Card 3-7-1 OCP 3.0 Use of the following type of OCP 3.0 NIC is recommended: • OCP 3.0 SFF with Pull Tab • OCP 3.0 SFF with Ejector Latch Follow these instructions to install an OCP 3.0 mezzanine card: Remove the two screws securing the mezzanine card slot cover.

  • Page 33: Installing The Hard Disk Drive

    Installing the Hard Disk Drive Read the following guidelines before you begin to install the HDD: • Take note of the drive tray orientation before sliding it out. • The tray will not fit back into the bay if inserted incorrectly. •...

  • Page 34: Installing The M.2 Device And Heat Sink

    Installing the M.2 Device and Heat Sink WARNING: Installation of the thermal pad over the M.2 device is required when installing an M.2 device. Lack of the thermal pad may result in the system overheating and throttle the system performance. CAUTION The position of the stand-off screw will depend on the size of the M.2 device.

  • Page 35: Removing And Installing The Fan Wall

    3-10 Removing and Installing the Fan Wall • Voltages can be present within the server whenever an AC power source is connected. This voltage is present even when the main power switch is in the off position. Ensure that the system is powered-down and all power sources have been disconnected from the server prior to replacing a system fan.

  • Page 36: Replacing The Fan Assembly

    3-11 Replacing the Fan Assembly • Voltages can be present within the server whenever an AC power source is connected. This voltage is present even when the main power switch is in the off position. Ensure that the system is powered-down and all power sources have been disconnected from the server prior to replacing a system fan.

  • Page 37: Replacing The Power Supply

    3-12 Replacing the Power Supply Follow these instructions to replace the power supply: Press the retaining clip on the right side of the power supply along the direction of the arrow. Pull out the power supply handle at the same time and pull out the power supply. Insert the replacement power supply firmly into the chassis.

  • Page 38: Cable Routing

    3-13 Cable Routing Front Switch Cable/Front LED Cable Front Panel USB 3.0 Cable System Hardware Installation - 38 -...
  • Page 39 Front HDD Backplane Board Power Cable Front HDD Backplane Board Signal Cable - 39 - System Hardware Installation...
  • Page 40 Rear Fan Cable GPU Card#0 Power Cable (for R292-4S0 only) System Hardware Installation - 40 -...
  • Page 41 GPU Card#1 Power Cable (for R292-4S0 only) GPU Card#2 Power Cable (for R292-4S0 only) - 41 - System Hardware Installation...
  • Page 42 GPU Card#3 Power Cable (for R292-4S0 only) Riser Card#1 Top Signal Cable System Hardware Installation - 42 -...
  • Page 43 Riser Card#2 Top Signal Cable (for R292-4S1 only) Riser Card#2 Bottom Signal Cable (for R292-4S1 only) - 43 - System Hardware Installation...
  • Page 44 Riser Card#3 Bottom Signal Cable SlimLine SAS Cable #1/#2/#3 System Hardware Installation - 44 -...
  • Page 45 NVMe Card #0/#1 NVMe Card #2/#3 - 45 - System Hardware Installation...
  • Page 46 NVMe Card #4/#5 <R292-4S0> <R292-4S1> System Hardware Installation - 46 -...
  • Page 47 NVMe Card #6/#7 <R292-4S0> <R292-4S1> - 47 - System Hardware Installation...
  • Page 48 NVMe Card #8/#9 System Hardware Installation - 48 -...

  • Page 49: Chapter 4 Motherboard Components

    Chapter 4 Motherboard Components Motherboard Components CPU0 CPU3 CPU1 CPU2 Item Description Power Supply Connector #1 (Primary) M.2 Connector (PCIe Gen3 x2, Supports NGFF-2280) Riser Connector #1 (2*PCIe Gen3 x16/Proprietary slot) System Battery Slimline SAS 4i Connectors (SATA 6Gb/s Signal) Slimline SAS 4i Connector (sSATA 6Gb/s Signal) TPM Module Connector (SPI Interface) Riser Connector #2 (2*PCIe Gen3 x16/Proprietary slot)
  • Page 50 2 x 7 Pin HDD Back Plane Board Power Connector 2 x 4 Pin P12V GPU Power Connector 2 x 4 Pin P12V GPU Power Connector Front Panel USB 3.0 Connector IPMB Connector Slimeline SAS 8i Connectors (PCIe Gen3 x8 Signal for CPU2) Slimeline SAS 8i Connectors (PCIe Gen3 x8 Signal for CPU1) OCP Mezzanine Connector (OCP3.0/SFF Type/Gen3 x16) HDD Back Plane Board Connector...

  • Page 51: Jumper Setting

    Jumper Setting MB_SW1 Stop initial power on S3_MASK Normal [Default] when BMC is not ready Password Default PMBUS_SEL PMBUS connect to PCH Normal [Default] Clear Enable BIOS_PWD HSMB_SEL Normal [Default] HSMB connect to BMC ME Force BIOS Recovery BIOS recovery mode Normal [Default] Default Update...

  • Page 52: Chapter 5 Bios Setup

    Chapter 5 BIOS Setup BIOS (Basic Input and Output System) records hardware parameters of the system in the EFI on the motherboard. Its major functions include conducting the Power-On Self-Test (POST) during system startup, saving system parameters, loading the operating system etc. The BIOS includes a BIOS Setup program that allows the user to modify basic system configuration settings or to activate certain system features.
  • Page 53  Main This setup page includes all the items of the standard compatible BIOS.  Advanced This setup page includes all the items of AMI BIOS special enhanced features. (ex: Auto detect fan and temperature status, automatically configure hard disk parameters.) ...

  • Page 54: The Main Menu

    The Main Menu Once you enter the BIOS Setup program, the Main Menu (as shown below) appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter other sub-menu. Main Menu Help The on-screen description of a highlighted setup option is displayed on the bottom line of the Main Menu.
  • Page 55 Parameter Description BIOS Information Project Name Displays the project name information. Project Version Displays version number of the BIOS setup utility. Build Date and Time Displays the date and time when the BIOS setup utility was created. BMC Information (Note1) BMC Firmware Version Displays BMC firmware version information.
  • Page 56 Onboard LAN Information LAN1 MAC Address Displays LAN MAC address information. (Note) LAN2 MAC Address (Note) Displays LAN MAC address information. System Date Sets the date following the weekday-month-day-year format. System Time Sets the system time following the hour-minute-second format. (Note) The number of LAN ports listed will depend on the motherboard / system model.

  • Page 57: Advanced Menu

    Advanced Menu The Advanced Menu displays submenu options for configuring the function of various hardware components. Select a submenu item, then press <Enter> to access the related submenu screen. When Boot Mode Select is set to UEFI (Default) - 57 - BIOS Setup...

  • Page 58: Trusted Computing

    5-2-1 Trusted Computing Parameter Description Configuration Enable/Disable BIOS support for security device. OS will not show security device. TCG EFI protocol and INT1A interface will not be Security Device Support available. Options available: Enable, Disable. Default setting is Enable. Enable/Disable Override to allow SID authentication in TCG Storage Disable Block Sid device.

  • Page 59: Serial Port Console Redirection

    5-2-2 Serial Port Console Redirection Parameter Description Console redirection enables the users to manage the system from a COM1 Console remote location. Redirection (Note)) Options available: Enabled, Disabled. Default setting is Disabled. Press [Enter] to configure advanced items. Please note that this item is configurable when COM1 Console Redirection is set to Enabled.
  • Page 60 Parameter Description Parity Š – A parity bit can be sent with the data bits to detect some transmission errors. – Even: parity bit is 0 if the num of 1's in the data bits is even. – Odd: parity bit is 0 if num of 1's in the data bits is odd. –...
  • Page 61 Parameter Description Legacy Console Redirection Press [Enter] to configure advanced items. Redirection COM Port Š – Selects a COM port for Legacy serial redirection. – Default setting is COM1. Resolution Š – Selects the number of rows and columns used in Console Redirection for legacy OS support.
  • Page 62 Parameter Description Flow Control EMS Š – Flow control can prevent data loss from buffer overflow. When sending data, if the receiving buffers are full, a 'stop' signal can Serial Port for Out-of-Band be sent to stop the data flow. Once the buffers are empty, a 'start' EMS Console Redirection signal can be sent to re-start the flow.

  • Page 63: Sio Configuration

    5-2-3 SIO Configuration Description Parameter Displays the AMI SIO driver version information. AMI SIO Driver Version Super IO Chip Logical Device(s) Configuration Press [Enter] to configure advanced items. Use This Device Š – When set to Enabled allows you to configure the serial port settings. When set to Disabled, displays no configuration for the serial port.

  • Page 64: Pci Subsystem Settings

    5-2-4 PCI Subsystem Settings BIOS Setup - 64 -...
  • Page 65 Parameter Description PCI Bus Driver Version Displays the PCI Bus Driver version information. When enabled, this setting will initialize the device expansion PCI Express Slot # I/O ROM ROM for the related PCI-E slot. (Note1) Options available: Enabled, Disabled. Default setting is Enabled. Enable/Disable the onboard LAN1/ LAN2 controller.

  • Page 66: Usb Configuration

    5-2-5 USB Configuration Parameter Description USB Configuration USB Devices: Displays the USB devices connected to the system. Enable/Disable the XHCI (USB 3.0) Hand-off support. XHCI Hand-off Options available: Enabled, Disabled. Default setting is Enabled. USB Mass Storage Driver Enable/Disable the USB Mass Storage Driver Support. Support Options available: Enabled, Disabled.

  • Page 67: Network Stack Configuration

    5-2-6 Network Stack Configuration Parameter Description Enable/Disable the UEFI network stack. Network Stack Options available: Enabled, Disabled. Default setting is Enabled. Enable/Disable the Ipv4 PXE feature. Ipv4 PXE Support Options available: Enabled, Disabled. Default setting is Enabled. Enable/Disable the Ipv4 HTTP feature. Ipv4 HTTP Support Options available: Enabled, Disabled.

  • Page 68: Post Report Configuration

    5-2-7 Post Report Configuration Parameter Description Post Report Configuration Error Message Report Enable/Disable the POST Error Message support. Post Error Message Options available: Enabled, Disabled. Default setting is Enabled. - 68 - BIOS Setup...

  • Page 69: Nvme Configuration

    5-2-8 NVMe Configuration Parameter Description NVMe Configuration Displays the NVMe devices connected to the system. Options available: BIOS Build-In, NVMe Device. Default setting is BIOS NVMe OPROM Select Build-In. NVMe Device # Press [Enter] for configuration of advanced items. BIOS Setup - 69 -...

  • Page 70: Chipset Configuration

    5-2-9 Chipset Configuration Parameter Description Defines the power state to resume to after a system shutdown that is due to an interruption in AC power. When set to Last State, the system will return to the active power state prior to shutdown. When set to Restore on AC Power Loss (Note) Power Off, the system remains off after power shutdown.

  • Page 71: Tls Auth Configuration

    5-2-10 Tls Auth Configuration Parameter Description Press [Enter] for configuration of advanced items. Enroll Cert Š – Press [Enter] to enroll a certificate • Enroll Cert Using File • Cert GUID Server CA Configuration Input digit character in 1111111-2222-3333-4444-1234567890ab format. –...

  • Page 72: Iscsi Configuration

    5-2-11 iSCSI Configuration Parameter Description Press [Enter] configure advanced items. Attempt Priority Š Attempt Priority – Options available: Host Attempt, Redfish Attempt, Rsd Attempt. Default setting is Host Attempt. Commit Changes and Exit Š Press [Enter] to configure advanced items. iSCSI Initiator Name Š...

  • Page 73: Intel(R) X710 10Gbase-T Network Connection

    5-2-12 Intel(R) X710 10GBASE-T Network Connection - 73 - BIOS Setup...
  • Page 74 Description Parameter Press [Enter] to configure advanced items. Link Speed Š – Allows for automatic link speed adjustment. – Options available: Auto Negotiated, 10 Mbps Half, 10 Mbps Full, 100 Mbps Half, 100 Mbps Full. Default setting is Auto Negotiated. Wake On LAN Š...

  • Page 75: Vlan Configuration

    5-2-13 VLAN Configuration - 75 - BIOS Setup...
  • Page 76 Parameter Description Press [Enter] to configure advanced items. Create new VLAN Š VLAN ID Š – Sets VLAN ID for a new VLAN or an existing VLAN. – Press the <+> / <-> keys to increase or decrease the desired values. –...

  • Page 77: Ipv4 Network Configuration

    5-2-14 IPv4 Network Configuration Parameter Description Indicates whether network address is configured successfully or not. Configured Options available: Enabled, Disabled. Default setting is Disabled. Options available: Enabled, Disabled. Default setting is Enabled. Enable DHCP (Note) Local IP Address Press [Enter] to configure local IP address. (Note) Press [Enter] to configure local NetMask.

  • Page 78: Driver Health

    5-2-15 Driver Health Parameter Description Driver Health Displays driver health status of the devices/controllers if installed BIOS Setup - 78 -...

  • Page 79: Chipset Menu

    Chipset Menu Chipset Setup menu displays submenu options for configuring the function of Platform Controller Hub(PCH). Select a submenu item, then press <Enter> to access the related submenu screen. BIOS Setup - 79 -...
  • Page 80 5-3-1 Processor Configuration - 80 - BIOS Setup...

  • Page 81: Processor Configuration

    Description Parameter Processor Configuration Press [Enter] to configure advanced items. CPU Socket 0/1/2/3 Configuration Š – Core Disable Bitmap(Hex) • Number of Cores to enable. 0 means all cores. FFFFFFF Pre-Socket Configuration means to disable all cores. The maximum value depends on the number of CPUs available.

  • Page 82: Common Refcode Configuration

    5-3-2 Common RefCode Configuration Parameter Description Common RefCode Configuration Selects the MMIO High Base setting. MMIO High Base Options available: 56T, 40T, 32T, 24T, 16T, 4T, 2T, 1T, 512G, 3584T. Default setting is 4T. Selects the allocation size used to assign memory-mapped I/O (MMIO) resources.

  • Page 83: Upi Configuration

    5-3-3 UPI Configuration - 83 - BIOS Setup...
  • Page 84 Description Parameter UnCore Configuration Press [Enter] to configure advanced items. Uncore Status Š – Press [Enter] to view the Uncore status. Link Frequency Select Š – Selects the UPI link frequency. – Options available: 9.6GB/s, 10.4GB/s, Auto, Use Per Link Setting. Default setting is Auto.

  • Page 85: Memory Configuration

    5-3-4 Memory Configuration Description Parameter Integrated Memory Controller (iMC) When set to Enable, the system enforces Plan Of Record restrictions for DDR4 frequency and voltage programming. Enforce POR Options available: POR, Disable. Default setting is POR. Enable/Disable memory population POR enforcement. Options available: Disable Enforcement, Enforce Supported Enforce Population POR Populations, Enforce Validated Populations.
  • Page 86 Description Parameter Specifies the Data Save Mode for ADR. Batterybacked or Type 01 NVDIMM. ADR Data Save Mode Options available: Disable, Batterybacked DIMMs, NVDIMMs. Default setting is NVDIMMs. Enable/Disable Erasing and Arming NVDIMMs. Erase-Arm NVDIMMs Options available: Enable, Disable. Default setting is Enable. Enable/Disable Automatic restoring of NVDIMMs.
  • Page 87 Description Parameter Correctable Error Time Window Š – Correctable Error time window based interface in hour (0-24). – Press the <+> / <-> keys to increase or decrease the desired values. Leaky bucket time window based interface Š – Enable/Disable leaky bucket time window based interface. –...

  • Page 88: Iio Configuration

    5-3-5 IIO Configuration Description Parameter IIO Configuration Press [Enter] to configure advanced items. ® Intel VT for Directed I/O (VT-d) Š – Enable/Disable the Intel VT for Directed I/O (VT-d) support function by reporting the I/O device assignment to VMM through DMAR ACPI Tables.
  • Page 89 Description Parameter Press [Enter] to configure advanced items. ® Intel VMD technology Š ® ® Intel VMD technology Intel VMD Configuration Š – Enable/Disable the Intel VMD support function. – Options available: Enable, Disable. Default setting is Disable. Enable/Disable MCTP (Management Component Transport Protocol). MCTP Options available: Yes, No.

  • Page 90: Advanced Power Management Configuration

    5-3-6 Advanced Power Management Configuration Description Parameter Advanced Power Management Configuration Press [Enter] to configure advanced items. SpeedStep (Pstates) Š – Conventional Intel SpeedStep Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. –...
  • Page 91 Description Parameter Press [Enter] to configure advanced items. Hardware P-States Š – When this item is disabled, the processor hardware chooses a P-state based on OS Request (Legacy P-States). – In Native mode, the processor hardware chooses a P-state based Hardware PM State Control on OS guidance.

  • Page 92: Pch Configuration

    5-3-7 PCH Configuration Description Parameter PCH Configuration Press [Enter] to configure advanced items. SATA Controller Š – Enable/Disable SATA controller. – Options available: Enable, Disable. Default setting is Enable. Configure SATA as Š – Configures on chip SATA type. – AHCI Mode: When set to AHCI, the SATA controller enables its AHCI functionality.
  • Page 93 Description Parameter Port 0/1/2/3/4/5/6/7 Š – Enable/Disable Port 0/1/2/3/4/5/6/7 device. – Options available: Enable, Disable. Default setting is Enable. Hot Plug (for Port 0/1/2/3/4/5/6/7) (Note 2) Š – Enable/Disable HDD Hot-Plug function. PCH SATA Configuration – Options available: Enable, Disable. Default setting is Disable. (continued) Spin Up Device (for Port 0/1/2/3/4/5/6/7) (Note 2)

  • Page 94: Miscellaneous Configuration

    5-3-8 Miscellaneous Configuration Description Parameter Miscellaneous Configuration Selects the active video type. Options available: Auto, Onboard Device, PCIE Device. Default setting is Active Video Auto. BIOS Setup - 94 -...

  • Page 95: Server Me Configuration

    5-3-9 Server ME Configuration Parameter Description General ME Configuration Oper. Firmware Version Displays the operational firmware version. ME Firmware Status #1/#2 Displays ME Firmware status information. Current State Displays ME Firmware current status information. Error Code Displays ME Firmware status error code. Recovery Cause Displays ME Firmware recovery cause.

  • Page 96: Runtime Error Logging Settings

    5-3-10 Runtime Error Logging Settings Description Parameter Runtime Error Logging Enable/Disable system error logging function. System Errors Options available: Enable, Disable. Default setting is Enable. Enable/Disable software injection error logging function. S/W Error Injection Support Options available: Enable, Disable. Default setting is Disable. Press [Enter] to configure advanced items.
  • Page 97 Description Parameter Press [Enter] to configure advanced items. PCIE Error Š – Enable/Disable PCIE error. – Options available: Enable, Disable. Default setting is Enable. Uncorrected Error Š – Enables and escalates Uncorrectable/Recoverable Errors to error pins. – Options available: Enable, Disable. Default setting is Enable. Fatal Error Enable Š...

  • Page 98: Power Policy

    5-3-11 Power Policy Description Parameter Selects a Power Policy Quick Setting. Options available: Standard, Best Performance, Energy Efficient, Turbo Power Policy Quick Settings Lock. Default setting is Standard. Conventional Intel SpeedStep Technology switches both voltage and frequency in tandem between high and low levels in response to processor SpeedStep (Pstates) load.
  • Page 99 Description Parameter Configures the state for the C-State package limit. Options available: C0/C1 state, C2 state, C6(non Retention) state, Package C State C6(Retention) state, No Limit, Auto. Default setting is Auto. The Hyper Threading Technology allows a single processor to execute two or more separate threads concurrently.

  • Page 100: Server Management Menu

    Server Management Menu Parameter Description Enable/Disable FRB-2 timer (POST timer). FRB-2 Timer Options available: Enabled, Disabled. Default setting is Enabled. Configures the FRB2 Timer timeout. The value is between 1 to 30 minutes. FRB-2 Timer Default setting is 6 minutes. timeout Please note that this item is configurable when FRB-2 Timer is set to Enabled.
  • Page 101 Parameter Description POST wait BMC ready and reboot system. Wait BMC Ready Options available: Disabled, 2 minutes, 4 minutes, 6 minutes. Default setting is 2 minutes. System Event Log Press [Enter] to configure advanced items. View FRU Press [Enter] to view the FRU information. Information BMC Self test log Press [Enter] to configure advanced items.

  • Page 102: System Event Log

    5-4-1 System Event Log Parameter Description Enabling / Disabling Options Change this item to enable or disable all features of System Event SEL Components Logging during boot. Options available: Enabled, Disabled. Default setting is Enabled. Erasing Settings Choose options for erasing SEL. Erase SEL Options available: No;...

  • Page 103: View Fru Information

    5-4-2 View FRU Information The FRU page is a simple display page for basic system ID information, as well as System product information. Items on this window are non-configurable. (Note) The model name will vary depends on the product you purchased - 103 - BIOS Setup...

  • Page 104: Bmc Self Test Log

    5-4-3 BMC Self Test Log Parameter Description Choose options for erasing log. Erase Log Options available: No; Yes, On every reset. Default setting is Yes, On every reset. Selects the action to be taken when log is full. When log is full Options available: Clear Log, Do not log any more.

  • Page 105: Bmc Vlan Configuration

    5-4-4 BMC VLAN Configuration Description Parameter BMC VLAN Configuration Select to configure BMC VLAN ID. The valid range is from 0 to 4094. When BMC VLAN ID set to 0, BMC VLAN ID will be disabled. Select to configure BMC VLAN Priority. The valid range is from 0 to 7. BMC VLAN Priority When BMC VLAN ID is set to 0, BMC VLAN Priority will not be selected.

  • Page 106: Bmc Network Configuration

    5-4-5 BMC Network Configuration Parameter Description BMC network configuration Lan Channel 1 Selects to configure LAN channel parameters statically or dynamically (DHCP). Do nothing option will not modify any BMC network parameters Configuration Address source during BIOS phase. Options available: Unspecified, Static, DynamicBmcDhcp, DynamicBmcNonDhcp.

  • Page 107: Ipv6 Bmc Network Configuration

    5-4-6 IPv6 BMC Network Configuration Parameter Description IPv6 BMC network configuration IPv6 BMC Lan Channel 1 Enable/Disable IPv6 BMC LAN channel function. When this item is disabled, the system will not modify any BMC network during BIOS IPv6 BMC Lan Option phase.

  • Page 108: Security Menu

    Security Menu The Security menu allows you to safeguard and protect the system from unauthorized use by setting up access passwords. There are two types of passwords that you can set: • Administrator Password Entering this password will allow the user to access and change all settings in the Setup Utility. •...

  • Page 109: Secure Boot

    5-5-1 Secure Boot The Secure Boot submenu is applicable when your device is installed the Windows 8 (or above) operating ® system. Parameter Description System Mode Displays if the system is in User mode or Setup mode. Enable/ Disable the Secure Boot function. Secure Boot Options available: Enabled, Disabled.
  • Page 110 Parameter Description Press [Enter] to configure advanced items. Please note that this item is configurable when Secure Boot Mode is set to Custom. Factory Key Provision Š – Allows to provision factory default Secure Boot keys when system is in Setup Mode.

  • Page 111: Boot Menu

    Boot Menu The Boot menu allows you to set the drive priority during system boot-up. BIOS setup will display an error message if the legacy drive(s) specified is not bootable. Parameter Description Boot Configuration Number of seconds to wait for setup activation key. 65535 (0xFFFF) Setup Prompt Timeout means indefinite waiting.
  • Page 112 Parameter Description FIXED BOOT ORDER Priorities Press [Enter] to configure the boot priority. By default, the server searches for boot devices in the following sequence: Hard drive. Boot Option #1 / #2 / #3 / #4 / #5 CD-COM/DVD drive. USB device.

  • Page 113: Save & Exit Menu

    Save & Exit Menu The Save & Exit menu displays the various options to quit from the BIOS setup. Highlight any of the exit options then press <Enter>. Parameter Description Save Options Saves changes made and closes the BIOS setup. Save Changes and Exit Options available: Yes, No.
  • Page 114 Parameter Description Loads the default settings for all BIOS setup parameters. Setup Defaults are quite demanding in terms of resources consumption. If you are using low-speed memory chips or other kinds of low-performance components Restore Defaults and you choose to load these settings, the system might not function properly.

  • Page 115: Bios Post Codes

    BIOS POST Codes 5-8-1 AMI Standard - PEI PEI_CORE_STARTED 0x10 PEI_CAR_CPU_INIT 0x11 PEI_CAR_NB_INIT 0x15 PEI_CAR_SB_INIT 0x19 PEI_MEMORY_SPD_READ 0x2B PEI_MEMORY_PRESENCE_DETECT 0x2C PEI_MEMORY_TIMING 0x2D PEI_MEMORY_CONFIGURING 0x2E PEI_MEMORY_INIT 0x2F PEI_MEMORY_INSTALLED 0x31 PEI_CPU_INIT 0x32 PEI_CPU_CACHE_INIT 0x33 PEI_CPU_AP_INIT 0x34 PEI_CPU_BSP_SELECT 0x35 PEI_CPU_SMM_INIT 0x36 PEI_MEM_NB_INIT 0x37 PEI_MEM_SB_INIT 0x3B PEI_DXE_IPL_STARTED...
  • Page 116 DXE_SB_INIT 0x70 DXE_SB_SMM_INIT 0x71 DXE_SB_DEVICES_INIT 0x72 DXE_ACPI_INIT 0x78 DXE_CSM_INIT 0x79 DXE_BDS_STARTED 0x90 DXE_BDS_CONNECT_DRIVERS 0x91 DXE_PCI_BUS_BEGIN 0x92 DXE_PCI_BUS_HPC_INIT 0x93 DXE_PCI_BUS_ENUM 0x94 DXE_PCI_BUS_REQUEST_RESOURCES 0x95 DXE_PCI_BUS_ASSIGN_RESOURCES 0x96 DXE_CON_OUT_CONNECT 0x97 DXE_CON_IN_CONNECT 0x98 DXE_SIO_INIT 0x99 DXE_USB_BEGIN 0x9A DXE_USB_RESET 0x9B DXE_USB_DETECT 0x9C DXE_USB_ENABLE 0x9D DXE_IDE_BEGIN 0xA0 DXE_IDE_RESET 0xA1 DXE_IDE_DETECT...

  • Page 117: Ami Standard - Error

    5-8-3 AMI Standard - ERROR PEI_MEMORY_INVALID_TYPE 0x50 PEI_MEMORY_INVALID_SPEED 0x50 PEI_MEMORY_SPD_FAIL 0x51 PEI_MEMORY_INVALID_SIZE 0x52 PEI_MEMORY_MISMATCH 0x52 PEI_MEMORY_NOT_DETECTED 0x53 PEI_MEMORY_NONE_USEFUL 0x53 PEI_MEMORY_ERROR 0x54 PEI_MEMORY_NOT_INSTALLED 0x55 PEI_CPU_INVALID_TYPE 0x56 PEI_CPU_INVALID_SPEED 0x56 PEI_CPU_MISMATCH 0x57 PEI_CPU_SELF_TEST_FAILED 0x58 PEI_CPU_CACHE_ERROR 0x58 PEI_CPU_MICROCODE_UPDATE_FAILED 0x59 PEI_CPU_NO_MICROCODE 0x59 PEI_CPU_INTERNAL_ERROR 0x5A PEI_CPU_ERROR 0x5A PEI_RESET_NOT_AVAILABLE 0x5B...

  • Page 118: Intel Upi Post Codes

    5-8-4 Intel UPI POST Codes Initialize KTIRC inuput structure default values 0xA0 Collect info such as SBSP, Boot Mode, Reset type etc 0xA1 Setup IO SADs in SBSP to access the config space 0xA2 Setup up minimum path between SBSP & other sockets 0xA3 Add the node to the tree Parse the LEP of the discovered socket...

  • Page 119: Intel Mrc Post Codes

    Unsupported topology 0xDC RC Behavior: System Halt SBSP cannot find KPIRC TXEQ Parameters for this 0xDD link in GetSocketLinkEparams(). No retry. RC Behavior: System Halt 5-8-6 Intel MRC POST Codes Detect DIMM population 0xB0 Set DDR frequency 0xB1 Gather remaining SPD data 0xB2 Program registers on the memory controller level 0xB3...

  • Page 120: Intel Pm Post Codes

    5-8-8 Intel PM POST Codes Start of PPM structure initialization 0xD0 PPM CSR programming 0xD1 PPM MSR programming 0xD2 Start of PState transition init 0xD3 PPM exit 0xD4 PPM On ready to boot event 0xD5 5-8-9 Intel PM POST Codes Start of IIO early Initialization 0xE0 Pre Link training...

  • Page 121: Bios Post Beep Code (Ami Standard)

    BIOS POST Beep code (AMI standard) 5-9-1 PEI Beep Codes # of Beeps Description Memory not Installed. Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found Recovery failed S3 Resume failed Reset PPI is not available...
  • Page 122 This page intentionally left blank - 122 - BIOS Setup...

This manual is also suitable for:

R292-4s1

Table of Contents
