Summary of Contents for Lean Cars CH9958A
- Page 1 CH9958A Ride on car Installation and operation manual Forward and backward function Alarm light function Executive standard: EN71 and EN62115 ; GB6675and GB19865 Assembly By Adult Only Please follow real product, Photo for reference only...
- Page 2 The picture in this manual is to show the product operation and structure, please follow the real product only if any difference between picture and product happens. There must be chance not to inform you on time to improve the product result from appearance or structure, please be understood.
- Page 3 部件说明 Component Component Component Serial Serial Serial Quantity Quantity Quantity Name Name Name seat Body Drive wheel Windshields Gear box Assm Rear wheel cover Steering wheel Non-drive Wheel Charger Manual Washer M8 Nut Rear wheel alignment tube...
- Page 4 1:Install the gasket on both sides of the front wheel shaft, and then install a non driving wheel on both sides of the front wheel shaft. 2:Install a gasket on both sides of the non drive wheel, then lock the nut and fix it with an M8 wrench.
- Page 5 1.First, insert the connecting line, then insert the wind bracket into the corresponding holes of the vehicle body with force, so that the wind bracket and the vehicle body are buckled.(as shown in the figure) 1.Insert the steering wheel firmly into the corresponding hole of the instrument panel to make the steering wheel and the instrument panel snap together.（as shown in the figure）...
- Page 6 1.open the seat. Plug in the battery cable and drive motor cable（red to red. White to white） 1Clip the seat buckle into the corresponding body buckle hole. Then fix the seat with screws. 2.Open the engine cover and clip the 2 No.5 batteries into the battery box of the alarm light.
- Page 7 Steering wheel drive pedal horn Foot switch Instrument cluster functions 前进 后退 power switch Forward / backward switch Alarm light switch...
- Page 8 The charging hole is located in the front of the seat. Insert the Q head of the charger into the charging hole. Insert the other end into the socket...
- Page 9 WARNING: For your baby to drive safely, you must pay attention to the following warnings： The assembly and adjustment of the product must be carried out by adults. Please keep children away from moving parts Small parts inside Children must use the product under the guidance of adults, and the carer must not leave during use! Do not get close to the fire Do not allow children to stand or play on the footboard (or electric vehicle) The battery must be charged by adults before using this product...
-
Page 10: Precautions For Use
PRECAUTIONS FOR USE When using the electric vehicle for the first time, the battery must be charged for 18 hours, otherwise the battery will be permanently damaged and cannot be repaired Before use, please check whether all parts are installed in place and connected firmly Do not use in dangerous areas such as streets, roads, slopes, ditches, etc Do not use on smooth ground such as marble tile Do not switch the forward / reverse switch while the electric vehicle is running.
