Thank you for purchasing your new
Round-Top Backyard Chicken Coop!
PLEASE READ as we want your assembly experience to be fun and as
frustration free as possible.
It has been our experience that if you will read through these instructions first, then identify
and lay out each part of your package using the parts identification pages in these
instructions, assembly is more trouble-free. The more options you order, the more important
this becomes as these coops are quite large, and you may become confused by panels that
look similar.
You should expect extra fasteners to be left over. In the rare occasion that we either mis-
manufactured a part, a part was damaged in shipping, or we forgot to package a needed
part, contact us, and we will FedEx a replacement part to you.
There are also helpful assembly videos that can be found on the product page of your coop
at
www.urbancoopcompany.com,
and you can of course contact us at 877-741-2667. We
can solve most issues you might have over the phone.
Advertisement
Related Manuals for Urban Coop Company Backyard Chicken Coop
Summary of Contents for Urban Coop Company Backyard Chicken Coop
- Page 1 Thank you for purchasing your new Round-Top Backyard Chicken Coop! PLEASE READ as we want your assembly experience to be fun and as frustration free as possible. It has been our experience that if you will read through these instructions first, then identify and lay out each part of your package using the parts identification pages in these instructions, assembly is more trouble-free.
- Page 2 3) Phillips Bit 6) Roost Bars 2x 7) Eave Boards 2x Note: The above list is for a base Backyard Chicken Coop. If you 8) Galvalume Roof Panels 2x ordered a run extension (section 12) and/or a Duplex Kit (section 13), you will have more parts and need to reference those sections.
- Page 3 A8 Rear Legs (4 holes in Each; top is beveled) Note: These illustrations are for a base Backyard Chicken Coop. If you ordered a run extension (section 12) and/or a Duplex Kit (section 13), you will have more/different parts and need to reference those sections for A7 Front Legs (have notch additional details.
- Page 4 Backyard Chicken Coop™ Parts Identification B. Roost C. Egg Box & D. Storage Area Fence Illustrations are not to scale and are simplified for ease of reference. Note: These illustrations are for a base Backyard Coop. If you ordered a run extension (section...
-
Page 5: Right Panel
Note: Don't forget the videos on E5 T-Nut YouTube. Search “Urban Coop Company.” A7 Front Leg © Urban Coop Company, all rights reserved. Run Assembly A8 Rear Leg Attach Back Panel: With wire facing inward on A2 back panel, use four E4 bolts and washers and 4 E5 t-nuts to... - Page 6 © Urban Coop Company, all rights reserved. Front Panel Hardware Install SKIP STEP IF YOU’RE INSTALLING A RUN EXTENSION! Step 1: A3 front panel is held into place by two G3 hasps.
- Page 7 It makes top stronger in the middle. © Urban Coop Company, all rights reserved. Roost Assembly Attach B1 roost front to B3 roost sides as shown using E1 brown screws into pre-drilled holes. Top edge should leave a gap for one B7 eave board to fit into, and bottoms should be flush.
- Page 8 E1 Brown Screws holds it in place holds it in place holds it in place during shipping. during shipping. during shipping. © Urban Coop Company, all rights reserved.
- Page 9 (5) E1 screw to lock screws egg box in place. © Urban Coop Company, all rights reserved. Storage/Planter Area Fence Skip this step if you ordered a planter box. See section Set back storage area long piece D3 between legs A8 and egg box side fence board D2 and roost side board D1 in place as shown.
- Page 10 Roost Door Hardware Install Using G2 hardware, install latch onto roost door of front roost panel B1 using screws in latch kits. Remove nail or screw in side of door frame that holds door in place for shipping. You will need to squeeze latch body together a little for holes to line up.
- Page 11 Fig 2 Fig 3 © Urban Coop Company, all rights reserved. Optional Easy-Fill Feeder If you bought the feeder at the same time as your coop, we will have cut out the wire in the mounting holes in the corner of panel A5.
- Page 12 Eye Bolt Screw 3” From Bottom J2 top is flush on Front panel A3 Door sides and Side Panel J1 front A3 Wire Faces Into Run Extension © Urban Coop Company, all rights reserved.
- Page 13 This is optional and purely a cosmetic thing but we (notched) and one end board. Use brown E1 T25 wanted to provide a means to make your new installation screws to secure. just perfect! © Urban Coop Company, all rights reserved.
- Page 14 Run Extension Trim Boards End-Blocks (Gold Screws) Your run extension is shipped with upgraded trim boards that you can optionally install. Using brown Mid-Blocks (Brown Screws) T25 screws, attach the three trim boards around the top of the extension with the end-blocks on the outside of your coop by driving 1 screw down through each mid-block into frame of extension with edges flush.
- Page 15 Ranchette Coop (optional coop doubler) You must FIRST read through the instructions for building the Round-Top Backyard Chicken Coop then NEXT understand these variant instructions for the Ranchette Coop Extender Kit. Look at pictures on the next page...they will help! (R1) One of your panels A6 will be Ÿ...
- Page 16 Shown with optional run extensions installed...
- Page 17 R1 Narrower of the 2 Fill Panels Run Extension or Panel A3 Goes On Ends Coop 1 Run Extension or Panel Coop 2 A3 Goes On Ends Ranchette Run Assembly Illustration of Coop Concept Blow-Up...
- Page 18 Round-Top Planter Box (optional coop accesory) Parts List: 3) Bottom 6) Bottom Side X2 4) 1 5/8 Green T20 Screws 7) 3” Brown T25 Screw 1) Back Panel 5) Longer Side Board 8) 3 ½” Green T25 Screw 2) Front Panel 5a) Shorter Side Board 9) 8 1/8”...
