JDI-DPES
JDI-DPES-UL
DIAPHRAGM PUMP EVACUATION
SYSTEM USER'S MANUAL
Part No. JDI-DPES & Part No. JDI-DPES-UL
FOR WARRANTY INFORMATION, PLEASE CALL 800-433-0708
MODEL NO:
DATE OF PURCHASE:
READ AND SAVE THIS MANUAL
FOR SERVICE ASSISTANCE, CALL 800-433-0708 OR VISIT JOHNDOW.COM
151 Snyder Ave.
Barberton, OH 44203
Rev 8/2021
Advertisement
Related Manuals for JohnDow Industries JDI-DPES
Summary of Contents for JohnDow Industries JDI-DPES
- Page 1 ™ JDI-DPES JDI-DPES-UL DIAPHRAGM PUMP EVACUATION SYSTEM USER’S MANUAL Part No. JDI-DPES & Part No. JDI-DPES-UL FOR WARRANTY INFORMATION, PLEASE CALL 800-433-0708 MODEL NO: DATE OF PURCHASE: READ AND SAVE THIS MANUAL FOR SERVICE ASSISTANCE, CALL 800-433-0708 OR VISIT JOHNDOW.COM 151 Snyder Ave.
- Page 2 III-Trichloroethane, Methylene Chloride or other Halogenated Hydrocarbon solvents which WARNING may react and explode. • Air pressure should not exceed 115 psi (JDI-DPES) or 110 psi (JDI-DPES-UL). Indicates a hazardous situation that, if not avoided, could CAUTION result in minor or moderate injury.
- Page 3 GETTING STARTED This pump comes fully assembled and ready for use. If you notice any parts are missing or damaged per the contents list below, please contact us. CONTENTS Item JDI-DPES JDI-DPES-UL Description Qty. Replacement Part Replacement Part...
- Page 4 5. Wrap threads of 1/4” NPT M x F 90° Brass Fitting [12] with PTFE tape. Thread into ball valve [16]. 6. For JDI-DPES: · Wrap threads of ball valve [16] with PTFE tape. Thread into front, center port of pump. Tighten with 13/16”...
