Corbin Russwin CL3800 Series Quick Start Manual

Installation Instructions
Grade 2 Key-In-Lever
Cylindrical Lockset
CL3800 Series
IMPORTANT: The accuracy of the door preparation is critical for the proper functioning and security of this lever
handle lock. Misalignment can cause premature wear and a lessening of security.
*
Standard Installation for 1-3/4" doors.
See page 2 to adjust for other door thicknesses.
A
B
In U.S.: Corbin Russwin, Inc.
225 Episcopal Road
Berlin, CT 06037-4004
www.corbin-russwin.com
Technical Product Support:
Phone: 888-607-5703
Fax: 800-659-7293
In Canada: Assa Abloy DSS Canada
160 Four Valley Drive
Vaughun, ONT L4K 4TG
www.yalecorbin.on.ca
Lever Release
P A T E N T E D L E V E R D E S I G N
PATENT NO.
4920773
BH MA
C E R T I F I E D
TEST OPERATION: Rotate levers to see that latchbolt moves freely.
DO NOT FORCE.
If lockset does not operate properly, remove lockset from door and check door preparation.
(1)
Attention Installer
Please read these instructions carefully to prevent
missing important steps.
Please note: Improper installation may result in
damage to the lock and void the factory warranty.
FM 249
A
Install Latchbolt
B
Install Lockbody
C
Install Inside Trim
4
5
C
5
6
12/06 617417644
1
2
3
6
7
7
