Summary of Contents for Hyundai 2007 Tiburon

  • Page 1 2007...
  • Page 2: Warranties For Your Hyundai Vehicle

    A020A01A-AAT RESPONSIBILITY FOR MAINTENANCE The maintenance requirements for your new Hyundai are found in Section 5. As the owner, it is your responsibility to see that all maintenance operations specified by the manufacturer are carried out at the appropriate intervals.
  • Page 3 All information in this Owner's Manual is current at the time of publication. However, Hyundai reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all Hyundai models and includes descriptions and explanations of optional as well as standard equipment.
  • Page 4 Your Hyundai should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your Hyundai and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations established by the U.S. Department of Transportation and other federal or state agencies.
  • Page 5 A090A01A-AAT SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as WARNING, CAUTION and NOTE. These titles indicate the following: WARNING: This indicates that a condition may result in harm, serious injury or death to you or other persons if the warning is not heeded.
  • Page 6: Vehicle Data Collection And Event Data Recorders

    To retrieve this information, special equipment is needed and access to the vehicle or the device that stores the data is required. Hyundai will not access information about a crash event or share it with others except:...
  • Page 7 Your Owner's Manual will introduce you to the features and operation of your new Hyundai. It is suggested that you read it carefully because the information it contains can contribute greatly to the satisfaction you receive from your new car.
  • Page 8 Hyundai Warranty. 3. How can you tell if you are purchasing Hyundai Genuine Parts? Look for the Hyundai Genuine Parts Logo on the package (see below). Hyundai Genuine Parts exported to the United States are packaged with labels written only in English.
  • Page 9: Table Of Contents

    TABLE OF CONTENTS FEATURES OF YOUR HYUNDAI DRIVING YOUR HYUNDAI WHAT TO DO IN AN EMERGENCY CORROSION PREVENTION & APPEARANCE CARE VEHICLE MAINTENANCE REQUIREMENTS SECTION DO-IT-YOURSELF MAINTENANCE EMISSION CONTROL SYSTEMS CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS...
  • Page 10: Instruments And Controls

    INSTRUMENTS AND CONTROLS B250A02GK-AAT OGK026002N...
  • Page 11 1. Multi-Function Light Switch 2. Horn and Driver's Airbag 3. Windshield Wiper/Washer Switch 4. Ignition Switch 5. Front Fog Light Switch (If installed) 6. Digital Clock 7. Hazard Warning Switch 8. Outside Temperature Switch 9. Passenger's Air Bag Off Indicator 10.
  • Page 12: Indicator Symbols On The Instrument Panel

    YOUR VEHICLE AT A GLANCE B255A02GK-AAT INDICATOR SYMBOLS ON THE INSTRUMENT PANEL Turn Signal Indicator Lights ABS Service Reminder Indicator (SRI) (If installed) High Beam Indicator Light Low Oil Pressure Warning Light Parking Brake/ Low Brake Fluid Level Warning Light Charging System Warning Light Door Ajar Warning Light and Chime Low Fuel Level Warning Light...
  • Page 13: Features Of Your Hyundai

    FEATURES OF YOUR HYUNDAI Fuel Recommendations ... 1-2 Breaking in Your New Hyundai ... 1-3 Keys ... 1-3 Door (Theft-Alarm System) ... 1-4, 1-6 Power Windows ... 1-9 Seats ... 1-10 Seat Belts... 1-16 Child Restraint System ... 1-22 Supplemental Restraint (AIRBAG) System (SRS) ... 1-30 Instrument Cluster and Indicator Lights ...
  • Page 14: Fuel Recommendations

    B010D01A-AAT Do Not Use Methanol Fuels containing methanol (wood alcohol) should not be used in your Hyundai. This type of fuel can reduce vehicle performance and damage components of the fuel system. CAUTION: Your Hyundai's New Vehicle Limited War-...
  • Page 15: Gasolines For Cleaner Air

    Emission Control System. B010F01A-AAT Operation in Foreign Countries If you are going to drive your Hyundai in another country, be sure to: o Observe all regulations regarding registra- tion and insurance.
  • Page 16: Door (Theft-Alarm System)

    Record Your Key Number B030B01MC A code number is stamped on the key number plate that came with the keys to your Hyundai. This key number plate should be kept in a safe place, not in the vehicle. The key number should also be recorded in a place where it can be found in an emergency.
  • Page 17 To reduce the chance of theft, always remove the ignition key, close all win- dows, and lock all doors when leaving your vehicle unattended. FEATURES OF YOUR HYUNDAI B040D01S-AAT Locking From the Inside UNLOCK LOCK...
  • Page 18: Theft-Alarm System

    FEATURES OF YOUR HYUNDAI B040G02GK-GAT Central Door Lock OGK046003 The central door locking is operated by pushing the driver's door lock switch toward the front or rear of the vehicle. If the passenger door is open when the switch is pushed, the door will remain locked when closed.
  • Page 19 27 seconds. (This hap- pens 3 times). To turn off the system, unlock the door with the transmitter. CAUTION: Avoid trying to start the engine while the system is armed. FEATURES OF YOUR HYUNDAI B070D05GK-AAT Disarmed Stage UNLOCK LOCK OGK016102...
  • Page 20 When the transmitter does not work cor- rectly, open and close the door with the ignition key. If you have a problem with the transmitter, contact an authorized Hyundai Dealer. NOTE: Keep the transmitter away from water or any liquid.
  • Page 21: Power Windows

    1) Turn the ignition key to the "ACC" posi- tion. 2) Make sure that the turn signal lamps blink once by pushing the "LOCK" or "UNLOCK" button on the transmitter. FEATURES OF YOUR HYUNDAI POWER WINDOW B050A02GK-AAT HGK2015 The power windows operate only when the ignition key is in the "ON"...
  • Page 22: Seats

    FEATURES OF YOUR HYUNDAI To stop at the desired opening, pull up and release the switch. In order to prevent operation of the passenger front window by the passen- ger, a window lock switch (2) is provided on the arm rest of the driver's door. To disable the passenger's power window, push the window lock switch.
  • Page 23 Sud- den or unexpected movement of the driver's seat could cause you to lose control of the vehicle resulting in an accident. FEATURES OF YOUR HYUNDAI B080C02A-AAT Adjusting Seatback Angle OGK036003 To recline the seatback, lean forward to take your weight off it, then pull up on the recliner control lever at the outside edge of the seat.
  • Page 24 FEATURES OF YOUR HYUNDAI WARNING: Riding with a reclined seatback increases your chance of serious or fatal injuries in the event of a collision or sudden stop. The protection of your restraint system (seat belts and airbags) is greatly reduced by reclining your seat.
  • Page 25: Rear Seat Entry (Walk In Device)

    (Driver's Seat Only) (If Installed) OGK036004 To raise or lower the front part of the seat cushion, turn the knob forward or rearward. FEATURES OF YOUR HYUNDAI B130A02GK-AAT Rear Seat Entry (Walk in device) The driver and front passenger's seatbacks should be tilted to enter the rear seat.
  • Page 26: Before Folding The Rear Seats

    FEATURES OF YOUR HYUNDAI OGK036008 By pulling up the walk in device lever (1) at the right-upper side of the passenger side seatback, the seatback will tilt forward. Then push the seat forward to allow the occupants to enter. Recliner Memory...
  • Page 27 When you return the seatback to its upright position, always be sure it has locked into position by pulling and pushing on the top of the seatback. FEATURES OF YOUR HYUNDAI WARNING: The purpose of the fold-down rear seatbacks is to allow you to carry longer objects than could otherwise be accommo- dated.
  • Page 28: Seat Belts

    FEATURES OF YOUR HYUNDAI B140A01S-AAT REAR SEAT WARNING OGK016140 For the safety of all passengers, luggage or other cargo should not be piled higher than the top of the seatback. In addition, do not place objects on the rear shelf as they may move forward during braking or in an accident and strike vehicle passengers.
  • Page 29: Larger Children

    13 in the front seat. NEVER place a rear facing child seat in the front seat of a vehicle. FEATURES OF YOUR HYUNDAI B150D01A-AAT Pregnant Women The use of a seat belt is recommended for pregnant women to lessen the chance of injury in an accident.
  • Page 30: Care Of Seat Belts

    Entire in-use seat belt assembly or assemblies should be replaced if the vehicle has been involved in an accident. This should be done even if no damage is visible. Additional ques- tions concerning seat belt operation should be directed to your Hyundai Dealer.
  • Page 31 Replace your seat belts after being in an accident as soon as possible. FEATURES OF YOUR HYUNDAI B180A01L-AAT SEAT BELT-Driver's 3-Point System with Emergency Locking Retractor: To Fasten Your Belt...
  • Page 32 Combination retractor type seat belts are in- stalled in the rear seat positions to help accom- modate the installation of child restraint sys- tems. Hyundai strongly recommends that chil- dren always be seated in the rear seat. NEVER place any infant restraint system in the front seat of the vehicle.
  • Page 33 Rather, one should be over and the other under, as shown in the illustration. Never wear the seat belt under the arm nearest the door. FEATURES OF YOUR HYUNDAI B210A01A-AAT To Release the Seat Belt B210A01NF The seat belt is released by pressing the re- lease button in the locking buckle.
  • Page 34: Child Restraint System

    FEATURES OF YOUR HYUNDAI CHILD RESTRAINT SYSTEM B230A03A-AAT Children riding in the car should sit in the rear seat and must always be properly restrained to minimize the risk of injury in an accident, sudden stop or sudden maneuver. According to acci-...
  • Page 35 Your vehicle is provided with two child restraint hook holders for insta lling the child seat or infant seat. FEATURES OF YOUR HYUNDAI B230C06F-AAT Installing a Child Restraint Seat with the "Tether Anchorage" System Two child restraint hook holders are located on the luggage compartment floor.
  • Page 36 FEATURES OF YOUR HYUNDAI Rear luggage compartment floor Blanking covers Covering shelf Child Restraint Hook Holders Tether strap hook Front of Vehicle B230E01GK 3. Remove the blanking covers on the cover- ing shelf. 4. Connect the tether strap hook to the child restraint hook holder through the hole on the covering shelf and tighten to secure the seat.
  • Page 37 FEATURES OF YOUR HYUNDAI o When using the vehicle’s “ISOFIX” sys- tem to install a child restraint system in the rear seat, all unused vehicle rear seat...
  • Page 38 FEATURES OF YOUR HYUNDAI ISOFIX Anchor ISOFIX Anchor Position Indicator B230D02GK The ISOFIX anchors are located between the seatback and the seat cushion of the rear seat left and right outboard seating positions. HGK261 Follow the child seat manufacturer's instruc- tions to properly install child restraint seats with ISOFIX or ISOFIX-compatible attachments.
  • Page 39 If the seat belt does not operate as de- scribed, have the system checked imme- diately by your authorized Hyundai dealer. FEATURES OF YOUR HYUNDAI WARNING: o If the retractor is not in the Automatic...
  • Page 40 FEATURES OF YOUR HYUNDAI B180B05GK-AAT Pre-tensioner Seat Belt (If Installed) Your Hyundai vehicle is equipped with driver's and front passenger's pre-tensioner seat belts. The purpose of the pre-tensioner is to make sure that the seat belts fit tightly against the occupant's body in certain frontal collisions.
  • Page 41 Do not attempt to inspect or replace the pre-tensioner seat belts yourself. This must be done by an authorized Hyundai dealer. o Do not strike the pre-tensioner seat belt assemblies.
  • Page 42: Supplemental Restraint (Airbag) System (Srs)

    FEATURES OF YOUR HYUNDAI SUPPLEMENTAL RESTRAINT (AIRBAG) SYSTEM B240D01GK-GAT (If Installed) 1. Driver's front airbag 2. Passenger's front airbag 3. Front side impact airbag OGK036022...
  • Page 43: Driver's And Passenger's Front Air Bag

    B240A02GK-AAT Driver's and Passenger's Front Airbag Driver's Front Airbag OGK016240 Your Hyundai is equipped with an advanced Supplemental Restraint (Airbag) System. The indications of the system's presence are the letters "SRS AIRBAG" embossed on the airbag pad cover in the steering wheel and the passenger's side front panel pad above the glove box.
  • Page 44 6 seconds when the igni- tion key is turned to the "ON" position, or if it illuminates while the vehicle is being driven, have an authorized Hyundai dealer inspect the advanced SRS airbag system as soon as possible.
  • Page 45 If the SRS airbag warning light (see page 1-49) remains illuminated while the ve- hicle is being driven, have an authorized Hyundai dealer inspect the airbag sys- tem as soon as possible. o Airbags can only be used once – have an authorized Hyundai dealer replace the airbag immediately after deployment.
  • Page 46 If the airbags deploy, they must be re- placed by an authorized Hyundai dealer. Deployed airbags WILL NOT inflate again and will provide no protection in subse- quent collisions.
  • Page 47: Srs Components And Functions

    9. Driver's and Front Passenger's Seat Belt Buckle Sensors 10. Side Impact Sensor (If Installed) 11. Retractor Pre-tensioner Assemblies FEATURES OF YOUR HYUNDAI 12. Side Impact Airbag Module (If Installed) 13. Front Impact Sensor The SRSCM continually monitors all elements while the ignition is "ON"...
  • Page 48 FEATURES OF YOUR HYUNDAI The airbag modules are located both in the center of the steering wheel and in the front passenger's panel above the glove box. When the SRSCM detects a sufficiently severe impact to the front of the vehicle, it will automatically deploy the front airbags.
  • Page 49 SRS is not working properly. If this oc- curs, have your vehicle immediately in- spected by your Hyundai dealer. o Before you replace a fuse or disconnect a battery terminal, turn the ignition key to the "LOCK" position or remove the ignition key.
  • Page 50 FEATURES OF YOUR HYUNDAI If the front passenger seat is occupied by a person that the system determines to be of adult size, and he/she sits properly (sitting upright with the seatback in an upright position, cen- tered on the seat cushion with their seat belt on, legs comfortably extended and their feet on the floor), the "PASSENGER AIR BAG OFF"...
  • Page 51 Never sit with hips shifted towards the front of the seat. 1KMN3662 Never excessively recline the front passen- ger seatback. FEATURES OF YOUR HYUNDAI 1KMN3665 Never place feet on the dashboard. 1KMN3664 Never lean on the center console. Never sit on one side of the front passenger...
  • Page 52 FEATURES OF YOUR HYUNDAI Proper position B990A01O When an adult is seated in the front passenger seat, if the "PASSENGER AIR BAG OFF" indi- cator is on, turn the ignition key to "LOCK" and ask the passenger to sit properly (sitting upright...
  • Page 53 6 seconds when the ignition key is turned to the "ON" position, or if it illuminates while the vehicle is being driven, have an authorized Hyundai dealer inspect the occupant classification system and the SRS air bag system as soon as possible.
  • Page 54 OFF" indicator. B990B02MC-AAT Side Impact Airbag B990B02Y Your Hyundai is equipped with a side impact airbag in each front seat. The purpose of the airbag is to provide the vehicle's driver and/or the front passenger with additional protection than that offered by the seat belt alone. The side...
  • Page 55: Srs Care

    Any work on the SRS system, such as remov- ing, installing, repairing, or any work on the steering wheel must be performed by a qualified Hyundai technician. Improper handling of the airbag system may result in serious personal injury. FEATURES OF YOUR HYUNDAI...
  • Page 56 WARNING: o If your car was flooded and has soaked carpeting or water on the floor, you shouldn't try to start the engine; have the car towed to an authorized Hyundai dealer. B240D02JM-AAT Additional Safety Precautions o Never let passengers ride in the cargo area (trunk) or on top of a folded-down back seat.
  • Page 57: Adding Equipment To Or Modifying Your Airbag-Equipped Vehicle

    Adding Equipment to or Modifying Your Airbag-Equipped Vehicle. If you modify your vehicle by changing your vehicle's frame, bumper system, front end or side sheet metal or ride height, this may affect the operation of your vehicle's airbag system. FEATURES OF YOUR HYUNDAI...
  • Page 58: Instrument Cluster And Indicator Lights

    FEATURES OF YOUR HYUNDAI INSTRUMENT CLUSTER AND INDICATOR LIGHTS B260A03GK-AAT OGK046028N...
  • Page 59 21. Trip Computer Reset Knob (If installed) 22. CRUISE Indicator Light (If installed) 23. CRUISE SET Indicator Light (If installed) 24. Tail Gate Open Warning Light 25. Door Ajar Warning Light 26. ABS Service Reminder Indicator (SRI) FEATURES OF YOUR HYUNDAI...
  • Page 60: Warning And Indicator Lights

    "ON" position, but should go out after approximately three seconds. If the ESC or ESC-OFF indicator stays on, take your car to your authorized Hyundai dealer and have the system checked. See section 2 for more infor- mation about the ESC.
  • Page 61: Charging System Warning Light

    Do this as shown on page 6-19 by pushing down on the center of the belt. Have the system checked by your Hyundai dealer as soon as possible. B260B01JM-AAT SRS (Airbag) Warning Light The SRS service reminder indicator (SRI) comes on for about 6 seconds after the ignition key is turned to the "ON"...
  • Page 62 In any instance where the oil light stays on when the engine is running, the engine should be checked by a Hyundai dealer before the car is driven again. B260N02A-AAT Malfunction Indicator...
  • Page 63: Door Ajar Warning Light And Chime

    After adding fluid, if no other trouble is found, the car should be immediately and care- fully driven to a Hyundai dealer for inspection. If further trouble is experienced, the vehicle should not be driven at all but taken to a dealer by a professional towing service.
  • Page 64: Instrument Cluster

    ABS. If this occurs, have your vehicle checked by your Hyundai dealer as soon as possible. The normal braking system will still be operational, but without the assistance of the anti-lock brake system.
  • Page 65: Engine Coolant Temperature Gauge

    Then open the hood and after the engine has cooled, check the coolant level and the water pump drive belt. If you suspect cooling system trouble, have your cooling system checked by a Hyundai dealer as soon as possible. FEATURES OF YOUR HYUNDAI B300A01A-AAT Speedometer...
  • Page 66 FEATURES OF YOUR HYUNDAI B330A03E-AAT Tachometer OGK016265 The tachometer registers the speed of your engine in revolutions per minute (rpm). CAUTION: The engine should not be raced to such a speed that the needle enters the red zone on the tachometer face. This can cause severe engine damage and may void your warranty.
  • Page 67: Trip Computer

    LCD. FEATURES OF YOUR HYUNDAI Reset Switch o The reset switch is used to zero the multi- functional display mode.
  • Page 68 FEATURES OF YOUR HYUNDAI Type A Type B OGK016401N 1. Distance to Empty o This mode provides the estimated distance to empty from the current fuel level in the fuel tank. o The trip computer may not register additional fuel if less than 1.36 gallons (6 liters) of fuel are added to the vehicle.
  • Page 69: Multi Gauge

    B330C01GK Torque gauge It shows instantaneous change of the torque by rpm. FEATURES OF YOUR HYUNDAI B330C04GK Instantaneous fuel Consumption gauge It shows instantaneous fuel consumption ac- cording to driving conditions. The more indi- cated figure is low, the more it indicates efficient...
  • Page 70: Multi-Function Light Switch

    Check for a burned- out fuse or bulb or see your Hyundai dealer. B340B01A-AAT Lane Change Signal...
  • Page 71: Headlight Switch

    To turn on the headlight high beams, push the lever forward (away from you). The high beam indicator light will come on at the same time. For low beams, pull the lever back toward you. FEATURES OF YOUR HYUNDAI B340G02LZ-GAT Auto Light (If installed) OGK026223N To operate the automatic light feature, turn the barrel on the end of the multi-function switch.
  • Page 72: Windshield Wiper/Washer Switch

    FEATURES OF YOUR HYUNDAI Auto Light Sensor OGK026223C NOTE: o Never place anything over the sensor located on the instrument panel, to en- sure better auto light system control. o Don't clean the sensor using a window cleaner. o If your vehicle has window tint or other...
  • Page 73 Mist Wiper Operation OGK047049N If a single wipe is desired in mist, move the windshield wiper and washer control lever up. FEATURES OF YOUR HYUNDAI B350C01S-AAT Adjustable Intermittent Wiper Operation OGK047050N To use the intermittent wiper feature, place the wiper switch in the "INT"...
  • Page 74: Front Fog Light Switch

    FEATURES OF YOUR HYUNDAI B390A01E-AAT Rear Window Wiper And Washer Switch OGK047051N : The rear window wiper starts to oper- ate three times after the washer fluid sprays onto the rear window. 2.OFF 3.INT : The interval between wipes operates every 5 seconds intermittently.
  • Page 75: Hazard Warning System

    20 min- utes. To restart the defroster cycle, push in the switch again after it has turned itself off. FEATURES OF YOUR HYUNDAI CAUTION: Do not clean the inner side of the rear window glass with an abrasive type of glass...
  • Page 76: Digital Clock

    Do not hold the cigarette lighter pressed in. This can damage the heating element and create a fire hazard. If it is necessary to replace the cigarette lighter, use only a genuine Hyundai replacement or its approved equivalent. CAUTION: Do not use electric accessories or equip- ment other than the Hyundai genuine parts in the socket.
  • Page 77: Drink Holder

    The drink holder is used for holding cups or cans. To use the passenger's drink holder, push the drink holder. FEATURES OF YOUR HYUNDAI WARNING: o Use caution when using the drink hold- ers. A spilled beverage that is very hot can injure you or your passengers.
  • Page 78: Sunroof

    FEATURES OF YOUR HYUNDAI SUNSHADE B470A01GK-AAT (If Installed) OGK046019 The sunshade can be opened and closed by sliding it forward or rearward when the sunroof is closed. The sunshade will open automatically when the sunroof is opened, but it must be closed manually.
  • Page 79 Do not press any sunroof control button longer than necessary. Damage to the motor or system compo- nents could occur. FEATURES OF YOUR HYUNDAI B460D03GK-AAT Manual Operation of Sunroof If the sunroof does not electrically operate: OGK046020 1.
  • Page 80: Interior Light

    FEATURES OF YOUR HYUNDAI OGK046021 2. Insert the hexagonal head wrench provided with the vehicle into the socket. This wrench can be found in the vehicle’s trunk or glove box. 3. Push and turn the wrench clockwise to close or counterclockwise to open the sunroof.
  • Page 81: Sunglass Holder

    To open the glove box, pull on the glove box release lever. FEATURES OF YOUR HYUNDAI B500B01NF-GAT Illuminated Glove Box Opening the glove box will automatically turn on the light when the multi-function switch is turned to the first position.
  • Page 82: Outside Rearview Mirror

    FEATURES OF YOUR HYUNDAI OUTSIDE REAR VIEW MIRROR B510B02A-AAT Electric Type OGK046026L The outside rearview mirrors can be adjusted to your preferred rear vision, both directly be- hind the vehicle, and to the rear of the left and right sides.
  • Page 83: Day/Night Inside Rear View Mirror

    MIRROR B520A01A-AAT Manual Type OGK046024 Your Hyundai is equipped with a day/night inside rear view mirror. The "night" position is selected by flipping the tab at the bottom of the mirror toward you. In the "night" position, the glare of headlights of cars behind you is reduced.
  • Page 84: High-Mounted Rear Stop Light

    FEATURES OF YOUR HYUNDAI PARKING BRAKE B530A03A-AAT OGK056005 Always engage the parking brake before leav- ing the car. This also turns on the parking brake indicator light when the key is in the "ON" or "START" position. Before driving away, be sure that the parking brake is fully released and the indicator light is off.
  • Page 85: Front Door Edge Warning Light

    HOOD RELEASE B570A01GK-GAT Hood Release Lever OGK046011L 1. Pull the release knob to unlatch the hood. FEATURES OF YOUR HYUNDAI OGK046012L 2. Press the safety hook lever up and lift the hood. 3. Raise the hood by hand.
  • Page 86 If the filler cap must be replaced, only use genuine Hyundai re- placement parts. o After refueling, make sure the fuel cap is installed securely to prevent fuel spill- age in the event of an accident.
  • Page 87 If you must use your cellular phone use it in a place away from the gas station. FEATURES OF YOUR HYUNDAI WARNING: When refueling always shut the en- gine off. Sparks produced by electri- cal components related to the engine can ignite fuel vapors causing a fire.
  • Page 88: Tail Gate

    FEATURES OF YOUR HYUNDAI TAIL GATE B540A01F-AAT Remote Tail Gate Release OGK046005 To open the tail gate without using the key, pull up the lid release lever located on the driver's door panel. To close, lower the tail gate, then press down on it until it locks.
  • Page 89: Sun Visor

    B580A01GK-AAT Vanity mirror HGK2119 Your Hyundai is equipped with sun visors to give the driver and front passenger either frontal or sideward shade. To reduce glare or to shut out direct rays of the sun, turn the sun visor down.
  • Page 90: Steering Wheel Tilt Lever

    FEATURES OF YOUR HYUNDAI WARNING: Do not place the sun visor in such a manner that it obscures visibility of the roadway, traffic or other objects. B580C01JM-AAT Sun Visor Extender (If Installed) B580C01GK Your vehicle is equipped with sun visor extend- ers that may be used when the visor is in the side glass position.
  • Page 91: Luggage Net

    To prevent damage to the goods or the vehicle, care should be taken when carrying fragile or bulky objects in the luggage com- partment. FEATURES OF YOUR HYUNDAI WARNING: Avoid eye injury. Do not overstretch. Al- ways keep face and body out of recoil path.
  • Page 92: Cruise Control

    FEATURES OF YOUR HYUNDAI WARNING: o Make sure the floor mat is properly placed on the floor carpet. If the floor mat slips and interferes with the movement of the pedals during driving, it may cause an accident. o Don't put an additional floor mat on the...
  • Page 93 9 mph (15 km/h). o Decrease the vehicle speed to less than 25 mph (40 km/h). o Release the main switch. FEATURES OF YOUR HYUNDAI B660D01E-AAT To Resume the Preset Speed OGK016663 The vehicle will automatically resume the speed set prior to cancellation when you push the control switch upward to "RESUME (ACCEL)"...
  • Page 94 FEATURES OF YOUR HYUNDAI B660E01E-AAT To Reset at a Faster Speed 1. Push the control switch upward to "RE- SUME (ACCEL)" position and hold it. 2. Accelerate to desired speed and release the control switch. While the control switch is held, the vehicle will gradually gain speed.
  • Page 95: Audio Remote Control Switch

    ) switch once to skip forward to the beginning of the next track. VOL ( ) Switch o Press the VOL ( ) button to increase volume. o Press the VOL ( ) button to decrease volume. FEATURES OF YOUR HYUNDAI...
  • Page 96: Heating And Cooling Control

    FEATURES OF YOUR HYUNDAI HEATING AND COOLING CONTROL B710A02GK-GAT 1. Side Defrost Nozzle 2. Side Ventilator 3. Windshield Defrost Nozzle 4. Center Ventilator B710B02O-AAT Center Ventilator The center ventilators are located in the middle of the dashboard. To change the direction of the air flow, move the knob in the center of the vent up-and-down and side-to-side.
  • Page 97: Heating And Ventilation

    This blower fan speed, and therefore the vol- ume of air delivered from the system, may be controlled manually by setting the blower con- trol between the "1" and "4" positions. FEATURES OF YOUR HYUNDAI B670E02A-AAT Temperature Control Cool Warm...
  • Page 98 FEATURES OF YOUR HYUNDAI B670C02Y-AAT Air Intake Control OGK046044 This is used to select fresh outside air or recirculation of inside air. Fresh Recirculation With the " " mode selected, air enters the vehicle from outside and is heated or cooled according to the other functions selected.
  • Page 99: Floor-Level

    Air is discharged through the face vents and the floor vents. This makes it possible to have cooler air from the dashboard vents and warmer air from the floor outlets at the same time. FEATURES OF YOUR HYUNDAI OGK016097 Floor-Level Air is discharged through the floor vents, wind- shield defroster nozzle, side defroster nozzle and side ventilator.
  • Page 100 FEATURES OF YOUR HYUNDAI OGK016098 Floor-Defrost Level Air is discharged through the windshield defrost nozzle, the floor vents, side defroster nozzle, side ventilator. If the "Floor-Defrost" mode is selected, the A/C will be turn on automatically and "Fresh" mode will be activated.
  • Page 101: Heating Controls

    NOTE: If the air flow control is off, the air intake control is set to the fresh mode automati- cally. FEATURES OF YOUR HYUNDAI HEATING CONTROLS B690A02S-AAT OGK046038A For normal heating operation, set the air intake control to the fresh air (...
  • Page 102: Bi-Level Heating

    FEATURES OF YOUR HYUNDAI BI-LEVEL HEATING B700A02A-AAT OGK016700N Your Hyundai is equipped with bi-level heating controls. This makes it possible to have cooler air from the dashboard vents and warmer air from the floor outlets at the same time. To use...
  • Page 103 For greater cooling, turn the fan control to one of the higher speeds or temporarily select the recirculate ( ) position on the air intake control switch. FEATURES OF YOUR HYUNDAI B740C01GKA-AAT Dehumidified Heating OGK016705N For dehumidified heating: o Adjust the air flow control to the desired position.
  • Page 104: Operation Tips

    FEATURES OF YOUR HYUNDAI B740D01A-AAT Operation Tips o If the interior of the car is hot when you first get in, open the windows for a few minutes to expel the hot air. o When you are using the air conditioning system, keep all windows closed to keep hot air out.
  • Page 105 ) position. (The o Set the temperature control to warm. o Set the fan speed control to position "3" or "4". ) or defrost level ( FEATURES OF YOUR HYUNDAI B Type OGK016801N ) position. (The ), it may cause fog to form...
  • Page 106: Automatic Heating And Cooling Control System

    FEATURES OF YOUR HYUNDAI AUTOMATIC HEATING AND COOLING CONTROL SYSTEM B970A01Y-AAT (If lnstalled) Your Hyundai is equipped with an automatic heating and cooling control system controlled by simply setting the desired temperature. B970B03GK-GAT Heating and Cooling Controls 1. Temperature Control 2.
  • Page 107 32°C(90°F) by turning the knob clock- wise. The temperature will decrease to the mini- mum 17°C(62°F) by turning the knob coun- terclockwise. FEATURES OF YOUR HYUNDAI NOTE: If the battery has been discharged or dis- connected, the temperature mode will reset to Centigrade degrees.
  • Page 108: Manual Operation

    FEATURES OF YOUR HYUNDAI Photo Sensor OGK026223C NOTE: Never place anything over the sensor which is located on the instrument panel to en- sure better control of the heating and cool- ing system. B995A01GK-GAT Outside Temperature Switch OGK046066 Press the button, the display show that the unit of outside temperature is adjusted to centigrade or fahrenheit (°C →...
  • Page 109: Fan Speed Control Switch

    FRESH MODE ( ) : The indicator light on the button goes on when the air intake control is in fresh mode. FEATURES OF YOUR HYUNDAI OGK046062L RECIRCULATION MODE ( ) : The indica- tor light on the button is illuminated when the air intake control is in recirculation mode.
  • Page 110 FEATURES OF YOUR HYUNDAI NOTE: It should be noted that prolonged opera- tion of the heating system in "recirculation" mode will give rise to fogging of the wind- shield and side windows and the air within the passenger compartment will become stale.
  • Page 111 OGK046065 The air conditioning is turned on or off by pushing the A/C button on the heating/air con- ditioning control panel. FEATURES OF YOUR HYUNDAI B980D01Y-AAT Heating and Cooling System Off OGK046067 Press the "OFF" button to stop the operation of...
  • Page 112: Air Flow Control

    FEATURES OF YOUR HYUNDAI B980E01GK-GAT Air Flow Control OGK046059 This is used to direct the flow of air. Air can be directed to the floor, instrument panel outlets, or windshield. Four symbols are used to represent Face, Bi-Level, Floor and Floor-Defrost position.
  • Page 113: Defrost Switch

    FEATURES OF YOUR HYUNDAI B980F01GK-AAT Defrost Switch OGK046060 When the "Defrost" button is pressed, the "...
  • Page 114: Climate Control Air Filter

    FEATURES OF YOUR HYUNDAI B980G02NF-GAT Auto de-humidified control (If Installed) There is a humidity sensor in the middle of the instrument panel pad. If it becomes very humid inside the car, the air conditioning is turned on automatically to control the humidity.
  • Page 115: Stereo Sound System

    These long, low frequency radio waves can follow the curvature of the earth rather than travelling straight out into the atmosphere. In addition, they curve around obstructions so that they can provide better signal coverage. FEATURES OF YOUR HYUNDAI FM radio station Mountains Unobstructed area...
  • Page 116 WARNING: Hyundai recommends that you never use a cell phone while driving. This could result in loss of control, and an accident that may cause death, serious injury, or property damage.
  • Page 117: Antenna

    AM and FM broadcast signals through the antenna in the rear window glass. FEATURES OF YOUR HYUNDAI CAUTION: o Do not clean the inner side of the rear window glass with an abrasive type of...
  • Page 118: Audio System

    FEATURES OF YOUR HYUNDAI AUDIO SYSTEM H280A01GK-GAT Stereo Radio Operation (H280) (If Installed) 1, 2 1. 2. Power Button and Volume Control 3. Radio Band Selection Button 4. SCAN Button 5. Automatic Channel Selection Button 6. Preset Button 7. Information Display Screen (LCD) 8.
  • Page 119 BASS ➟ MIDDLE ➟ TREBLE ➟ FADER ➟ BALANCE and the mode will be displayed on the screen. FEATURES OF YOUR HYUNDAI Turn the TUNE Controller BASS clockwise to increase bass tone and counterclockwise to decrease.
  • Page 120 FEATURES OF YOUR HYUNDAI 9. Manual Channel Selection Control (TUNE) Turn this controller while listening to the radio to manually adjust frequency. Turn clockwise to increase frequency and counterclockwise to reduce frequency. 10. EQ Button Each time you press this button the sound equalizer setting will switch from POP ➟...
  • Page 121 H280C01GK-GAT Cassette Tape Player Operation (H280) (If Installed) GK_280_NA FEATURES OF YOUR HYUNDAI 1. TAPE MODE Selection Button / TAPE Side Selection Button 2. Cassette Tape Deck 3. Tape Eject Button 4. DOLBY Selection Button 5. Fast Rewind 6. Fast Forward 7.
  • Page 122 FEATURES OF YOUR HYUNDAI H280D01GK-GAT 1. TAPE MODE Selection Button / TAPE Side Selection Button Press this button to turn to the TAPE mode. The system will play the tape if the tape is inside the deck and turn off CD or radio if either mode was If you press this button while the tape is being played, the other side of the tape will be played.
  • Page 123 H280E01GK-GAT Compact Disc Player Operation (H280) (If installed) GK_280_NA FEATURES OF YOUR HYUNDAI 1. CD Deck 2. CD Indicator 3. CD EJECT Button 4. CD Selection Button 5. Fast Backward 6. Fast Forward 7. Automatic Previous Track Selection Button 8. Automatic Next Track Selection Button 9.
  • Page 124 FEATURES OF YOUR HYUNDAI H280F01GK-GAT 1. CD Deck Make sure the printed side of the disk faces upward when you insert the disk. If you insert the disk when the ignition switch of the automo- bile is set to ACC (1st notch) or ON (2nd notch), the CD Deck will automatically play CD even if the power was off.
  • Page 125: Scroll Button

    Avoid using recorded compact discs in your audio unit. Original compact discs are recommended. FEATURES OF YOUR HYUNDAI NOTE: When you use CD-R or CD-RW, the CD may not be played due to the manufacturing method of CD makers and the recording method of the user.
  • Page 126 FEATURES OF YOUR HYUNDAI H265A01GK-GAT Stereo Radio Operation (H265) (If installed) 1. Power Button and Volume Control (Power On / Volume) 2. Radio Band Selection Button 3. Automatic Channel Selection Button(SEEK) 4. Manual Channel Selection Control (TUNE) 5. Preset Button 6.
  • Page 127 When you release the button, the system will turn to the automatic selection mode. FEATURES OF YOUR HYUNDAI 5. Preset Button (1~6) Press this button but do not hold for no more than 2 seconds to listen to the channels memorized to each button.
  • Page 128 FEATURES OF YOUR HYUNDAI 8. AUDIO Select Button o Press this button to change AUDIO function control mode. Current State➟BASS➟MID➟TRE➟ FAD➟BAL o Select the audio control mode you want and increase or decrease the setting by ±10 from currently audio control mode. If no actions are taken, the screen will return to the pre- vious display after 3 seconds.
  • Page 129 H265C01GK-GAT Compact Disc Player Operation (H265) (If installed) GK_265_NA FEATURES OF YOUR HYUNDAI 1. CD DECK 2. CD INDICATOR 3. CD Disc EJECT Button 4. CD Selection Button 5. Fast Backward 6. Fast Forward 7. Automatic Previous Track Selection Button 8.
  • Page 130 FEATURES OF YOUR HYUNDAI H265D01GK-GAT 1. CD Deck Make sure the printed side of the disk faces upward when you insert the disk. If you insert the disk when the ignition switch of the automo- bile is set to ACC (1st notch) or ON (2nd notch), the CD DECK will automatically play CD even if the power was off.
  • Page 131 Do not attempt to grab or pull the com- pact disc out while the disc is being pulled into the audio unit by the self- loading mechanism. Damage to the audio unit and compact disc could oc- cur. FEATURES OF YOUR HYUNDAI...
  • Page 132 FEATURES OF YOUR HYUNDAI H465A01GK-GAT Stereo Radio Operation (H465) (If Installed) 1, 2 1. 2. Power Button and Volume Control 3. Radio Band Selection Button 4. SCAN Button 5. Automatic Channel Selection Button 6. Manual Channel Selection Control (TUNE Control) 7.
  • Page 133 1.5 seconds then the channel will be memorized to the button with a beep. FEATURES OF YOUR HYUNDAI 8. Information Display Screen (LCD) A variety of information will be displayed on the screen including the radio bands (FM1/FM2/...
  • Page 134 FEATURES OF YOUR HYUNDAI Turn the TUNE Controller BALANCE clockwise to increase right speaker volume and coun- terclockwise to increase left speaker volume. Turn the TUNE Controller FADER clockwise to increase rear speaker volume and coun- terclockwise to increase front speaker volume.
  • Page 135 H465C01GK-GAT Compact Disc Player Operation (H465) (If installed) GK_465_NA FEATURES OF YOUR HYUNDAI 1. CD Deck 2. CD Load Button 3. CD Eject Button 4. Information Display Screen (LCD) 5. CD Changer Selection Button 6. Disc Selection Button 7. Fast Backward 8.
  • Page 136 FEATURES OF YOUR HYUNDAI H465D01GK-GAT 1.CD Deck The deck will open only when you press [LOAD] button. Make sure the printed side of the disk faces upward when you insert the disk. The CD changer can only play 12cm disks. If you insert video CD or DATA CD, then the screen will display "ERROR DISC,"...
  • Page 137: Bookmark Button

    5 seconds after you select a track then the system will automatically return to the cur- rent track. FEATURES OF YOUR HYUNDAI CAUTION: o Do not insert warped or poor quality discs into the CD player as damage to the unit may occur.
  • Page 138: Care Of Discs

    FEATURES OF YOUR HYUNDAI CARE OF DISCS B850A02F-AAT Proper Handling B850A01L Handle your disc as shown. Do not drop the disc. Hold the disc so you will not leave finger- prints on the surface. If the surface is scratched, it may cause the pickup to skip signal tracks. Do not affix tape, paper, or gummed labels on the disc.
  • Page 139 Head Cotton applicator B860A02L FEATURES OF YOUR HYUNDAI o The playback head, capstan and pinch roll- ers will develop a coating of tape residue that can result in deterioration of sound quality, such as a wavering sound.
  • Page 140 FEATURES OF YOUR HYUNDAI B860A03L NOTE: Look at a tape before you insert it. If the tape is loose, tighten it by turning one of the hubs with a pencil or your finger. If the label is peeling off, do not put it in the drive mechanism.
  • Page 141 DRIVING YOUR HYUNDAI Engine Exhaust Can Be Dangerous! ... 2-2 Before Starting the Engine ... 2-3 Key Positions ... 2-4 Starting ... 2-5 Operating the Manual Transaxle ... 2-6 Automatic Transaxle ... 2-8 Anti-Lock Brake System (ABS) ... 2-12 Electronic Stability Control (ESC) ... 2-13 Good Braking Practices ...
  • Page 142: Driving Your Hyundai

    Hyundai dealer. o Do not run the engine in an enclosed area.
  • Page 143: Before Starting The Engine

    DRIVING YOUR HYUNDAI TO START THE ENGINE C030A01A-AAT Combination Ignition Switch o If your Hyundai is equipped with a manual transaxle, place the shift lever in neutral and depress the clutch pedal fully. o If your Hyundai has an automatic transaxle, place the shift lever in "P"...
  • Page 144: Key Positions

    DRIVING YOUR HYUNDAI KEY POSITIONS C040A02A-AAT WARNING: The engine should not be turned off or the key removed from the ignition key cylinder while the vehicle is in motion. The steering wheel is locked by removing the key. LOCK START C040A01E-1 o "START"...
  • Page 145: Starting

    DRIVING YOUR HYUNDAI 4. Turn the ignition key to the "Start" position and release it when the engine starts. After the engine has started, allow the engine to run for 10 to 20 seconds prior to placing the vehicle in gear.
  • Page 146: Operating The Manual Transaxle

    C070A03GK-AAT Type A Type B HGK3023 Your Hyundai's manual transaxle has a con- ventional shift pattern. This shift pattern is im- printed on the shift knob. The transaxle is fully synchronized in all forward gears so shifting to either a higher or a lower gear is easily accom- plished.
  • Page 147: Using The Clutch

    DRIVING YOUR HYUNDAI WARNING: o Always buckle-up! In a collision, an unbelted occupant is significantly more likely to be seriously injured or killed than a properly belted occupant.
  • Page 148: Automatic Transaxle

    60 mph (95 km/h) AUTOMATIC TRANSAXLE C090A03Y-AAT HGK3025 The highly efficient Hyundai automatic transaxle has four forward speeds and one reverse speed. The individual speeds are selected au- tomatically, depending on the position of the speed selector lever. The selector lever has 2 gates;...
  • Page 149: Sports Mode

    C090E01O-AAT o D(Drive): Use for normal driving. The transaxle will auto- matically shift through a four gear sequence. DRIVING YOUR HYUNDAI C090F02GK-GAT Sports Mode HGK3027 Whether the vehicle is stationary or in motion, sports mode is selected by pushing the selector lever from the "D"...
  • Page 150 DRIVING YOUR HYUNDAI CAUTION: o In sports mode, the driver must execute shifts in accordance with prevailing road conditions, taking care to keep the en- gine speed below the red zone. o For engine protection, upward shifts are made automatically when the engine rpm reaches the red zone.
  • Page 151 Instead, slow down before pulling back into the travel lanes. o Never exceed posted speed limits. DRIVING YOUR HYUNDAI WARNING: If your vehicle becomes stuck in snow, mud, sand, etc., then you may attempt to rock the vehicle free by moving it forward and backward.
  • Page 152: Anti-Lock Brake System (Abs)

    DRIVING YOUR HYUNDAI ANTI-LOCK BRAKE SYSTEM (ABS) C120A03A-AAT (If installed) The Anti-Lock Brake System (ABS) is designed to prevent wheel lock-up during sudden braking or on hazardous road surfaces. The ABS con- trol module monitors the wheel speed and con- trols the pressure applied to each brake.
  • Page 153 Electronic stability control is only a driving aid; all normal precautions for driving in inclement weather and on slippery road surfaces should be observed. DRIVING YOUR HYUNDAI C310B01JM-AAT ESC ON/OFF Mode When the ESC is operating, the ESC indicator in the instrument cluster will blink.
  • Page 154: Good Braking Practices

    Hyundai dealer for assistance. o Don’t coast down hills with the car out of gear. This is extremely hazardous. Keep the car...
  • Page 155: Driving For Economy

    (see Section 5 for details). o Keep your car clean. For maximum service, your Hyundai should be kept clean and free of corrosive materials. It is especially impor- tant that mud, dirt, ice, etc. not be allowed to accumulate on the underside of the car.
  • Page 156: Smooth Cornering

    DRIVING YOUR HYUNDAI o Don't "lug" or "over-rev" the engine. Lugging is driving too slowly in too high a gear result- ing in the engine bucking. If this happens, shift to a lower gear. Over-revving is racing the engine beyond its safe limit. This can be avoided by shifting at the recommended speeds.
  • Page 157 Visually inspect the battery and cables as described in Section 6 (See page 6-19). The level of charge in your battery can be checked by your Hyundai dealer or a service station. C160E01A-AAT Change to "Winter Weight" Oil if Neces-...
  • Page 158 DRIVING YOUR HYUNDAI C160J01A-AAT Don’t Let Ice and Snow Accumulate Underneath Under some conditions, snow and ice can build up under the fenders and interfere with the steering. When driving in severe winter condi- tions where this may happen, you should peri-...
  • Page 159: Trailer Or Vehicle Towing

    Since laws vary from State to State, the require- ments for towing trailers, cars, other types of vehicles, or apparatus may differ. Ask your Hyundai dealer for further details before towing. CAUTION: Do not do any towing with your car during its first 1,200 miles (2,000 km) in order to allow the engine to properly break in.
  • Page 160 DRIVING YOUR HYUNDAI CAUTION: o Never connect a trailer brake system directly to the vehicle brake system. o When towing a trailer on steep grades (in excess of 6%) pay close attention to the engine coolant temperature gauge to ensure the engine does not overheat. If...
  • Page 161 Turn your front wheel into the curb, set the parking brake firmly, and put the transaxle in 1st or Reverse (manual) or Park DRIVING YOUR HYUNDAI (automatic). In addition, place wheel chocks at each of the trailer's tires. 9. If the trailer has electric brakes, start your...
  • Page 162: Vehicle Load Limit

    DRIVING YOUR HYUNDAI CAUTION: If overheating should occur when towing, (the temperature gauge reads near red zone), taking the following action may reduce or eliminate the problem. 1. Turn off the air conditioner. 2. Reduce highway speed. 3. Select a lower gear when going uphill.
  • Page 163 (2)Determine the combined weight of the driver and passengers that will be riding in your vehicle. DRIVING YOUR HYUNDAI (3)Subtract the combined weight of the driver and passengers from XXX kilograms or XXX pounds. (4)The resulting figure equals the avail- able amount of cargo and luggage load capacity.
  • Page 164 DRIVING YOUR HYUNDAI Example 1 C190F01JM Item Description Total 1400 lbs Vehicle Capacity Weight (635 kg) Subtract Occupant Weight 300 lbs 150 lbs (68 kg) × 2 (136 kg) Available Cargo and 1100 lbs Luggage weight (498 kg) Example 2...
  • Page 165 Weight Rating). The GVWR in- cludes the weight of the vehicle, all occupants, fuel and cargo. DRIVING YOUR HYUNDAI This label also tells you the maximum weights that can be supported by the front and rear axles, called Gross Axle Weight Rating (GAWR).
  • Page 166 DRIVING YOUR HYUNDAI WARNING: o Do not load your vehicle any heavier than the GVWR, either the maximum front or rear GAWR and vehicle capacity weight. If you do, parts, including tires on your ve- hicle can break, and it can change the way your vehicle handles and braking ability.
  • Page 167 Do not leave an unsecured child restraint in your vehicle. o When you carry something inside the vehicle, secure it. o Do not drive with a seat folded down unless necessary. DRIVING YOUR HYUNDAI...
  • Page 168 WHAT TO DO IN AN EMERGENCY If the Engine will not Start ... 3-2 Jump Starting ... 3-3 If the Engine Overheats ... 3-4 Tire Pressure Monitoring System (TPMS) ... 3-5 Spare Tire ... 3-9 If You Have a Flat Tire ... 3-11 Changing a Flat Tire ...
  • Page 169: What To Do In An Emergency

    1. Reduce your speed gradually, keeping a straight line. Move cautiously off the road to a safe place. 2. Turn on your emergency flashers. 3. Try to start the engine again. If your vehicle will not start, contact a Hyundai dealer or seek other qualified assistance.
  • Page 170: Jump Starting

    JUMP STARTING D020A03A-AAT 2.0L Dis- charged battery Booster battery HGK4001 Dis- 2.7L charged battery Booster battery HGK4002 WARNING: The gas produced by the battery during the jump-start operation is highly explosive. If these instructions are not followed exactly, serious personal injury and damage to the vehicle may occur! If you are not sure how to follow this procedure, seek qualified assistance.
  • Page 171: If The Engine Overheats

    5. If the water pump drive belt is broken or engine coolant is leaking out, stop the engine immediately and call the nearest Hyundai dealer for assistance. WARNING: Do not remove the radiator cap when the engine is hot.
  • Page 172: Tire Pressure Monitoring System (Tpms)

    (Page 6-8) to bring the fluid level in the reservoir up to the halfway mark. 7. Proceed with caution, keeping alert for fur- ther signs of overheating. If overheating happens again, call a Hyundai dealer for assistance. CAUTION: Serious loss of engine coolant indicates...
  • Page 173 WHAT TO DO IN AN EMERGENCY Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operat- ing properly. The TPMS malfunction indicator is provided by a separate tell- tale, which displays the symbol "TPMS" when illuminated.
  • Page 174 TPMS malfunction indicator. Have the system checked by an autho- rized Hyundai dealer as soon as pos- sible to determine the cause of the problem. NOTE:...
  • Page 175 TPMS malfunction indi- cators are not extinguished after about 20 minutes of continuous driving, please visit an authorized Hyundai dealer. You may not be able to identify a low tire by simply looking at it. Always use a good quality tire pressure gauge to measure the tire's inflation pressure.
  • Page 176: Spare Tire

    This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any inter- ference received, including interfer- ence that may cause undesired op- eration.
  • Page 177 WHAT TO DO IN AN EMERGENCY WARNING: The temporary spare tire is for emer- gency use only. Do not operate your vehicle on this temporary spare at speeds over 50 mph (80 kmh). The original tire should be repaired or replaced as soon as is possible to avoid failure of the spare possibly leading to personal injury or death.
  • Page 178: If You Have A Flat Tire

    IF YOU HAVE A FLAT TIRE D050A01A-AAT If a tire goes flat while you are driving: 1. Take your foot off the accelerator pedal and let the car slow down while driving straight ahead. Do not apply the brakes immediately or attempt to pull off the road as this may cause a loss of control.
  • Page 179 WHAT TO DO IN AN EMERGENCY HGK4009 The jack is located behind the right side luggage trim. Remove the jack cover by unscrewing the bolts. Turn the jack end counterclockwise to lower the jack height by using a screw driver or wrench bar and remove it from the bracket.
  • Page 180 D060E01A-AAT 4. Put the Jack in Place OGK036401 The base of the jack should be placed on firm, level ground. The jack should be positioned as shown in the drawing. D060F02E-AAT 5. Raising the Car Wrench bar Wheel nut wrench D060F01MC After inserting a bar into the wheel nut wrench, install the bar into the jack as...
  • Page 181 WHAT TO DO IN AN EMERGENCY D060G02Y-AAT 6. Changing Wheels OGK036403 Loosen the wheel nuts and remove them with your fingers. Slide the wheel off the studs and lay it flat so it cannot roll away. To put the wheel on the hub, pick up the spare tire, line up the holes with the studs and slide the wheel onto them.
  • Page 182 ameter ends directed inward. Jiggle the tire to be sure it is completely seated, then tighten the nuts as much as pos- sible with your fingers again. D060I01E-AAT 8. Lower Vehicle and Tighten Nuts HGK4014 Lower the car to the ground by turning the wheel nut wrench counterclock- wise.
  • Page 183: If Your Vehicle Must Be Towed

    TOWED D080A01O-GAT If your vehicle has to be towed, it should be done by your Hyundai dealer or a commercial tow truck service. This will help assure that your vehicle is not damaged in towing. Also, profes- sionals are generally aware of local laws gov- erning towing.
  • Page 184 CAUTION: o When towing the vehicle, take care not to cause damage to the bumper or under- body of the vehicle. HGK4016 o Do not tow with sling type truck as this may cause damage to the bumper or underbody of the vehicle. 1) If the vehicle is being towed with the rear wheels on the ground, be sure the parking brake is released.
  • Page 185: Emergency Towing

    IF YOU LOSE YOUR KEYS D120A01A-AAT If you lose your keys, many Hyundai dealers can make you a new key if you have your key number. If you lock the keys inside your car and you cannot obtain a new key, many Hyundai dealers can use special tools to open the door for you.
  • Page 186: Corrosion Prevention & Appearance Care

    CORROSION PREVENTION & APPEARANCE CARE Corrosion Protection ... 4-2 To Help Prevent Corrosion ... 4-2 Washing and Waxing ... 4-3 Cleaning the Interior ... 4-5...
  • Page 187: Corrosion Protection

    Corrosion By using the most advanced design and con- struction practices to combat corrosion, Hyundai produces cars of the highest quality, However, this is only part of the job. To achieve the long-term corrosion resistance your Hyundai can deliver, the owner’s cooperation and assistance is also required.
  • Page 188: Keep Your Garage Dry

    Use a good quality car-washing solu- tion and follow the manufacturer's directions on the package. These are available at your Hyundai dealer or auto parts outlet. Don't use strong household detergents, gasoline, strong solvents or abrasive cleaning powders as these may damage the finish.
  • Page 189: Spot Cleaning

    To protect the paintwork of the car against corrosion, you must clean your Hyundai (at least once a month). Give special attention to the removal of salt, mud and other sub- stances on the underside of the splashboards of the car.
  • Page 190: Cleaning The Interior

    Maintaining Bumpers Special precautions must be observed to pre- serve the appearance of the bumpers on your Hyundai. They are: o Be careful not to spill battery electrolyte or hydraulic brake fluid on the bumpers. If you do, wash it off immediately with clear water.
  • Page 191: Any Questions

    However, when cleaning the in- side of the rear window be careful not to damage the rear window defroster wiring. ANY QUESTIONS? E050A01A-AAT If you have any questions about the care of your car, consult your Hyundai dealer.
  • Page 192 VEHICLE MAINTENANCE REQUIREMENTS Maintenance Intervals ... 5-2 Scheduled Maintenance ... 5-4 Maintenance under Severe Usage Conditions ... 5-6 Explanation of Scheduled Maintenance Items ... 5-7...
  • Page 193: Vehicle Maintenance Requirements

    F010D01A-AAT General Checks These are the regular checks you should per- form when you drive your Hyundai or you fill the fuel tank. A list of these items will be found on page 6-4. F010E01A-AAT Do-It-Yourself Maintenance...
  • Page 194: Scheduled Maintenance

    Hyundai dealer. o If you choose to do your own maintenance and repairs, you may find it helpful to have an official Hyundai Shop Manual. A copy of this publication may be purchased at your Hyundai dealer's parts department. SCHEDULED MAINTENANCE...
  • Page 195: Scheduled Maintenance

    VEHICLE MAINTENANCE REQUIREMENTS SCHEDULED MAINTENANCE F030A01A-AAT The following maintenance services must be performed to ensure good emission control and performance. Keep receipts for all vehicle emission services to protect your emission warranty. Where both mileage and time are shown, the frequency of service is determined by whichever occurs first. F030B04GK-AAT R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary.
  • Page 196 F030C02GK-AAT R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MILES X 1000 DESCRIPTION KILOMETERS X 1000 MONTHS GENERAL ITEMS DRIVE BELT (WATER PUMP, GENERATOR AND A/CON) COOLANT TIMING BELT MANUAL TRANSAXLE OIL AUTOMATIC TRANSAXLE FLUID BRAKE FLUID &...
  • Page 197: Maintenance Under Severe Usage Conditions

    VEHICLE MAINTENANCE REQUIREMENTS MAINTENANCE UNDER SEVERE USAGE CONDITIONS F040A04GK-AAT The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MAINTENANCE ITEM ENGINE OIL AND FILTER TIMING BELT...
  • Page 198: Explanation Of Scheduled Maintenance Items

    F060H01A-AAT o Air cleaner filter A Genuine Hyundai air cleaner filter is recom- mended when the filter is replaced. F060J01A-AAT o Spark plugs Make sure to install new spark plugs of the correct heat range.
  • Page 199 Use HYUNDAI GENUINE ATF SP III, DIAMOND ATF SP III, SK ATF SP III or other brands meeting the SP III specification approved by Hyundai Motor Co.
  • Page 200 F070J01A-AAT o Brake Pads, Calipers and Rotors Check the pads for excessive wear, discs for run out and wear, and calipers for fluid leakage. F070K01A-AAT o Exhaust Pipe and Muffler Visually inspect the exhaust pipes, muffler and hangers for cracks, deterioration, or damage. Start the engine and listen carefully for any exhaust gas leakage.
  • Page 201: Do-It-Yourself Maintenance

    Do-It-Yourself Maintenance Engine Compartment ... 6-2 General Checks ... 6-4 Checking the Engine Oil ... 6-5 Checking and Changing the Engine Coolant ... 6-7 Changing the Air Cleaner Filter ... 6-9 Windshield Wiper Blades ... 6-9 Checking the Transaxle Oil (manual) ... 6-11 Checking the Transaxle Fluid (Automatic) ...
  • Page 202: Engine Compartment

    DO-IT-YOURSELF MAINTENANCE ENGINE COMPARTMENT G010B01GK-GAT (2.0 DOHC CVVT) 1. Engine oil filler cap 2. Brake booster 3. Brake fluid reservoir 4. Clutch fluid reservoir (If installed) 5. Relay box 6. Windshield washer fluid reservoir cap 7. Power steering fluid reservoir 8.
  • Page 203 G010C01GK-GAT (2.7 V6) 1. Power steering fluid reservoir 2. Brake booster 3. Brake fluid reservoir 4. Air Cleaner 5. Relay box 6. Windshield washer fluid reservoir cap 7. Engine coolant reservoir 8. Engine oil level dipstick 9. Radiator cap DO-IT-YOURSELF MAINTENANCE CAUTION: When inspecting or servicing the engine, you should handle tools and other heavy...
  • Page 204: General Checks

    Seat control condition and operation o Seat belt condition and operation o Sunvisor operation If you notice anything that does not operate correctly or appears to be functioning incor- rectly, inspect it carefully and seek assistance from your Hyundai dealer if service is needed.
  • Page 205: Checking The Engine Oil

    CHECKING THE ENGINE OIL G030A01A-AAT Engine oil is essential to the performance and service of the engine. It is suggested that you check the oil level at least once a week in normal use and more often if you are on a trip or driving in severe conditions.
  • Page 206: Proposition 65 Warning

    NOTE: o It is recommended that the engine oil and filter should be changed by an au- thorized Hyundai dealer. o Always dispose of used engine oil in an environmentally acceptable manner. It is suggested that it be placed in a sealed container and taken to a service station for reclaimation.
  • Page 207: Checking And Changing The Engine Coolant

    "L" mark, add engine coolant to bring it up between "L" and "F". If the level is low, inspect for coolant leaks and recheck the fluid level frequently. If the level drops again, visit your Hyundai dealer for an inspection and diagnosis of the reason.
  • Page 208 DO-IT-YOURSELF MAINTENANCE G050D03A-AAT To Change the Engine Coolant The engine coolant should be changed at those intervals specified in the vehicle maintenance schedule in Section 5. CAUTION: Engine coolant can damage the finish of your car. If you spill engine coolant on the car, wash it off thoroughly with clean water.
  • Page 209: Changing The Air Cleaner Filter

    To change the filter, unsnap the clips around the cover. When this is done, the cover can be lifted off, the old filter removed and the new filter put in its place. Genuine Hyundai Replacement Parts are recommended. CAUTION: o Operating your vehicle without a proper air filter in place can result in excessive engine wear.
  • Page 210 DO-IT-YOURSELF MAINTENANCE o When the wiper blades are frozen in winter weather or the washer fluid reser- voir is empty, the wipers may not operate for ten minutes. This isn't a mechanical trouble but the function protecting the wiper by operat- ing circuit breaker inside of the wiper motor.
  • Page 211: Filling The Washer Reservoir

    FILLING THE WASHER RESERVOIR G090A03A-AAT HGK5014 The washer fluid reservoir supplies fluid to the windshield washer system. A good quality washer fluid should be used to fill the washer reservoir. The fluid level should be checked more frequently during inclement weather or whenever the washer system is in more frequent use.
  • Page 212: Checking The Transaxle Fluid (Automatic)

    MOND ATF SP III, SK ATF SP III or other brands meeting the SP III specification ap- proved by Hyundai Motor Co. If you are having your vehicle serviced at a facility other than a Hyundai dealer, verify ATF is used for your vehicle.
  • Page 213: Checking The Automatic Transaxle Fluid Level

    G110D01GK-AAT Checking the automatic transaxle fluid level 2.0L 2.7L HGK5007 The automatic transaxle fluid level should be checked regularly. Keep the vehicle on level ground with the park- ing brake applied and check the fluid level according to the following procedure. 1.
  • Page 214: Checking The Brakes

    Because brakes are essential to the safe operation of the car, it is suggested that they be checked and inspected by your Hyundai dealer. The brakes should be checked and inspected for wear at those intervals specified in the vehicle mainte- nance schedule in Section 5.
  • Page 215: Checking The Clutch Fluid

    "MAX" and "MIN" level markings on the fluid reservoir. Fill as required. Fluid loss indicates a leak in the clutch system which should be inspected and repaired imme- diately. Consult your Hyundai dealer. DO-IT-YOURSELF MAINTENANCE G130B02A-AAT To Replace the Fluid Recommended brake fluid conforming to DOT 3 or DOT 4 specification should be used.
  • Page 216: Air Conditioning Care

    2. If the air coming out of the in-dash vents is not cold, have the air conditioning system inspected by your Hyundai dealer. CAUTION: Running the air conditioning system for extended periods of time with a low refrig- erant level may damage the compressor.
  • Page 217 OGK076021 2. Open the glove box and remove the mount- ing screws on the upside of the glove box. HGK2114 3. Remove the filter cover. DO-IT-YOURSELF MAINTENANCE HGK2115 4. Replace the climate control air filter with a new one. 5. Installation is the reverse order of disassem- bly.
  • Page 218: Checking And Replacing Fuses

    If this ever happens, have a Hyundai dealer determine the cause, repair the system and replace the fusible link. The fusible links are located in a relay box(2.0L )or below the positive (+) post cover of the battery (2.7L) for easy inspection.
  • Page 219: Checking The Battery

    The fuse should be a snug fit. If it is not, have the fuse clip repaired or replaced by a Hyundai dealer. If you do not have a spare fuse, you may be...
  • Page 220 DO-IT-YOURSELF MAINTENANCE o If battery fluid is on your skin, flush the affected areas with water for at least 15 minutes and then seek medical assistance. o If battery fluid is in your eyes, rinse out your eyes with water and get medical assistance as soon as possible.
  • Page 221: Checking Electric Cooling Fans

    WARNING: If electrolyte gets on your skin, thoroughly wash the contacted area. If you feel a pain or a burning sensation, get medical attention immediately. Wear eye protection when charg- ing or working near a battery. Always provide ventilation when working in an enclosed space.
  • Page 222: Power Steering Hoses

    G250A01A-AAT If you desire additional information about main- taining and servicing your Hyundai, you may purchase a factory Shop Manual at your Hyundai dealer's parts department. This is the same manual used by dealership technicians and while it is highly technical it can be useful in obtaining a better understanding of your car and how it works.
  • Page 223: Specification

    VERTICAL AIMING. WARNING: Never attempt to adjust the horizontal align- ment of your headlights. Horizontal aiming must be adjusted by an authorized Hyundai dealer to avoid incorrect alignment that will reduce the effectiveness of your headlights. G290B02GK-AAT Adjustment After Headlight Assembly...
  • Page 224: Replacement Of Light Bulbs

    If you don't have necessary tools, the correct bulbs and the expertise, consult your authorized Hyundai dealer. G270A01GK-AAT Headlight and Front Turn Signal Light 1. Allow the bulb to cool. Wear eye protection.
  • Page 225 OGK076049 7. Push the bulb spring to remove the headlight bulb. OGK076050 8. Remove the protective cap from the re- placement bulb and install the new bulb by matching the plastic base with the headlight hole. Reattach the bulb spring and recon- nect the connector.
  • Page 226 Keep the bulb out of the reach of children and dispose of the used bulb with care. G270K01CM-GAT Front Fog Light (If Installed) NOTE: It is recommended that the front fog light bulb be replaced by an authorized Hyundai dealer. G270B02GK-GAT Rear Combination Light (Without woofer speaker) OGK076037...
  • Page 227 OGK076040 2. To remove the cover of the rear luggage trim, turn the knobs by hand to the counterclock- wise. OGK076041 3. Remove the nut (8mm) with a socket wrench. DO-IT-YOURSELF MAINTENANCE OGK076042 4. To detach the rear combination light tap it strongly with your hand.
  • Page 228 DO-IT-YOURSELF MAINTENANCE G275B02GK-GAT Rear Combination Light (With woofer speaker) OGK076037 1. Open the tail gate. HGK5038 2. Take off the luggage board. OGK076039 3. Extract the mounting screws (10mm) around the woofer speaker with a socket wrench. 4. Disconnect the power cord from the woofer speaker.
  • Page 229 OGK076040 5. To remove the cover of the rear luggae trim, turn the knob by hand to the counterclock- wise. OGK076041 6. Remove the nut (8mm) with a socket wrench. OGK076042 7. To detach the rear combination light tap it strongly with your hand.
  • Page 230: Map Light

    DO-IT-YOURSELF MAINTENANCE G270C01GK-AAT Luggage Compartment Light OGK076035 1. Open the tail gate. 2. Remove the cover with a flat-blade screw- driver. HGK5046 3. Disconnect the power cord. OGK076032 4. Replace with a new bulb. G270G01GK-AAT Map Light OGK076046 1. Remove the cover with a flat-blade screw- driver.
  • Page 231 G270H01GK-GAT Glove Box Illuminated Light OGK076020 1. Remove the mounting screws on the down- side of the glove box. OGK076021 2. Open the glove box and remove the mount- ing screws on the upside of the glove box. DO-IT-YOURSELF MAINTENANCE OGK076022 3.
  • Page 232 4. Disconnect the power cord. 5. Remove the glove box illuminated light by pushing the clip. 6. Replace with a new bulb. G270E02A-GAT Side Repeater (If Installed) NOTE: It is recommended that the side repeater bulb be replaced by an authorized Hyundai dealer.
  • Page 233: Bulb Wattage

    BULB WATTAGE G280A04GK-AAT Part Name Head Light (Low) Front Position Light Map Light Front Turn Signal Light Front Fog Light (If installed) Head Light (High) Front Side Marker Light Side Repeater Front Door Edge Warning Light Wattage Socket type Part Name PGJ 19-2 Luggage Compartment Light BAY15d...
  • Page 234: Fuse Panel Description

    DO-IT-YOURSELF MAINTENANCE FUSE PANEL DESCRIPTION G200C01GK-GAT Engine Compartment If installed HGK4005 NOTE: Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse box on your vehicle, refer to the fuse box label.
  • Page 235: Protected Components

    DESCRIPTION FUSERATING Generator(2.0L) BATT 120A BCM BOX(Tail lamp relay,Power connector,Fuse(2,7,12,13,19,20,24) BATT COND Condenser fan relay Radiator fan relay Engine control relay, Fuel pump relay, A/T control relay, Generator, PCM(2.0L) Ignition switch,Start relay ABS 1 ABS/ESC control module,ESC Air bleeding connector ABS 2 ABS/ESC control module,ESC Air bleeding connector Blower relay...
  • Page 236: Inner Panel

    DO-IT-YOURSELF MAINTENANCE G200D02GK-GAT Inner Panel OGK066010L...
  • Page 237 DESCRIPTION FUSERATING Ignition coil(2.7L), Electronic chrome mirror IG COIL B/UP LAMP Back-up lamp switch,Transaxle range switch,Cruise control module,Cluster R postion A/BAG IND Instrument cluster (A/BAG IND.) A/BAG SRS control module, S/Buckle DRV, ASS HTD MIR Mirror defogger Hazard relay HAZARD R/WIPER Rear wiper motor,Rear intermittent wiper relay TAIL-RH...
  • Page 238: Emission Control Systems

    EMISSION CONTROL SYSTEMS Emission Control System ... 7-2 Catalytic Converter ... 7-3...
  • Page 239: Emission Control System

    In order to ensure the proper function of the emission control systems, it is recommended that you have your car inspected and main- tained by an authorized Hyundai dealer in ac- cordance with the maintenance schedule in this manual. Caution for the Inspection and Maintenance...
  • Page 240: Catalytic Converter

    EMISSION CONTROL SYSTEMS o Remember that your Hyundai dealer is your best source of assistance. o Do not stop your Hyundai over any com- bustible material such as grass, paper, leaves or rags. These materials might contact the hot catalytic converter and a...
  • Page 241: Consumer Information, Reporting Safety Defects

    Tire Balancing ... 8-11 Tire Traction ... 8-11 When to Replace Tires ... 8-12 Spare Tire and Tools ... 8-13 Warranties for Your Hyundai Vehicle ... 8-13 Consumer Information ... 8-13 Reporting Safety Defects ... 8-17 Binding Arbitration of Warranty Claims ... 8-17...
  • Page 242: Vehicle Identification Number (Vin)

    TIRES I020A02A-AAT Tire Information The tires supplied on your new Hyundai are chosen to provide the best perfor- mance for normal driving. If you ever have questions about your tire warranty and where to obtain ser-...
  • Page 243 I030A03JM-AAT Recommended Cold Tire Inflation Pressures HGK6003 Tire label located on the driver's side of the center pillar outer panel gives the cold tire pressures recommended for your vehicle with the original tire size, the number of people that can be in your vehicle and vehicle capacity weight.
  • Page 244 Replace tires that are worn, show uneven wear, or are damaged. o Remember to check the pressure of your spare tire. Hyundai recom- mends that you check the spare every time you check the pressure of the other tires on your vehicle.
  • Page 245: Tire Sidewall Labeling

    I035A01JM-AAT Checking Tire Inflation Pressure Check your tires once a month or more. Also, check the tire pressure of the spare tire. How to Check Use a good quality gage to check tire pressure. You can not tell if your tires are properly inflated simply by looking at them.
  • Page 246: Index

    CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS 1. Manufacturer or Brand name o Manufacturer or Brand name is shown. 2. Tire size (example: P215/45R17 87V) o The "P" indicates the tire is de- signed for passenger vehicles. A "T"...
  • Page 247: Tire Terminology And Definitions

    6. Maximum load rating This number indicates the maximum load in kilograms and pounds that can be carried by the tire. When replacing the tires on the vehicle, always use a tire that has the same load rating as the factory installed tire.
  • Page 248: Maximum Loaded Vehicle Weight

    CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS Intended Outboard Sidewall: The side of an asymmetrical tire, that must al- ways face outward when mounted on a vehicle. Kilopascal (kPa): The metric unit for air pressure. Load Index: An assigned number rang- ing from 1 to 279 that corresponds to the load carrying capacity of a tire.
  • Page 249: Snow Tires

    CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS I040B01JM-AAT All Season Tires Hyundai specifies all season tires on some models to provide good perfor- mance for use all year round, including snowy and icy road conditions. All sea-...
  • Page 250: Tire Chains

    CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS I050A04GK-AAT Tire Chains Tire chains, if necessary, should be installed on the front wheels. Be sure that the chains are installed in accor- dance with the manufacturer's instruc- tions. Refer to the following informa- tion.
  • Page 251: Tire Balancing

    (10,000 km). If you notice that tires are wearing unevenly between ro- tations, have the car checked by a Hyundai dealer so the cause may be corrected. After rotating, adjust the tire pressures and be sure to check wheel nut torque.
  • Page 252: When To Replace Tires

    Wheels that do not meet Hyundai's specifications may fit poorly and result in damage to the vehicle or unusual handling and poor ve- hicle control.
  • Page 253: Spare Tire And Tools

    Refer to this page for further infor- mation and tread limits. SPARE TIRE AND TOOLS I100A02Y-AAT HGK4008 Your Hyundai is delivered with the fol- lowing: Spare tire and wheel Wheel nut wrench, Wrench bar Jack...
  • Page 254: Warranties For Your Hyundai Vehicle

    CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS I110A01A-AAT Shop Manual A Hyundai Shop Manual is available from your authorized Hyundai dealer. It's written for pro- fessional technicians, but is simple enough for most mechanically-inclined owners to under- stand.
  • Page 255 I130B04A-AAT Tire quality grading Department of Transportation quality grades - All passenger vehicle tires must conform to Federal Safety Stan- dards in addition to these grades. These quality grades are molded on the sidewall. Treadwear - The tread wear grade is a comparative rating based on the wear rate of the tire when tested under con- trolled conditions on a specified gov-...
  • Page 256 For example: Treadwear 200 Traction AA Temperature A I130D04A-AAT Hyundai motor vehicles are designed and manu- factured to meet or exceed all applicable safety standards. For your safety, however, we strongly urge you to read and follow all directions in this Owner's Manual, particularly the information under the headings "NOTE", "CAUTION"...
  • Page 257: Reporting Safety Defects

    You will not be responsible for paying filing and hearing fees above $275.00. All other arbitration costs shall be borne by Hyundai Motor America. You are not responsible to pay any of the costs Hyundai incurs. This Binding Arbitration Agreement shall not deprive you of any remedies avail- able to you under applicable law.
  • Page 258: Vehicle Specifications

    VEHICLE SPECIFICATIONS Measurement ... 9-2 Engine ... 9-3 Lubrication Chart ... 9-4...
  • Page 259 VEHICLE SPECIFICATIONS J010A01GK-AAT MEASUREMENT Overall length Overall width Overall height (unladen) Wheel base Front Wheel tread P205/55 R16 Rear Front 215/45 R17 Rear J020A01GK-AAT POWER STEERING Type Rack and pinion Wheel free play 0 ~ 1.18 in.(0 ~ 30 mm) Rack stroke 5.20 in.(132 mm) Oil pump type...
  • Page 260 ENGINE J070A05GK-AAT ITEMS Engine Type Bore x Stroke (mm) Displacement (cc) Firing order For adjusting Valve clearance (Cold Engine : 20 ± 5°C) For checking Idle speed (RPM) Ignition timing (Base) 2.0 L 4-Cyl., In-line DOHC CVVT 82 x 93.5 1,975 1 - 3 - 4 - 2 Intake...
  • Page 261: Lubrication Chart

    API SJ,SL or ABOVE, ILSAC GF-3 or ABOVE Manual HYUNDAI GENUINE PARTS MTF 75W/85 (API GL-4) HYUNDAI GENUINE ATF SP III, DIAMOND ATF SP III, Transaxle Auto SK ATF SP III or other brands meeting the SP III specification approved by Hyundai Motor Co..
  • Page 262: Index

    INDEX...
  • Page 263 (H280, H265, H465) ... 1-111, 1-117, 1-123 Consumer Information ... 8-13 Cooling Fans ... 6-21 Corrosion Protection Cleaning the interior ... 4-5 Protecting your Hyundai from corrosion ... 4-2 Washing and waxing ... 4-3 Cruise Control ... 1-80 Defrosting/Defogging ... 1-93 Door Central door lock ...
  • Page 264 Driving Economical driving ... 2-15 Smooth cornering ... 2-16 Winter driving ... 2-16 Electronic Stability Control (ESC) ... 2-12 Emissions Control Systems ... 7-1 Engine Before starting the engine ... 2-3 Compartment ... 6-2 Coolant ... 6-7 Coolant temperature gauge ... 1-53 If the engine overheats ...
  • Page 265 INDEX Jump Starting ... 3-3 Keys ... 1-3 If you lose your keys ... 3-18 Positions ... 2-3 Lubrication Chart ... 9-4 Luggage Net ... 1-79 Maintenance Intervals Explanation of scheduled maintenance items ... 5-7 Maintenance under severe usage conditions ... 5-6 Scheduled maintenance ...
  • Page 266 Vehicle Load Limit ... 2-22 Vehicle Specification ... 9-1 Ventilation Center ventilator ... 1-84 Side ventilator ... 1-84 Warning Lights ... 1-48 Warranties for Your Hyundai ... 8-13 Windshield Wiper and Washer ... 1-60 Windshield Wiper Blades ... 6-9 INDEX...
  • Page 267 INDEX...
  • Page 268 A000A01A-AAT This Owner's Manual should be considered a part of the car and remain with it when it is sold for the use of the next owner. ORIGINAL OWNER ADDRESS CITY DELIVERY DATE DEALER NAME ADDRESS CITY OWNER'S I.D. STATE ZIP CODE (Date Sold to Original Retail purchaser) DEALER NO.
  • Page 269 Apply the parking brake, with the engine running, shift the selector lever through all ranges and return to “N” (Neutral) position. Then check the level of fluid on the dipstick. Use only HYUNDAI GENUINE ATF SP III, DIAMOND ATF SP III, SK ATF SP III or other brands meeting the SP III specification approved by Hyundai Motor Co..

Table of Contents
