INDICE NORME GENERALI DI SICUREZZA SPECIFICHE PROCEDURA STANDARD PER IL RECUPERO DI FLUIDI/VAPORI PROCEDURA DI SCARICO AUTOMATICO PROCEDURA DI PUSH-PULL PER FLUIDI PROCEDURA DI RAFFREDDAMENTO DEL SERBATOIO (OPZIONALE) PROCEDURA DI RAFFREDDAMENTO ALTERNATIVA (OPZIONALE) CONSIGLI PER IL RECUPERO RICERCA GUASTI SCHEMA ELETTRICO GARANZIA...
NORME GENERALI DI SICUREZZA Leggere attentamente tutte le norme di sicurezza e le istruzioni d’uso prima di azionare la macchina di recupero. Pensare sempre prima di agire. La familiarità favorisce la distrazione e la distrazione può essere pericolosa per la salute o, ancor peggio, causare incidenti mortali.
SPECIFICHE R-12, R22, R-134a, R-401A, R401B, R401C, R402A, R402B, Refrigeranti R404A, R406A, R407B, R407C, R407D, R408A, R409A, R410A, R411A, R411B, R-412A, R500, R502, R507, R509 Tensione 110/120 VAC 60 Hz 220-240 VAC 50 Hz Compressore 1/2HP senza olio Corrente massima 4 A a 50 Hz 9 A a 60 Hz Spegnimento ad alta pressione 38 bar/550 pps...
Page 5
Collegare la macchina di recupero a un’uscita corretta (consultare la targhetta identificativa sulla macchina). Portare l’interruttore di alimentazione in posizione ON fino all’attivazione delle ventole, quindi premere l’interruttore START per avviare il compressore. Aprire lentamente la porta di ingresso sulla macchina. 1) Se il compressore inizia a battere in testa, chiudere lentamente la valvola di ingresso fino alla cessazione del battito in testa.
PROCEDURA DI SCARICO AUTOMATICO Procedura per scaricare il rimanente refrigerante dalla presente macchina Chiudere le porte dell’impianto sottoposto a manutenzione che sono collegate alla porta di ingresso della macchina. Spegnere la macchina di recupero. Portare la valvola di ingresso in posizione di scarico (PURGE). Portare la valvola di modalità...
PROCEDURA DI RAFFREDDAMENTO DEL SERBATOIO (OPZIONALE) Per eseguire questa procedura è necessario che siano presenti almeno 2,3 kg di fluido refrigerante all’interno del serbatoio di stoccaggio. Collegare i tubi flessibili come illustrato. Ruotare la valvola di modalità (MODE) in posizione di recupero (RECOVER). Aprire la valvola dei vapori e dei fluidi del serbatoio di stoccaggio.
CONSIGLI PER IL RECUPERO 1. Utilizzare tubi flessibili più corti possibile per l’intervento. I tubi flessibili lunghi aumentano il tempo di recupero. Rimuovere tutte le restrizioni presenti nei tubi flessibili. I tubi flessibili con valvole a sfera alle estremità sono migliori rispetto ai tubi flessibili auto-sigillanti. Rimuovere, se possibile, le valvole a saracinesca Schrader dalle porte di servizio.
SCHEMA ELETTRICO PRESA ALIMENTAZIONE INTERRUTTORE INTERRUTTORE ELETTRICA DI CIRCUITO DI POTENZA CONNETTORE INTERRUTTORE DI AVVIO CONDENSATORE INTERRUTTORE DI PRESSIONE MOTORE DELLA VENTOLA CONNETTORE MOTORE DEL COMPRESSORE...
GARANZIA La garanzia ha durata di 1 (uno) anno a decorrere dalla data di consegna e copre i difetti del materiale con esclusione delle merci non prodotte dal fornitore. La garanzia non opererà con riferimento ai difetti causati da: • trasporto non idoneo; •...
Page 11
Rev.00/2014 USER MANUAL REFRIGERANT RECOVERY UNIT ITEM CODE: 11131104 -11131106...
Page 12
GENERAL SAFETY GUIDELINES 1.Read all safety, operating guidelines and instructions before opera ting this recovery machine. 2. Always think before acting, familiarity breeds carelessness, and carelessness can be harmful to your health, or worse, result in death. 3.Only a qualified technician should operate this Recovery machine. 4.Read all safety information regarding the safe handling of refrigerant and refrigerant oil, including the Material Safety Data Sheet.
Page 13
SPECIFICHE R-12, R22, R-134a, R-401A, R401B, R401C, R402A, R402B, Refrigerants R404A, R406A, R407B, R407C, R407D, R408A, R409A, R410A, R411A, R411B, R-412A, R500, R502, R507, R509 Voltage 110/120 VAC 60 Hz 220-240 VAC 50 Hz Compressor 1/2HP Oil-less Max current 4 A a 50 Hz 9 A a 60 Hz HP Shut-off 38bar/550psi 38 bar/550 pps Vapor 0,25 kg /min.
Page 14
7. Connect the recovery unit to a right outlet. (See the nameplate on the machine) Switch the power switch to the ON position, to start the compressor. 8. Slowly open the input port on the machine. 1) If the compressor starts to knock, slowly throttle back the input valve until the knocking stops. 2) If the input valve was throttled back, it should be fully opened once the liquid has been removed from the system (the manifold gauge set vapor port should also be opened at this time).
Page 15
SELF-PURGING PROCEDURE Procedure for purging remaining refrigerant from this machine 1. Close the ports of the system being serviced that are connected to the input port of the machine. 2. Turn off the recovery machine. 3. Turn the Input valve to the PURGE position. 4.
Page 16
TANK COOLING PROCEDURE (OPTIONAL) In order for this procedure, you must have a minimum of 5 lbs (2.3kg) of liquid refrigerant in the storage tank. 1.Connect the hoses as shown 2. Turn the MODE valve to the Recover position. 3. Open the Vapor and Liquid valve of the storage tank. 4.
Page 17
OIL SEPARATING PROCEDURE 1.Make sure all connections are correct and tight. 2.Make sure the port of drain valve is closed. 3.Make sure the MODE valve on RECOVERY position. 4.Open the liquid port of the storage tank. 5.Open the output port of the unit and liquid port on the manifold gauge set. 6.Turn the power switch to ON.
Page 18
WIRING DIAGRAM SOCKET CIRCUIT POWER SWITCH BREAKER CONNECTOR SWITCH START CONDENSER PRESSURE SWITCH FAN MOTOR CONNECTOR COMPRESSOR MOTOR...
Page 19
WARRANTY The warranty runs for 1 year from the date of delivery. The supplier guarantees the quality of the materials used and the correct construction of the curtain itself. The warranty covers all defects in materials and production, as well as the supply of spare parts to replace any faulty parts, without this giving any entitlement to indemnity, interest or claims for Damages.
