Assembly Instructions
Round-Top Backyard
These written instructions, as
provided with your purchase, will
always be the latest iteration of the
instructions and match the coop
shipped and provide the most
complete up-to-date information.
We depend on feedback about our
instructions to implement changes
to future versions. Please know
that we value your input to that
ongoing process and endeavor to
produce instructions that are as
effective as possible for a wide
variety of customers.
Assembly
Overview...
Use your phones camera to read QR Code.
Representation of procedure... not instructions.
Copyright ® Urban Coop Company all rights reserved. This document is provided to you for your own personal limited use as a paying customer to assemble your coop. We
consider these instructions company intellectual property and are granting you limited personal use only. Do not copy or distribute without written permission of Urban Coop
VJ
Spring '19
Company. We claim all available Federal protection for the name Round-Top Coop™, our protected designs and trade dress as is allowed by any and all Federal intellectual
property protection laws. We invest heavily in your coop and work very hard to do a good job and it is only fair that our workers benefit for their hard work.
Coop™
Help Text-line: 512-596-5200
EMAIL: support@urbancoopcompany.com re: Assembly Support
VOICE: 877-741-COOP | Assembly Support ext 3
Shown With Optional Waterer & Feeder

Advertisement

loading
Need help?

Need help?

Do you have a question about the Round-Top Backyard Coop and is the answer not in the manual?

Questions and answers

Related Manuals for Urban Coop Company Round-Top Backyard Coop

Summary of Contents for Urban Coop Company Round-Top Backyard Coop

  • Page 1 Representation of procedure... not instructions. Copyright ® Urban Coop Company all rights reserved. This document is provided to you for your own personal limited use as a paying customer to assemble your coop. We consider these instructions company intellectual property and are granting you limited personal use only. Do not copy or distribute without written permission of Urban Coop Spring '19 Company.
  • Page 2 Front Left Roost House Can Be Reveresed Page Right Back We recommend having the egg box side of your coop facing North in weather intense locations.
  • Page 3 22" Page...
  • Page 4 Reading this will help you... Understanding these concepts / conventions will help guide you through the instructions. Mating edges of parts to be flush and tight (when called for) will keep measurements in tolerance as the coop grows in size. �...

  • Page 5: Please Be Careful

    Please Be Careful Coop is designed to be assembled by two people of ordinary skill. Any roof metal and flashing can have sharp edges. We attempt to knock of sharp corners and edges from roof metal. You must be the final determiner of sharp edges.
  • Page 6 Written Parts List A. Run Panels G. Hardware A1) Sides 2x (top is wider rail) G1) Spring Clips 4x A2) Back (top is wider rail) G2) Gate Latches 2x A3) Front (has door) G3) Locking Hasps 2x Typical Provided Hardware Box A4) Top Ramp Side (open middle) A5) Top Storage Side Required Tools (not provided)
  • Page 7 Parts ID: 15-20 Minutes of Well Spent Time Tops Wider 2 Identical Panels A1 Sides A1 Sides Top Wider Holes in Face A2 Back Holes in End If you purchased options such as a run extension or a planter box, parts ID and assembly instructions are contained in addendums at the end of these...

  • Page 8: Front Panel

    Parts ID: 15-20 Minutes of Well Spent Time Wire will be cut out if you ordered optional Waterer or Feeder. Front Panel Run Top Panels Page...
  • Page 9 Parts ID: 15-20 Minutes of Well Spent Time Ramp Back Legs Front Legs Header Page...
  • Page 10 B2 Roost Back B1 Roost Front B3 Roost Sides Identical Page Parts ID: 15-20 Minutes of Well Spent Time...
  • Page 11 B4 Center Roof Support B5 Mid-Roof Support Identical B6 Roost Bars Identical B7 Eave Boards Beveled Top Edges Identical Page Parts ID: 15-20 Minutes of Well Spent Time...
  • Page 12 Parts ID: 15-20 Minutes of Well Spent Time C2 Left C1 Right Egg Box Sides (mirrored) C3 Egg Box Door Assembly Page...
  • Page 13 Parts ID: 15-20 Minutes of Well Spent Time D1 Roost Side Shorter D3 Back Side Planter & Storage Yard Boards Longer These parts are omitted if you ordered optional planter box. D2 Egg Box Side Page...

  • Page 14: Handle Carefully

    Parts ID: 15-20 Minutes of Well Spent Time Egg Box Roof Handle Carefully Top has holes in valley groove. Page Bottom Lip Run Roof Panels...
  • Page 15 Here's the first thing to do. See the next page for how to do it. Special Notice Thicker Top Wire Side In Panel Board Brackets If Installed Face Inward Mirrored left and right run sides with legs attached. Page...
  • Page 16 E5 T-Nut E4 Bolt (5/16 x 4" 18TPI) Provided 1/2" wrench E4 Washer or better yet, your 1/2" socket & ratchet. order of assembly Flush Tops Make 2 Mirrored Side Bolt & Washer Panel Assemblies Repeat for all 8 bolts both sides.
  • Page 17 Place A2 Back Panel Between Back Legs And Bolt Into Place It's taking shape now! Using Same Procedure After this, its a good time to level things up From Prior Step For and move into exact spot your coop will sit. T-Nuts &...
  • Page 18 Fit front panel into place. Skip this step if you purchased the optional run extension. That will come later. A3 Front Panel Spread front legs out or in as needed Page to get pins to line up in holes in bottom of A3 front panel and make an equal gap on both sides.
  • Page 19 Ignore this step if you Phillips Bit purchased the optional Bit Holder run extension. That will come later. Your Drill Included Included Round Head Attach bottom side of G3 hasp in predrilled holes in A3 panel. Flip up hasp and install receiver piece of G3 hasp on Your hardware may vary A9 Header and line up as...
  • Page 20 T25 Bit Bit Holder T25 Brown Screw Green arrows indicate a Brown T25 Screw and its direction. Put Front Edge Screws In First Wire Side Up On All Top Panels Flush Front Flush & Edge Square to A1 Sides By Racking Bottom if Needed After Install...
  • Page 21 As illustrated in these instructions, egg box is on the right side of coop. If you flip the A4 panel in the previous step as indicated, you'll be building out the coop with the egg box on the left side of coop. Page...
  • Page 22 T25 Brown Screw Beveled Edge to Top And Centered Left to Right T-20 Green Screw Gently Tap Roof B2 Back Panel Supports Screws Into B3's Down Into Using Brown Brackets Screws Attach B7 Eave Boards Both Sides Using Green Screws All Edges Flush Page Attach B1 to...
  • Page 23 T25 Brown Screw Flush Top Edges Slide To Side To Access Screw Holes If Needed Egg Box Assembly Loosen Leg & Header Bolts If Need To Fit Between Legs Repeat For Both Sides Rests On Top of Wire Inside Edge Page...
  • Page 24 T25 Brown Screw Attach Roost to Run Top Remove brown T-25 shipping screw in door frame to be able to open door. Open Door In Bottom Flush Of Door Frame To Run Top Through Leg Into Frame Of Egg Box Flush Edges If you wanted to move...
  • Page 25 Bit Holder Overlap middle edges of roof metal center left to right and center over top of B4 roof support then affix middle of Use Bit Holder No Bit Ridges In Roof roof screwing through both Metal Point Up sheets into B4. Outer screws first then middle one.
  • Page 26 Tighten just enough to compress rubber Roof Egg Box Roof Screw washer. Ridges In Roof Metal Point Up Install Roof Screws. B2 Slot Notched Edge Center Bottom Left to Right Page...
  • Page 27 Attach Roost Ramp Flat Head Screw Position Ramp As Illustrated And Use Screws To Attach Roost Bar Holder Place the 2 B6 Page Roost Bars Into The Holder. Roost Bar Info: Higher positions are for normal sized hens and provide best weather protection. Lower positions are for either bantam sized birds that don't jump well, or giant breeds that require more head room.
  • Page 28 Attach Roost Door Hardware Small Pan Head Screw Attach catch in pre-drilled holes. Squeeze if needed to get holes to line up. Attach door side of catch too, making sure to align for smooth operation. Use safety clip to make sure door stays locked.
  • Page 29 Longer side board on eggbox side Yard Board Install T25 Brown Screw All outside edges flush. Skip this step if you ordered the optional planter box. Wire will be cut out only if you ordered a feeder or waterer. Shorter side Flush board on roost side...
  • Page 30 Poultry nipple is shipped uninstalled to avoid damage... 1A. Insert the black grommet into bottom end of Waterer using a little vegetable oil rubbed on it if necessary. Make sure any debris from fabrication or shipping is clear of hole before inserting grommet. Press firmly and rotate several times to fully seat.
  • Page 31 No Cross Braces Trim Boards x3 On Run Extension Tops Addendum: Optional Run Extension Extra Spots For Optional Waterers & Feeders In This J2 Top Panel. Note: Wired closed if you did not order optional waterer and/or feeder. From Main Coop Extra Extension Hardware: T25 Brown Screws x16+...
  • Page 32 T25 Brown Screw Wire Down Notch Wire In Bolt Page If you are nesting multiple run extensions into each other, the outer run extension eye bolts will be in the outside edge of J1.
  • Page 33 T25 Brown Screw T20 Gold Screw All Edges Are Flush Page...
  • Page 34 T20 Gold Screw Beauty Boards Omitted Trial fit hinged portion of hasp over eyebolt on run extension then mark holes onto front leg of coop Front Leg Move assembled run extension into place. Use gold T20 screws to attach hinged portion of hasp to front legs of coop.
  • Page 35 An optional waterer and feeder are available for the run extension too. Extension Slips Under Header Board Coop Header Board Metal brackets on front legs can be removed or left in place. Page...
  • Page 36 Flip and install the P5 or P5A support T-20 Green Screw boards as needed to match the orientation of your roost house being on left or right side. Longer Egg Box Side Spacer Block Is Provided To Help Align Sides If You Have No Tape Measure.
  • Page 37 T25 Longer Green Screw T25 Brown Screw Screw Will Be At Angle Pre-Drilled Screws Same This Side The planter box replaces the D1, D2, D3 yard boards of your coop. If you ordered a Page planter box with your coop, we will not ship the standard yard boards.
