IN120 WiFi
Installation Instructions
ED5200(S)N & ED5600N Series Exit Devices
(Includes: Rim & Mortise)
Please read these instructions carefully to prevent missing important steps.
Please Note: Improper installations may result in damage to the lock and void the factory warranty.
Important: The accuracy of the door preparation is critical for proper functioning and security of this lock.
Misalignment can cause premature wear and a lessening of security.
For Technical Assistance call Corbin Russwin at 1-800-810-WIRE (9473)
Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
Attention Installer
FM432 10/18
WARNING
This product can expose
you to lead which is
known to the state of
California to cause cancer
and birth defects or other
reproductive harm. For
more information go to
www.P65warnings.ca.gov.
08/2018
Advertisement
Related Manuals for Corbin Russwin ED5200N Series
Summary of Contents for Corbin Russwin ED5200N Series
- Page 1 08/2018 For Technical Assistance call Corbin Russwin at 1-800-810-WIRE (9473) Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
-
Page 2: Table Of Contents
To comply with “Fire Listed” doors, the batteries must be replaced with alkaline batteries only. Observe precautions for handling electrostatic sensitive devices. Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the... -
Page 3: General Description
Exit Devices For 9100/9M100 IN120 Series Trim 2) General Description The Corbin Russwin IN120 pairs a sleek, attractive design with the latest in access control technology to address the evolving needs of today’s facilities. Featuring HID multiCLASS SE technology, this innovative WiFi lock ®... -
Page 4: Product Illustration
*Specifying B indicates BLE (Bluetooth) option when ordering **Specify finish Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited. -
Page 5: Rim Exit Installation Instructions
Hole Holes Backplate Mount Holes Through-bolt Holes Fig. 2 Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited. - Page 6 Fig. 3 Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
- Page 7 Cam must be postitioned as shown when cylinder tailpiece is assembled Fig. 4b Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
- Page 8 Position Switch Tighten securely Tailpiece Fig. 5d Fig. 5c Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
- Page 9 Harness Adapter Fig. 6 *Not used in typical installation Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
- Page 10 Fig. 7a Important Note: Rim Exit Installation Continues on Page 15 - Section 7 Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
-
Page 11: Mortise Exit Installation Instructions
Position Switch Through-bolt Holes Trim Tailpiece Hole Fig. 9 Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited. - Page 12 Fig. 10 Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
- Page 13 Fasten trim assembly to door using (2) 1/4-20 oval head screws and (2) finish washers (Fig. 11b). Note: Finger tighten only. Fig. 11a Fig. 11b Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
- Page 14 Door Position Switch Tighten securely Fig. 12b Fig. 12a Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
- Page 15 Harness Adapter Fig. 13 *Not used in typical installation Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
- Page 16 Fig. 14a Mortise Exit Installation Continues on Next Page - Section 7 Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
-
Page 17: In120 Installation Instructions
Outside Face of Door Fig. 15a Reader Assembly with Harness Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited. - Page 18 (Fig. 15b). Once cables/connectors are fed through, reattach gasket to mounting plate. Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
- Page 19 D. Secure the 24-pin card reader connector (Fig. 16d). Reader (24-pin) Fig. 16b Board-to-Board Fig. 16d Connector Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
- Page 20 Fig. 17b Tabs click in here Fig. 17a Fig. 17c Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
- Page 21 Secure cover utilizing security allen wrench. Security Allen Screw Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
-
Page 22: Operational Check
Do not wave credential. Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited. - Page 23 ED5200N & ED5600N Series Exit Devices For 9100/9M100 IN120 Series Trim Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
- Page 24 Copyright © 2018 Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.
