Thank you for
purchasing your
new Round-Top
Mobile Chicken
Coop!
Urban Coop Company
PLEASE READ... as we want your assembly experience to be fun and as
frustration free as possible.
It has been our experience that if you will read through these instructions first, then identify
and lay out each part of your package using the parts identification pages in these
instructions, assembly is more trouble free. The more options you order, the more
important this becomes as these coops are quite large, and you may become confused by
panels that look similar.
You should expect extra fasteners to be left over. In the rare occasion that we either mis-
manufactured a part, a part was damaged in shipping, or we forgot to package a needed
part, contact us, and we will FedEx a replacement part to you.
There are also helpful assembly videos that can be found on the product page of your
coop at
www.urbancoopcompany.com
We can solve most issues you might have over the phone.
V 08.09.16 Copyright Urban Coop Company, all rights reserved. Do not duplicate by any means except for personal non-commercial use or
distribute without prior written permission of the Urban Coop Company. Contact us at info@uccomail.com or call 877-741-COOP with any
questions or concerns.
The Round-Top Mobile Chicken Coop™ design and/or accessories may be protected by a federal copyright and/or a pending federal
design patent(s).
TM
Find your inner farmer
, and you can of course contact us at 877-741-2667.
Assembly Instructions
Advertisement
Related Manuals for Urban Coop Company Round-Top Mobile Chicken Coop
Summary of Contents for Urban Coop Company Round-Top Mobile Chicken Coop
- Page 1 We can solve most issues you might have over the phone. V 08.09.16 Copyright Urban Coop Company, all rights reserved. Do not duplicate by any means except for personal non-commercial use or distribute without prior written permission of the Urban Coop Company. Contact us at info@uccomail.com or call 877-741-COOP with any questions or concerns.
- Page 2 Round-Top Mobile Chicken Coop Assembly Instructions Assembly is easiest with two people and a dry flat area. You will need several hours of time to assemble. D. Misc. Parts G. Required Tools (not provided) Parts List: 1) Optional Waterer, Bracket & 2...
- Page 3 Round-Top Mobile Chicken Coop™ Parts Identification Wire omitted for simplicity. Parts not shown to scale. B2 & B3 Roost Ends Kims Hen House Egg Box Parts C3 Entry/Exit Board C1 Front Wire Bottom C2 Bottom 2x Sides Parts D5 Egg Box Valence...
- Page 4 Fig 3 BOUGHT AN EXTENSION? See step X1 in run extension section. © Urban Coop Company, all rights reserved. Roost Assembly (Coop Top Part 1) Fig 1 Attach four D3 lift bar brackets and one D4 lift bar (shorter) onto B2 and B3 roost ends as shown using three E1 brown screws for each bracket (one for bottom and two for sides).
- Page 5 Fig 1 Fig 2 © Urban Coop Company, all rights reserved. Squaring (suggested) Fig 1 Your coop is likely square, but it’s good to check. Using a measuring tape, measure the inside distance from corner to corner of the roost and “rack” the coop as needed to make the distance the same. If you own a square that will fit into the roost area and know how to use it, place it against the B2 roost ends and square up to the B1 roost side panels.
- Page 6 Fig 1 C2 Bottom C2 Side Fig 2 © Urban Coop Company, all rights reserved. Install C2 Into Coop (Prior to putting on roof) Fig 1 Lower bottom of C2 assembly into door end of roost. Fig 2 Drop C2 assembly down to where the top edge is flush with lower rail of B1 roost side and back edge tight against B2 roost front wall.
- Page 7 Fig 1 Fig 2 Fig 3 © Urban Coop Company, all rights reserved. Roost Bars Install Fig 1 Lower B4 roost bars (longer) down through the roost top. Using one E1 brown screw on each end, screw through bottom rail of B1 roost side panels into center ends of B4 roost bars. If you miss the exact center of the bar, no big deal, but try to get it the best you can in the center.
- Page 8 Repeat for other side using remaining B5 eave board. Fig 1 Fig 2 © Urban Coop Company, all rights reserved. CAUTION: Any metal roof panel may have edges that are sharp enough to cut you. Be careful! Roof Install Fig 1 Attach one edge of the B6 Galvalume roof panel onto one of the B5 eave boards, centering it from end to end.
- Page 9 Fig 2 Fig 3 Fig 1 © Urban Coop Company, all rights reserved. Optional Waterer Installation Optional Waterer Install Fig 1 If you ordered your waterer at the time of your coop, we have cut out the install hole for you. If not, starting 3”...
- Page 10 Support Posts those shown in photo. © Urban Coop Company, all rights reserved. Optional Waterer Nipple Installation Fig 1 While supporting the waterer, make sure the black rubber grommet is firmly seated into the pre-drilled hole in the waterer. Twist a little to seat it well, if needed.
- Page 11 Round-Top Mobile Chicken Coop™ Run Extension Assembly Instructions for assembling the optional run extension. Parts List: Extension Comes In 1 Box X. Run Extension 1) Sides 2x (identical) 2) Thru Panel 3) Top 4) 3” Brown T25 Screws 18x 5) 3 ½” Hasps 2x...
- Page 12 Repeat for other side. Fig 2 Fig 1 © Urban Coop Company, all rights reserved. Attach Run Extension Top Using eight X4 brown screws into the pre-drilled holes, attach X3 top panel, wire side down, to the side and back assembly.
- Page 13 Fold the hasp over onto the eye bolt, and install the provided spring clip lock. Repeat for the other side. Fig 2 Fig 1 © Urban Coop Company, all rights reserved. Enjoy! Extension can be removed using clips so that you can relocate your coop whenever you want.
