Platform: DBALL2
Firmware: BMW03
Update Alert: Firmware updates are posted to the web on a regular basis. We recommend
that you check for firmware and/or install guide updates prior to installing this product.
Installation Guide
Doorlock and
Electronic Ignition Interface
is required for some BMW vehicles which have Key Barrel and Ignition Switch with ribbon cable
(type 2 and type 3). Features include door locks, turn signals, windows and sunroof, door trigger
sensing, hood pin, trunk/hatch, ignition and tach output.
One universal transponder bypass module and one factory programmed key is required to install a remote starter.
Index
Vehicle Application Guide................................................................................................................................................
A Note Regarding Climate Controls.................................................................................................................................
Immobilizer Interface.......................................................................................................................................................
Installation - Wiring Diagram
Type 1 (Automatic Transmission)....................................................................................................................................
Type 1 (Manual Transmission)........................................................................................................................................
Locating components .....................................................................................................................................................
Type 2 (Automatic Transmission)....................................................................................................................................
Type 2 (Manual Transmission).........................................................................................................................................
Type 2 Connection Guide for KIBMW5..........................................................................................................................
.
Type 3 (Automatic Transmission)....................................................................................................................................
Type 3 (Manual Transmission).........................................................................................................................................
Programming
Module Programming......................................................................................................................................................
Module Reset..................................................................................................................................................................
Feature & Option List.......................................................................................................................................................
Feature Programming......................................................................................................................................................
LED Diagnostics and Troubleshooting............................................................................................................................
Warranty...........................................................................................................................................................................
† BMW and MINI are registered trademarks and property of their respective companies.
for BMW and MINI vehicles. dditional module KIBMW5
A
Rev.: 20191108
02
02
03
04
05
06
07
08
09
10
11
13
14
15
15
16
17
© 2019 Directed. All rights reserved.
Advertisement
Table of Contents
Related Manuals for Xpresskit 20191108
Summary of Contents for Xpresskit 20191108
-
Page 1: Table Of Contents
Platform: DBALL2 Firmware: BMW03 Rev.: 20191108 Update Alert: Firmware updates are posted to the web on a regular basis. We recommend that you check for firmware and/or install guide updates prior to installing this product. Installation Guide Doorlock and Electronic Ignition Interface for BMW and MINI vehicles. -
Page 2: Vehicle Application Guide
Platform: DBALL2 Firmware: BMW03 Rev.: 20191108 Page 2 Vehicle Application Guide The following table lists the vehicles and features which are compatible with this product. The number assigned to each year allows you to determine which installation type should be used for your vehicle. -
Page 3: Immobilizer Interface
Platform: DBALL2 Firmware: BMW03 Rev.: 20191108 Page 3 Immobilizer interface for Type 1 For vehicles with Keyless Entry you must remove battery from OEM Remote Control. 1. Standard immobilizer interface with TBXKEY TBXKEY are sold SEPARATELY. Request an order from Directed using the part numbers listed below. -
Page 4: Type 1 (Automatic Transmission)
Platform: DBALL2 Firmware: BMW03 Rev.: 20191108 Page 4 INSTALLATION - TYPE 1 (Automatic Transmission) (+) Ignition Input (AC) Tach Input (-) Handbrake Status Input* (-) Ground (-) Ground (+) 12V (+) 12 V Brake switch Purple/White Brown/Black Brown/Gray Brown/Gray Blue/Red... -
Page 5: Type 1 (Manual Transmission)
Platform: DBALL2 Firmware: BMW03 Rev.: 20191108 Page 4 INSTALLATION - TYPE 1 (Manual Transmission) (+) Ignition Input (AC) Tach Input (-) Handbrake Status Input* (-) Ground (-) Ground (+) 12V (+) 12 V Clutch switch Blue/Brown Blue/Brown Brown/Black* Blue/Brown* Violet/Yellow... -
Page 6: Locating Components
Platform: DBALL2 Firmware: BMW03 Rev.: 20191108 Page 5 Locating components in the vehicle BMW 5 Series (F10) BMW 5 Series (F10) Brake Switch CAS Plug Can Gateway PTS Wires Pin 6 - White/Blue Can H - Yellow/Red Pin 7 - Black/White... -
Page 7: Type 2 (Automatic Transmission)
Platform: DBALL2 Firmware: BMW03 Rev.: 20191108 Page 6 INSTALLATION - TYPE 2 (Automatic Transmission) (+) Ignition Input (AC) Tach Input (-) Handbrake Status Input* (-) Ground (-) Ground (+) 12 V (+) 12V Brake switch Purple/White Brown/Black Brown/Gray Brown/Gray Blue/Red... -
Page 8: Type 2 (Manual Transmission)
Platform: DBALL2 Firmware: BMW03 Rev.: 20191108 Page 7 INSTALLATION - TYPE 2 (Manual Transmission) (+) Ignition Input (AC) Tach Input (-) Handbrake Status Input (-) Ground (-) Ground (+) 12 V (+) 12V Clutch switch Blue/Brown Brown/Black* Blue/Brown* Violet/Yellow Violet/Yellow*... -
Page 9: Type 2 Connection Guide For Kibmw5
Platform: DBALL2 Firmware: BMW03 Rev.: 20191108 Page 8 TYPE 2 - Connection Guide for additional module KIBMW5 Connect the KIBMW5 Cable to the key slot after programming the DB-ALL module. Key Slot Disconnect original ribbon cable from ignition key slot Connection with DB-ALL Connect KIBMW5 Cable between key slot and original plug. -
Page 10: Type 3 (Automatic Transmission)
Platform: DBALL2 Firmware: BMW03 Rev.: 20191108 Page 9 INSTALLATION - TYPE 3 (Automatic Transmission) (+) Ignition Intput (AC) Tach Input (-) Ground (-) Parking/Neutral Input (+) 12 V (-) Ground Brake switch Purple/White Brown/Black Brown/Gray Brown/Gray Blue/Red Located at Blue/Red... -
Page 11: Type 3 (Manual Transmission)
Platform: DBALL2 Firmware: BMW03 Rev.: 20191108 Page 10 INSTALLATION - TYPE 3 (Manual Transmission) (+) 12 V (-) Ground (+) Ignition Intput (AC) Tach Input (-) Handbrake Status Input Clutch switch Blue/Brown Brown/Black* Blue/Brown* Violet/Yellow Violet/Yellow* Located at Blue/Black* Clutch pedal... -
Page 12: Module Programming
1. Connect the interface module to your computer using the XKLoader2. 2. Open an Internet Explorer browser (version 6 or higher), and go to www.xpresskit.com. The detail of the platform and firmware that is currently saved on the interface module will be indicated in the top left corner of the page. - Page 13 Platform: DBALL2 Firmware: BMW03 Rev.: 20191108 Page 12 For Type 2 vehicles Wait until the LED turns ON solid red and press the Unlock button on the OEM remote. Solid Important: Do NOT press the brake pedal. Insert the key into the key slot.
-
Page 14: Module Reset
Platform: DBALL2 Firmware: BMW03 Rev.: 20191108 Page 13 Module Reset A module reset will erase the module programming only (bypass, convenience and vehicle detection). All the settings configured on the module using the web config tool will remain untouched. D2D Installation If required for your installation, connect the 10-pin, 12-pin &... -
Page 15: Feature & Option List
It is recommended to configure all the features and options listed below using the configuration tool found on the module flashing page on www.xpresskit.com. The web offers more options; however, a manual configuration of the features is possible using the information on this page. -
Page 16: Led Diagnostics And Troubleshooting
Platform: DBALL2 Firmware: BMW03 Rev.: 20191108 Page 14 LED Diagnostics & Troubleshooting Status Description Troubleshooting Module Programming Module has no power. Check the power connections. Module is powered. Waiting for Solid red Check if the ignition input is properly connected. -
Page 17: Warranty
Platform: DBALL2 Firmware: BMW03 Rev.: 20191108 Page 16 Limited One Year Consumer Warranty For a period of ONE YEAR from the date of purchase of a Directed Electronics remote start or security product, Directed Electronics. (“DIRECTED”) promises to the original purchaser, to repair or replace with a comparable reconditioned piece, the security or remote start accessory piece (hereinafter the “Part”), which proves to be defective in workmanship or material...
