Page 1 M a n u a l ..SUBURBAN...
Page 3 This will help you enjoy safe and trouble-free operation of your vehicle. When it comes to service, keep in mind that your GMC Truck dealer knows your vehicle best and is interested in your complete satisfaction. Your dealer invites you to return for all of your service needs both during and after the warranty period.
Page 4 DGN Marketing Services Ltd., I500 Bonhill Rd., Mississauga, Ontario L5T GMCTRUCK General Motors, GM and the GM Emblem, GMC, Yukon and Suburban are registered trademarks of General Motors Corporation. if you ever need it will be there 1C7.
Page 5 Model Reference This manual covers these models: UTILITY WAGON...
Page 6 Table of Contents Introduction How to Use this Manual This section tells you how to use your manual and includes safety and vehicle damage warnings and symbols. Section 1 Seats and Safety Restraints This section tells you how to use your seats and safety restraints properly.
Page 7 How to Use This Manual Many people read their owner’s manual from beginning to end when they first receive their new vehicle. This will help you learn about the features and controls for your vehicle. In this manual, you’ll find that pictures and words work together to explain things quickly.
Page 8 Safety Warnings and Symbols You will find a number of safety cautions in this book. We use a box with gray background and the word CAUTION to tell you about things that could hurt you if you were to ignore the warning. In the gray caution area, we tell you what the hazard is.
Page 9 Vehicle Damage Warnings Also, in this book you will find these notices: NOTICE: These mean there is something that could damage your vehicle. In the notice area, we tell you about something that can damage your vehicle. Many times, this damage would not be covered by your warranty, and it could be costly.
Page 10 These symbols are important for you and your passengers whenever your vehicle is driven: Fasten Safety Belts These symbols have to do with your lights: Master Lighting Swifch Lights Parking Door LocWUnlock Turn Signal Hazard Warning Direction Running Lights Vlll Headlight Flasher High Beam...
Page 11 These symbols are on some of your controls: Windshield Wiper Rear Window Washer These symbols are used on warning and indicator lights: Engine Coolant Temperature BRAKE Brake Windshield Windshield Washer Defroster Rear Window Ventilating Defogger Battery Charging System ANTI- LOCK RELEASE 4 Wheel Parking Brake...
Page 12 Here are some other symbols you may see: Hood Release Lighter Horn Fuse...
Page 13: Table Of Contents
Seats Safety Belts Here you'll find information about the seats in your vehicle and how to use your safety belts properly . You can also learn about some things you should not do with safety belts Seats and Seat Controls ..... Frontseats .
Page 14: Seats And Seat Controls
Seats and Seat Controls This section tells about the seats and down. It also tells you about reclining front seatbacks and head restraints. Front Seats Manual Fronf Seaf Slide the lever at the front of the seat toward the outer seat support to unlock it.
Page 15 Power Seat You can use the center switch knob to move the seat where you want it. To raise the seat, move the center switch knob up. To lower the seat, move the center switch knob down. To move the seat forward, move the center switch knob toward the inside of the vehicle.
Page 17: Head Restraints
Head Restraints This position reduces the chance of a neck injury in a crash. Seatback Latches (Reclining Split Bench and Reclining Bucket The front seatback folds forward to let you access the rear of the vehicle. After returning the seatback to its upright position, pull the seatback forward to make sure it is locked.
Page 18 Easy Entry Seat (Utility Model Front Seats) The driver and passenger front bucket seat and the 40/60 split bench seat of your vehicle has an easy entry feature. This makes it easy to get in and out of the rear seat. After returning the seat to its regular position, try to move the seat with your body, to make sure the seat CAUTION:...
Page 19: Rearseats
Rear Seats Easy Entry Seat (Wagon Model Second Seat) The right side of the rear 60/40 split folding bench seat, available in the wagon model, has an easy entry feature, That makes it easy to get in and out of the third seat, if you have one. When you do, the seat bottom will release.
Page 20 Rear Folding Seat (Utility Model) If your vehicle has a rear seat, the seat can be folded flat for more cargo space. Before folding, make sure nothing is under or in front of the seat. When the seat is folded, While the seat is in the folded position, hang the latch plate end of the outer passenger position safety belts on the hooks at the top of each retractor cover, out of the way.
Page 21 Folding Second Seat (Wagon Models) If your vehicle has a 60/40 second seat, either side may be folded down to give you more cargo space. Before folding, push the buckle portion of the safety belt down into the seat cushion pockets, out sure that nothing is under or in front of the seat.
Page 22 Then, lift the seatback up and push rearward until it latches. Lower the seat cushion until it latches in position. After returning the seat to the passenger position, pull forward on the seatback and up on the seat cushion handle to make sure the seat is locked in place.
Page 23 TO remove the seat, fully open the rear load doors and enter the back of the vehicle. To unlatch the safety belt, press in on the inside of the buckle cover sleeve and pull the latch plate out of the buckle. Then, hang the latch plate end of the belt on the hook at the top...
Page 24 Turn the seat sideways and take it out of the vehicle. To put the seat back in, hold the seat sideways and put Turn the seat to the forward position and set it down, with the latches at the bottom of the seat over the hooks in the floor. Pull up on the center release handle and let the seat drop into place.
Page 25: Safety Belts: They're For Everyone
CAUTION: A safety belt that is twisted or not properly attached won’t provide the protection needed in a crash. The person wearing the belt could be seriously injured. After installing the seat, always check to be sure that the safety belts are not twisted and are properly attached.
Page 26: Why Safety Belts Work
In many states and Canadian provinces, the law says to wear safety belts. Here’s why: They work. You never know if you’ll be in a crash. If you do have a crash, you don’t know if it will be a bad one. A few crashes are mild, and some crashes can be so serious that even buckled up a person wouldn’t survive.
Page 27 Take the simplest “vehicle.” Suppose it’s just a seat on wheels. 1-15...
Page 28 Get it up to speed. Then stop the "vehicle." The rider doesn't stop. The person keeps going until stopped by something. In a real vehicle, it could be the windshield ... or the instrument panel ... 1-16...
Page 29: Questions Many People Ask About Safety Belts
With safety belts, you slow down as the vehicle does. You get more time to stop. You stop over more distance, and your strongest bones take the forces. That’s why safety belts make such good sense. Here Are Questions Many People Ask About Safety Belts Won’t I be trapped in the vehicle after an accident safety belt?
Page 30: How To Wear Safety Belts Properly
a good driver, and I never drive far from home, why should I I’m wear safety belts? You may be an excellent driver, but if you’re in an accident - even one that isn’t your fault a good driver doesn’t protect you from things beyond your control, such as bad drivers.
Page 31: Driver Position
Driver Position This section describes the driver’s restraint system. Lap-Shoulder Belt The driver has a lap-shoulder belt. Here’s how to wear it properly. 1-19...
Page 32 1. Close and lock the door. 2. Adjust the seat (to see how, see “Seats” in the Index) so you can sit straight. 3. Pick up the latch plate and pull the belt across you. (On some models, you may hear a clicking sound as the belt is pulled out. The clicking sound is the shoulder belt tension feature operating properly.) Don’t let the belt get twisted.
Page 33 What’s wrong with this? The shoulder belt is too loose. It won’t give nearly as much protection this way. 1-23...
Page 34 What’s wrong with this? 1-22...
Page 35 What's wrong with this? The belt is over armrest. 1-23...
Page 36 What’s wrong with this? The shoulder belt is worn under the arm. It should be worn over the shoulder at all times. CAUTION: You can be seriously injured if you your arm. In a crash, your body would move which would increase the chance of head and neck injury. Also, the belt would apply too much force to the ribs, which aren’t as strong as shoulder bones.
Page 37 What's wrong with this? The belt is twisted across the body. CAUTION: You can be seriously injured by a twisted belt. In a crash, you wouldn't have the full width of the belt to spread impaet forces. If a belt is twisted, make it straight so it can work properly, or ask your dealer to Before you close the door, be sure the belt is out of the way.
Page 38: Safety Belt Use During Pregnancy
Safety Belt Use During Pregnancy Safety belts work for everyone, including pregnant women. Like all occupants, they are more likely to be seriously injured if they don’t wear safety belts. The best way to protect the fetus is to protect the mother. When a safety belt is worn properly, it’s more likely that the fetus won’t be hurt in a crash.
Page 39 Center Passenger Position Lap Belt your vehicle has front and rear bench seats, someone can sit in the center positions. When you sit in a center seating position, lap safety belt, which has no retractor. make the belt longer, tilt the latch plate and pull it along the belt.
Page 40: Passenger Positions
Buckle, position and release it the same way as the lap part of a lap-shoulder belt. If the belt isn’t long enough, see “Safety Belt Extender” at the end of this section. Make sure the release button on the buckle is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.
Page 41: Lap-Shoulder Belt
Lap-Shoulder Belt The positions next to the windows have lap-shoulder belts. Here’s how to wear one properly. 1. Pick up the latch plate and pull the belt across you. Don’t let it get twisted. 2. Push the latch plate into the buckle until it clicks. If the belt stops before it reaches the buckle, tilt the latch plate and keep pulling until you can buckle Pull up on the latch plate to make sure it is secure.
Page 42 The lap part of the belt should be worn low and snug on the hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones. And you'd be less likely to slide under the lap belt. If you slid under it, the belt would apply force at your abdomen.
Page 43: Children
Children In fact, the law in every state in the United States and in every Canadian province says children up to some age must be restrained while in a vehicle. Smaller Children and Babies Everyone in a vehicle needs protection! That includes infants and all children smaller than adult size.
Page 44 CAUTION: Smaller children and babies should always be restrained in a child or infant restraint. The instructions for the restraint will say whether it is the right type and size for your child. A very young child’s hip bones are so small that not stay low on the hips, as it should.
Page 45: Child Restraints
Child Restraints Be sure to follow the instructions for the restraint. instructions on the restraint itself or in use the belt system in your vehicle, but the child also has to be secured within the restraint to help reduce the chance instructions that come with the infant or child restraint will show you how to do that.
Page 46 Securing a Child Restraint in a Rear Outside Position You’ll be using the lap-shoulder belt. See the earlier section about the top strap if the child restraint has one. 1. Put the restraint on the seat. Follow the instructions for the child restraint.
Page 47 To remove the child restraint, just unbuckle the vehicle’s safety belt and let it go back all the way. The safety belt will move freely again and be ready to work for an adult or larger child passenger. Buckle the belt. Make sure the release button is positioned so you...
Page 48 Securing a Child Restraint in a Center Seat Position When you secure a child restraint in a center seating position, you’ll be using the lap belt. See the earlier section about the top strap if the child restraint has one. 2.
Page 49 6. To tighten the belt, pull its free end while you push down on the child restraint. Push and pull the child restraint in different directions to be sure it is secure. If the child restraint isn’t secure, turn the latch plate over and buckle it again.
Page 50 3. Pick up the latch plate, and run the lap and shoulder portions of the vehicle’s safety belt through or around the restraint. The child restraint instructions will show you how. If the shoulder belt goes in front of the child’s face or neck, put it behind the child restraint.
Page 51 To remove the child restraint, just unbuckle the it go back all the way. The safety belt will move freely again and be ready to work for larger child passenger. 6. To tighten the belt, feed the lap belt back into the retractor while you push down on the child...
Page 52: Larger Children
Larger Children If you have the choice, a child should sit next to a window so the child can wear a lap-shoulder belt and get the additional restraint a shoulder belt can provide. Accident statistics show that children are safer if they are restrained in the rear seat.
Page 53 What if a child is wearing a lap-shoulder belt, but the child is so small that the shoulder belt is very close to the child’s face Move the child toward the center of the vehicle, but be sure that the shoulder belt still is on the child’s shoulder, so that in a crash the child’s upper body would have the restraint that belts provide.
Page 54: Safety Belt Extender
Wherever the child sits, the lap portion of the belt should be worn low and snug on the hips, just touching the child’s thighs. This applies belt force to the child’s pelvic bones in a crash. Safety Belt Extender If the vehicle’s safety belt will fasten around you, you should use it. But if a safety belt isn’t long enough to fasten, your dealer will order you an extender.
Page 55: Checking Your Restraint Systems
Checking Your Restraint Systems Now and then, make sure all your belts, buckles, latch plates, retractors, anchorages and reminder systems are working properly. Look for any loose parts or damage. If you see anything that might keep a restraint system from doing its job, have it repaired.
Page 56 What’s wrong with this? The belt is torn. Torn or frayed belts may not protect you in a crash. They can rip apart under impact forces. If a belt is torn or frayed, get a new one right away. Before replacing any safety belt, see your dealer for the correct part number. You’ll need the model year and model number for your vehicle.
Page 57 Features & Controls Here you can learn about the many standard and optional features on your vehicle. and information on starting. shifting and braking . Also explained are the instrument panel and the warning systems that tell you if everything is working properly-and For explanation of vehicle symbols.
Page 58 Parking Over Things That ......... . . EngineExhaust Running Your Engine While You’re Parked .
Page 59: Keys
Keys The square-shaped key is for the ignition only.
Page 60 When a new vehicle is delivered, the dealer removes the plugs from the keys, and gives them to the first owner. Each plug has a code on it that tells your dealer or a qualified locksmith how to make extra keys. Keep the plugs in a safe place. If you lose your keys, you’ll be able to have new ones made easily using these plugs.
Page 61: Doorlocks
Door Locks There are several ways to lock and unlock your vehicle: From the outside: Use your door key.
Page 62 Power Door Locks (Option) On four-door models, the switch on each rear door works only that door’s lock. It won’t lock (or unlock) all of the doors Leaving Your Vehicle If you are leaving the vehicle, take your keys, open your door and set the locks from inside.
Page 63: Your Doors And How They Work
Your Doors and How They Work Side Doors To open the door from the outside, pull the handle up and pull the door open. To open the door from the inside, pull the lever toward you and push the door open.
Page 64: Tailgate
Tailgate Glass, Tailgate and Rear Doors CAUTION: It can be dangerous to drive with the tailgate glass, tailgate, or rear doors open because carbon monoxide (CO) gas can come into your vehicle. You can’t see or smell CO. unconsciousness and even death. If you must drive with the tailgate glass, tailgate, or rear doors open, or if electrical wiring or other cable connections must pass through the seal between the body and the tailgate glass,...
Page 65: Paneldoors
Open the tailgate by lifting up on the handle while pulling the tailgate toward you. Close the tailgate before closing the tailgate is securely latched by pulling it toward you. After closing the rear glass, pull up on its handle to make sure it is locked. Panel Doors To open the rear panel doors on the wagon model, you must open the right door first.
Page 66: Theft
The rear doors have check assembly to keep them from fully opening during normal use. To fully open the either rear door, you must release the check strap. First, open the door part way until the white mark on the check strap is fully outside the door edge.
Page 67: New Vehicle Break-In
Parking at Night Park in a lighted spot, close all windows and lock your vehicle. Remember to keep your valuables out with you. Parking Lots If you park in a lot where someone will be watching your vehicle, it’s best to lock it up and take your keys.
Page 68: Ignitionswitch
Ignition Switch Use your square key to start your vehicle. The square key lets you turn the ignition switch to five different positions: ACC (Accessory): ACC lets you use things like the radio and the windshield wipers when the engine is off. To get into ACC, push in the key and turn it toward you.
Page 69: Starting Your Gasoline Engine
NOTICE: If your key seems stuck in “LOCK” and you can’t turn it, be sure it is all the and right while you turn the key hard. But turn the key only with your hand. Using a tool to force it could break the key or the ignition switch.
Page 70 Transmission: Auwmatic Move your shift lever to “P” (Park) or “N” (Neutral). Your engine won’t start in any other position already moving, use “ N ’ NOTICE: Don’t try to shift to “P” (Park) if your vehicle is moving. If you do, you could damage the transmission.
Page 71: Driving Through Deep Standing Water
If your engine is already hot and then stalls, turn your ignition key to OFF. your key to RUN and wait 20 seconds before you restart your Then turn engine. When the engine starts, let go of the key and the accelerator pedal. NOTICE: Your engine is designed to work with the electronics in your vehicle.
Page 72: Starting Your Diesel Engine
Driving In Snow (Diesel Engines) When driving in a heavy snowstorm or in swirling snow with a diesel engine, snow can get into the air intake system. If you keep driving in these conditions the air cleaner may get plugged, causing black smoke and loss of power.
Page 73 3. If this light does not come on, or the instant the light goes off, turn your ignition key to START. When the engine starts, let go of the key. NOTICE: Holding your key in “Start” for longer than 15 seconds at a time will cause your battery to be drained much sooner.
Page 74 To use the engine coolant heater, first turn off the engine. Theii hood, unwrap the electrical cord and plug it in. It uses normal house voltage volts), but: CAUTION: Plugging the cord into an ungrounded outlet could cause an electrical shock. Also, the wrong kind of extension cord could overheat and cause a fire.
Page 75 lf Your Diesel Engine Won’t Start If you’ve run out of fuel, look at “Running Out of Fuel” (see “Diesel Fuel Requirements and Fuel System” in the Index). If you’re not out of fuel, and your engine won’t start, do this: Turn your ignition key to RUN.
Page 76 In very cold weather, 0°F help. You’ll get easier starting and better fuel economy during engine warm-up. Usually, the coolant heater should be plugged in a minimum of four hours prior to starting your vehicle. To use the coolant heater: Turn off the engine.
Page 77: Automatic Transmission
Automatic Transmission P (Park) This locks your rear wheels. It’s the best position to use when you start your engine because your vehicle can’t move easily. There are several different positions for your shift lever. 2-21...
Page 78 R (Reverse) Use this gear to back up. NOTICE: Shifting to “R” (Reverse) while your vehicle is moving forward could damage your transmission. Shift to “R” only after your vehicle is stopped. To rock your vehicle back and forth to get out of snow, ice or sand without damaging your transmission, see “If You’re Stuck: In Sand, Mud, Ice or Snow”...
Page 79 Going about the way down. You’ll shift down to the next gear and have more power. should not be used when towing a trailer, carrying a heavy load, driving steep hills, or for off road driving. Select when operating the vehicle under any of these conditions. (Third Gear) This is like but you never go into Overdrive.
Page 80: Five-Speed Manual Transmission
Five-Speed Manual Transmission 1 (First Gear) - Press the clutch pedal and shift into slowly let up on the clutch pedal as you press the accelerator pedal. You can shift into “1” when you’re going less than 20 mph (32 k d h ) . If you’ve come to a complete stop and it’s hard to shift into “1 shift lever in Neutral and let up on the clutch.
Page 81 Shiff Light When this light comes on, you can shift to the next higher gear if weather, road and traffic conditions let you. For the best fuel economy, accelerate slowly and shift when the light comes on. While you accelerate, it is normal for the light to go on and off if you quickly change the position of the accelerator.
Page 82: Locking Rear Axle
NOTICE: If you skip more than one gear when you downshift, or if you race the engine when you downshift, you can damage the engine, clutch or transmission. Locking Rear Axle If you have this feature, your rear axle can give you additional traction on snow, mud, ice, sand or gravel.
Page 83 To release the parking brake: If the ignition is on when the parking brake is released, the brake system warning light will go off. NOTICE: Driving with the parking brake on can cause your rear brakes overheat. You may have to replace them, and you could also damage other parts of your vehicle.
Page 84 Shifting Into “P” (Park) (Automatic Transmission Models Only) Steering Column Shift Lever 2. Move the shift lever into “P” (Park) position like this: Pull the lever toward you. Move the lever up as far as it will go. 3. If you have four-wheel drive, be sure the transfer case is in a drive gear not i n “N”...
Page 85 5 . Remove the key and take it with you. If you can walk away from your vehicle with the ignition key in your hand, your vehicle is in (Park). Leaving Your Vehicle With the Engine Running (Automatic Transmission Models Only) If you have to leave your vehicle with the engine running, be sure your vehicle is in (Park) and your parking brake is firmly set before you...
Page 86: Parking Over Things That Burn
Parking Your Vehicle (Manual Transmission Models Only) Before you get out of your vehicle, put your manual transmission in “R” (Reverse), turn off the engine, and firmly apply the parking brake If you have four-wheel drive, be sure your transfer case is in a drive gear. Your vehicle could roll if it isn’t.
Page 87: Engineexhaust
Engine Exhaust Running Your Engine While You're Parked (Automatic Transmission) '2-31...
Page 88: Four-Wheeldrive
If you have four-wheel drive and your transfer case is in your vehicle will be free to roll, even if your shift lever is in be sure the transfer case is in a drive gear the proper steps to be sure your vehicle won’t move. See “Shifting Into ‘P’ (Park)”...
Page 89: Transfercase
NOTICE: Driving in the 4H or 4L positions for a long time on dry or wet pavement could shorten the life of your vehicle’s drivetrain. Transfer Case An indicator near the lever shows you the transfer case settings. Some delay between shifting and the indicator’s lighting is normal. If the indicator light does not light up, or if the front axle light does not go out after you shift out of four-wheel drive, have your dealer check your system.
Page 90: Front Axle Locking Feature
When your headlights or parking lights are on, rotate the dial to the right of your headlight switch up to brighten, or down to dim, your transfer case indicator light. 2H (2-Wheel High): This setting is for driving in most street and highway situations.
Page 91: Windows
Windows The driver’s door has a switch for the passenger windows as well. Your power windows will work when the ignition has been turned to ACC or RUN. Push the rear of the switch with the power window symbol on it to lower the window.
Page 92 Electric Tailgate Glass Release Before operating your electric tailgate glass release, see the caution under “Tailgate Glass, Tailgate and Rear Doors” in this section. If you have an automatic transmission, your shift lever must be in “P” (Park) or “N”(Neutra1) for the release to work. With a manual transmission, you must apply the parking brake for the release to work.
Page 93: Horn
Horn Tilt Wheel (Option) A tilt steering wheel allows you to adjust the steering wheel before you drive. You can raise it to the highest level to give your legs more room when you exit and enter the vehicle. To adjust the tilt steering wheel: sound the horn, press the pad in the center of the steering...
Page 94: Multifunction Lever
Multifunction Lever The lever on the left side of the steering column includes your: Turn Signal and Lane Change Indicator Headlight High-Low Beam Windshield Wipers Windshield Washer Cruise Control (Option) Passing Signal & 2-38...
Page 95: Turn Signal And Lane Change Indicator
Turn Signal and Lane Change Indicator To signal a turn, move the lever all the way up or down. When the turn is finished, the lever will return automatically. To signal a lane change, just raise or lower the lever until the green arrow starts to flash.
Page 96: Headlight High-Low Beam
Headlight High-Low Beam Windshield Wipers To change the headlights from low beam to high or high to low, pull the turn signal lever all the way toward you. Then release When the high beams are on, this blue light on the instrument panel also will be on.
Page 97: Windshield Washer
For a single wiping cycle, turn the band to MIST. Hold it there until the wipers start, then let go. The wipers will stop after one cycle. If you want more cycles, hold the band on MIST longer. You can set the wiper speed for a long or short delay between wipes.
Page 98: Cruise Control
Remember, in freezing weather, don’t use your washer until the windshield is warmed. Otherwise the washer fluid can form ice on the windshield, blocking your vision. When using concentrated washer fluid, follow the manufacturer’s instructions for adding water. Don’t mix water with ready-to-use washer fluid. Water can cause the solution to freeze and damage your tank and other parts of the washer system.
Page 99 When you apply your brakes, the Cruise Control shuts off. CAUTION: Cruise Control can be dangerous where you can’t drive safely at a steady speed. So, don’t use your Cruise Control on winding roads or in heavy traffic. Cruise Control can be dangerous on slippery roads. On such roads, fast changes in tire traction can cause needless wheel spinning, and you could lose control.
Page 100 To Resume a Sef Speed Suppose you set your Cruise Control at a desired speed and then you apply the brake. This, of course, shuts off the Cruise Control. But you don’t need to reset it. You’ll go right back up to your chosen speed and stay there. Remember, if you hold the switch at R/A longer than half a second, the vehicle will keep going faster until you release the switch or apply the brake.
Page 101 Here’s the second way to go to a higher speed: To increase your speed in very small amounts, move the switch to WA. Each time you do this, your vehicle will go about 1 mph (1.6 k d h ) faster. To Reduce Speed While Using Cruise Control There are two ways to reduce your speed while using cruise control: To slow down in very small amounts, push the button for less than half...
Page 102 Using Cruise Control on Hills How well your Cruise Control will work on hills depends upon your speed, load, and the steepness of the hills. When going up steep hills, you may have to step on the accelerator pedal to maintain your speed. When going downhill, you may have to brake or shift to a lower gear to keep your speed down.
Page 103: Headlights And Vehicle Lighting
Headlights and Vehicle Lighting Push the left side of the switch with the parking lights symbol on it to turn Parking Lights Sidemarker Lights Clearance Lights (if you have them) Taillights License Plate Lights Instrument Panel Lights Transfer Case Shift Indicator Light (if you have one) Push the left side of the switch with the master lighting symbol on it to turn on all the lights listed above as well as the headlights.
Page 104 Headlights-On Reminder A buzzer will sound when your headlights are turned on and your ignition is in OFF, LOCK or ACC. If you need to use your headlights when the ignition switch is in OFF, LOCK or ACC, the buzzer can be turned off by turning the interior light switch dial all the way off.
Page 105 Dome Lights The dome lights will come on when you open the doors or tailgate. YOU can also turn the dome lights on by turning the interior light dimmer dial all way up until it clicks. To turn the lights off, just press the side of the switch marked return the lights to automatic operation, Reading Lights You can use the dome...
Page 106 To turn the light on, press the button next to the light with lighting switch symbol on it. Press the button again to turn the light off. Underhood Reel Light To use the light, pull up on the lever and pull the light out. The cord will unreel as you pull light.
Page 107: Mirrors
Then, slide the light into the light into the holder. Mirrors lnside Mirror PUSH holder. Press on the lever to hook the 2-51 When you are done using the light, reel the cord back into the housing by tuming the handle.
Page 108 Outside Mirrors Electric Outside Rearview Mirrors If you have electric mirrors, they can be adjusted to point where you want from inside the vehicle. 2-52 Adjust your outside mirrors so you can just see the side of your vehicle, and have a clear view of objects behind you.
Page 109: Sunvisors
Convex Outside Mirror Your right side mirror may be convex. A convex mirror’s surface is curved so you can see more from the driver’s seat. Visors block out glare, you can swing down the visors. You can also swing them to help block glare at the front and side windows.
Page 110: Rear Window Wiper And Washer
Rear Window Wiper and Washer Some visors have an extender on the inside edge. When the visor is down, pull the extender out for extra glare coverage at the front or side. Some visors have mirrors with lights. If the mirror has lights, they will come on when you lift the mirror cover.
Page 111: Cigarette Lightedashtrays
For delay wiping, slide the lever under DELAY to the center of the rear wiper control. The wiper will cycle every nine seconds. For steady wiper action, move the slide lever all the way to the right. To wash the window, push in on the end of the lever. Window washer fluid will continue to spray until the lever is released.
Page 112: Storage Compartments
Storage Compartments Your vehicle has a variety of storage compartments provided for your convenience. Glove Box use a rear ashtray, pull at the top of the ashtray door to flip the door open. open your glove box, press the button down and pull the door open.
Page 113 Center Floor Console Your vehicle may have a console compartment between the bucket seats. Two cup depressions are provided for your convenience. To open it, just squeeze the buttons on both sides of the keyhole, and pull up. Use your round key to lock this compartment.
Page 114 Instrument Panel Cup Holder If your vehicle has a full or split bench seat, you may have a cup holder attached to the instrument panel. Your console also has a cup holder that slides out, for the back seat passengers to use. To use the cup holder, pull the handle and slide the cup holder...
Page 115 Center Overhead Console Garage Door Opener Compartment If you have a garage door opener, the front overhead compartment can be used to conveniently store the opener. Your vehicle may have an overhead console. It has storage compartments inside install the garage door opener, first open the compartment door 2-59...
Page 116 Center the garage door opener activation button over the console door button, and press the opener firmly into place. Add one peg at a time until the on the compartment door operates the garage door opener, with the compartment door closed, when you push the button marked PUSH.
Page 117 With the garage door opener positioned properly and the right number of pegs in place, you should only have to push the PUSH button slightly to operate the opener. Adjust the position of the garage door opener and add or remove pegs, as needed, until the opener operates properly.
Page 118 Rear Compartment Place your sunglasses in the compartment door with the lenses facing out. The rear compartment can be used to store a small item, like a book. To open the rear compartment, press the release button located at the rear of the compartment door.
Page 119 Other Storage Compartments Your vehicle features a number of storage compartments for convenient storage of often used items Some vehicles have storage areas in the Some models have a storage pocket on each of the front doors. You can use the pocket to store a variety of small items.
Page 120: Instrument Cluster
Instrument Panel 15 14 1. Side Window Defogger Vents 2. Light Controls Air Vents 4. Multifunction Lever 5. Tilt Lever 6. Instrument Cluster 7. Gearshift Lever 8. Audio System 9. Comfort Control System Instrument Cluster Your instrument cluster is designed to let you know at a glance how your vehicle is running.
Page 121 Speedometer and Odometer -... Tamper-Resistant Odometer Your odometer tamper-resistant. The odometer will show silver lines between the numbers if someone tries to turn it back. You may wonder what happens if your vehicle needs a new odometer installed. Laws vary as to the procedure that must be followed, so check with your state or provincial vehicle registration office.
Page 122 Tachometer NOTICE: Do not operate the engine with the tachometer in the red area, your engine or other parts could Damage to your engine or vehicle caused by operating the engine in the red area isn't covered by your vehicle warranty. Warning Lights and Indicators This section describes the warning lights and gages that may be on your vehicle.
Page 123 Waiting to do repairs can be costly know your warning lights and gages. They’re a big help. Brake System Warning Light Your vehicle’s hydraulic brake system is divided into two parts. If one part isn’t working, the other part can still work and stop you. For good braking, though, you need both parts working well.
Page 124 Anti-Lock Brake System Warning Light With anti-lock, this light will go on when you start your engine and may stay on for several seconds. That’s normal. If the light doesn’t come on, have it fixed so it will be ready to warn you if there is a problem. If the light stays on, or comes on when you’re driving, your vehicle needs service.
Page 125 Service Throffie Soon Light On diesel engines, a computer monitors the operation of the electronic accelerator. This light should come on when the ignition is on but the engine is not running, as a check to show you its working. If it does not come on at all, have it fixed right away.
Page 126 Low Coolant Warning Light If you have a diesel engine, you have a low coolant light. If this light comes on anytime the engine is running, your system is low on coolant and the engine may overheat. See “Engine Coolant” in the Index and have your vehicle serviced as soon as you can.
Page 127: Gages
Malfunction Indicator (Service Engine Soon) Lamp SERVICE ENGINE SOON A computer monitors the operation of your fuel, ignition and emission control systems. This light should come on when the ignition is on but the engine is not running, as a check to show you its working. If it does not come on at all, have it fixed right away.
Page 128 This light will come on briefly when you are starting the engine. If the light comes on and stays on while you are driving, it could indicate a problem with your vehicle. It could be a problem with your oil pressure, coolant temperature, or some other problem.
Page 129 Headlight High Beam lndicator Light The high beam indicator is on whenever you use your high beam headlights. For more details about high beams, see “Headlight High-Low Beam” earlier in this section. Turn Signal and Lane Change Indicator Lights The signal indicator will come on whenever you signal a turn or lane change.
Page 130 Gages Fuel Gage Standard Cluster -Gas Standard Cluster -Diesel DIESEL FUEL ONLY Tachometer Cluster -Gas Tachometer Cluster -Diesel The fuel gage, when the ignition is on, tells you about how much fuel you have left in your tank. The gage will first indicate empty before you are out of fuel, and you should get more fuel as soon as possible.
Page 131 Listed are four situations you may experience with your fuel gage: At the gas station, the fuel pump shuts It takes a little more or less fuel to fill up than the fuel gage indicated. For example, the gage may have indicated the tank was half full, but it actually took a little more or less than half the tank’s capacity to fill the tank.
Page 132 Oil Pressure Gage Standard Cluster -Gas Standard Cluster -Diesel Tachometer Cluster -Gas Tachometer Cluster -Diesel The oil pressure gage shows the engine oil pressure in psi (pounds per square inch) when the engine is running. Canadian vehicles indicate pressure in kPa (kilopascals). Oil pressure may vary with engine speed, outside temperature and oil viscosity, readings above the pressure...
Page 133 A reading in the low pressure zone level or other problem causing low possible. CAUTION: Don’t keep driving if the oil pressure is low. If you do, your engine can become so hot that it catches fire. You or others could be burned.
Page 134 You can only drive for a short time with the reading in either warning zone. If you must drive, turn off all unnecessary accessories, and have the vehicle serviced as soon as possible. Center High Mount Stop Lamp (CHMSL) If items are loaded on the roof of the vehicle, as in a luggage carrier, care should be taken not to block or damage the CHMSL unit.
Page 135: Luggage Carrier
Luggage Carrier (Option) The luggage carrier has slats and side rails attached to the roof, rails which can be moved fore and aft in the side rails to help secure Tie the load to the side rails or side rail supports. Use the cross rails mostly for fore and aft stops.
Page 136: Trailer Wiring Harness
If you need to carry long items, move the cross rails as far apart as they will go. Tie the load to the cross rails and the side rails or side rail supports. Also tie the load to the bumpers. Do not tie the load so tightly that the cross rails or side rails are damaged.
Page 137 Step-{ umper Pad If your vehicle has a rear step bumper, it may be equipped with a rear step pad at the center of the bumper. Use this pad to improve footing when you are stepping on the bumper step. If you will be using the bumper to tow a trailer, you must...
Page 138 Notes...
Page 139 Comfort Controls and Audio Systems In this section you’ll find out how to operate the comfort control systems and audio systems offered with your vehicle. Be sure to read about the particular system supplied with your vehicle. For explanation of vehicle symbols in this section, refer to “Vehicle Symbols”...
Page 140: Comfort Controls
Comfort Controls Flow-Through Ventilation System Your vehicle’s flow-through ventilation system supplies inside of your vehicle when it is moving. Outside air will also enter the vehicle when the heater or the air conditioning fan is running, unless your optional air conditioner is in the MAX mode.
Page 141 Air Vents If your vehicle does not have air conditioning, there are air vents below the instrument panel. You can move the vents grilles from side to side or up and down to direct the flow of air, or close the vents altogether. When you close a vent, it will increase the flow of air coming out of any vents that are open.
Page 142: Heating System
Heater Output Engine Coolant Heater If your vehicle has a diesel engine, it is equipped with an engine coolant heater. An engine coolant heater is optional on gas engine vehicles. You can use an engine coolant heater during initial start-up in cold weather (20” F, -8”...
Page 143: Electronic Heating/Air Conditioning Systeln
Function Lever The upper lever on the control panel can be moved to three different heating functions. Vent (Left): Air comes out at the vents on your instrument panel and at your front side windows. Heater (Center): Air comes out near the floor. This setting, along a heat setting, is best for cold weather.
Page 144 When you first turn on your vehicle’s air conditioning, open the windows to clear the vehicle of hot air. Using the MAX button can also help. See “MAX Button” in this section for more information. Function Display Your system has a lighted display showing each system when it is operating. During normal operation, all the lights won’t comc o n at thc same time.
Page 145 flow can be blended between the two positions. To blend between The air positions press the side of the button showing the area where you would like more air flow. The system will automatically begin to blend toward the position chosen. To stop the system between positions, just press the SAME side of the button again.
Page 146: Rear Air Conditioning And Heating Systems (Wagon Models)
Fan Control Button This button is in the upper right corner of your system control panel. The fan has four settings low, medium low, medium high and high. Press the top of the button to increase the air to decrease the air flow. The setting you select is shown on your display as LOW, MED LOW, MED HI or OFF Button Press this button to turn the air conditioning/heating system off.
Page 147 To operate the rear air conditioning system, the front air conditioning system must be on. With the front air conditioning system off, the rear system controls can be used to circulate air in the rear of the vehicle. To operate the rear system using the front control, just turn the knob to the blower position you want.
Page 148 Rear Air Conditioning and Rear Heater If your vehicle has a rear air conditioning and rear heater system combination, controls are provided to regulate the temperature, location and speed of the air flow. Front Control To adjust the air temperature, turn the temperature knob on the right side of the control panel.
Page 149: Rear Window Defogger
Rear Window Defogger r o u can tell if your vehicle has this option by looking at the rear window. If you see lines running across the glass, you have it. These are the wire-like elements which heat your window. NOTICE: Scraping the inside of your rear window could cut and damage the defogger.
Page 150: Audiosystems
Audio Systems Your Delco@ audio system has been designed to operate easily and give years of listening pleasure. You will get the most enjoyment out of it if you acquaint yourself with it first. Find out what your Delco@ system can do and how to operate all its controls, to be sure you’re getting the most out of the advanced engineering that went into it.
Page 151: How To Operate Your Am Etr Radio
NOTICE: Before you add any sound equipment to your vehicle tape player, CB radio, mobile telephone or two-way radio sure you can add what you want. If you can, it’s very important to do it properly. Added sound equipment may interfere with the operation of your vehicle’s engine, Delco@ radio or other systems, and even damage them.
Page 152: How To Operate Your Am-Fm Stereo Audio System And
TUNE Button Press the side of the button station frequency or the side of the button with the up arrow to increase the radio station frequency. Pushbuttons The five pushbuttons let you return to favorite stations. Just: Tune in the station you want. Press the SET button.
Page 153 SEEK Button Press the SEEK button higher available station. SCAN Button Press the SCAN button to make the receiver scan, and momentarily pause at, all available stations. SCAN will appear in the electronic display while the receiver is in the scan mode. Press and hold the current station.
Page 154 Pushbuttons The six pushbuttons let you return pushbuttons for up to twelve favorite stations (6 AM and 6 FM). To set the pushbuttons, just: Tune in the station you want. Press the SET button. (SET appears in the electronic display for a few seconds.) Within 5 seconds, push one of the six pushbuttons to store the station.
Page 155 Press the PWR button on the radio to turn the system on. The radio will play until a cassette is pushed into the cassette entry door (the tape side goes in first.) Once the tape is playing, use the radio control buttons for volume, tone, balance and fade, just as you do for the radio.
Page 156: How To Operate Your Am-Fm Stereo Audio System And
How to Operate Your AM-FM Stereo Audio System and Cassette Deck with Equalizer To Play The Radio Press the amber PWR button to switch the radio on and off. RCL Button When the ignition is off, press the RCL button to display the time. With the ignition in RUN or ACC, press RCL to recall the radio station frequency and volume setting when the time display is showing.
Page 157 Stereo (AM) Your Delco@ radio can receive C-QUAM@stereo broadcasts. Many AM stations around the country use C-QUAM@to produce stereo, though some do not. If your Delco@ system can get C-QUAM@ signals, your “STEREO” light will come on when you are receiving stereo. (C-QUAM@ is a registered trademark of Motorola Inc.).
Page 158 Then, press and hold the SCAN button until the correct minute appears on the display. After you set the time, the word SET will remain in the electronic display for a few seconds. Cassette Deck with Graphic Equalizer If you have a cassette deck, it is built to work best with tapes that are 30 to 45 minutes long on each side.
Page 159 Cr02 Button For better sound when playing high bias chrome or metal tapes, press the C r 0 2 button. The light in the button will be on while the player is in the C r 0 2 mode. When playing standard tapes, you will get better sound while in the standard mode.
Page 160: Care Of Your Cassette Tape Player
Button REPT Press the REPT button to repeat the currently playing selection on the tape. For the REPT mode to repeat a selection, there must be at least a 4-second gap between selections on the tape. Care of Your Cassette Tape Player A tape player that is not cleaned regularly can result in reduced sound quality, ruined cassettes, or a damaged player mechanism.
Page 161 Your Driving and the Road Here you’ll find information about driving on different kinds of roads and in varying weather conditions . We’ve also included many other useful tips on dsiving ......... . . Defensive Driving .
Page 162: Defensive Driving
Defensive Driving The best advice anyone can give about driving is: Drive defensively. Please start with a very important safety device in your vehicle: Buckle up. (See “Safety Belts” in the Index.) Defensive driving really means “be ready for anything.” On city streets, rural roads, or freeways, it means “always expect the unexpected.”...
Page 163 According to the American Medical Association, a 180-pound (82 kg) person who drinks three 12-ounce end up with a BAC of about 0.06 percent. The person would reach the same BAC by drinking three 4-ounce (120 ml) glasses of wine or three mixed drinks if each had 1-1/2 ounces (45 ml) of a liquor like whiskey, gin or vodka.
Page 164: Control Of A Vehicle
But it’s very important to keep in mind that the ability to drive is affected well below a BAC of 0.10 percent. Research shows that the driving skills of many people are impaired at a BAC approaching 0.05 percent, and that the effects are worse at night.
Page 165: Braking
Sometimes, as when you’re driving on snow or ice, it’s easy to ask more of those control systems than the tires and road can provide, That means you can lose control of your vehicle. Braking Braking action involves perception time and reaction time. First, you have to decide to push on the brake pedal.
Page 166 Anti-Lock Brakes (ABS) Your vehicle has an advanced electronic braking system that can help you keep it under control. When you start your vehicle and begin to drive away, you may hear a momentary motor or clicking noise. This is the ABS system testing itself.
Page 167: Steering
Remember: Anti-lock doesn’t change the time you need to get your foot up to the brake pedal. If you get too close to the vehicle won’t have time to apply your brakes if that vehicle suddenly slows or stops. Always leave enough room up ahead to stop, even though you have anti-lock brakes.
Page 168 What should you do if this ever happens? Ease up on the accelerator pedal, steer the vehicle the way you want it to go, and slow down. Speed limit signs near curves warn that you should adjust your speed. Of course, the posted speeds are based on good weather and road conditions.
Page 169: Off-Road Recovery
Off-Road Recovery You may find sometime that your right wheels have dropped off the edge of a road onto the shoulder while you’re driving. If the level of the shoulder is only slightly below the pavement, recovery should be fairly easy. Ease off the accelerator and then, if there is nothing in the way, steer so that your vehicle straddles the edge of the pavement.
Page 170: Loss Of Control
Watch for traffic signs, pavement markings, and lines. If you can see a sign up ahead that might indicate a turn or an intersection, delay your pass. broken center line usually indicates it’s all right to pass (providing the road ahead is clear). Never cross a solid line on your side of the lane or a double solid line, even if the road seems empty of approaching traffic.
Page 171 Skidding In a skid, a driver can lose control of the vehicle. Defensive drivers avoid most skids by taking reasonable care suited to existing conditions, and by not “overdriving” those conditions. But skids are always possible. The three types of skids correspond to your vehicle’s three control systems. In the braking skid your wheels aren’t rolling.
Page 172: Off-Road Driving With Your Four-Wheel Drive Vehicle
Off-Road Driving with Your Four- Wheel Drive Vehicle This off-road guide is for vehicles that have four-wheel drive. Also, see “Anti-lock Brakes” in the Index. If your vehicle doesn’t have four-wheel drive, you shouldn’t drive off-road unless you’re on a level, solid surface. Off-road driving can be great fun.
Page 173 You’ll find other important information in this manual. See “Vehicle Loading,” “Luggage Carrier” and “Tires” in the Index. Traveling to Remote Areas It makes sense to plan your trip, especially when going to a remote area. Know the terrain and plan your route. You are much less likely surprises.
Page 174 Controlling your vehicle is the key to successful off-road driving. One of the best ways to control your vehicle is to control your speed. Here are some things to keep in mind. At higher speeds: you approach things faster and you have less time to scan the terrain for obstacles.
Page 175 When you drive over bumps, rocks, or other obstacles, your wheels can leave the ground. If this happens, even with one or two wheels, you can’t control the vehicle as well or at all. Because you will be on an unpaved surface, it’s especially important to avoid sudden acceleration, sudden turns, or sudden braking.
Page 176 Here are some other things to consider as you approach a hill. Is there a constant incline, or does the Is there good traction on the hillside, or will the surface cause tire slipping? Is there a straight path up or down the hill so you won’t have to make turning maneuvers? Are there obstructions on the hill that can block your path (boulders, trees, logs or ruts)?
Page 178 vehicle will roll backwards very quickly and you could go out of control. Instead, apply the regular brake to stop the vehicle. Then apply the parking brake. Shift into reverse, release the parking brake, and slowly back straight down. Never attempt to turn around if you are about to stall when going up a hill.
Page 179 If you decide you can go down a hill safely, then try to keep your vehicle headed straight down, and use a low gear. This way, engine drag can help your brakes and they won’t have to do all the work. Descend slowly, keeping your vehicle under control at all times.
Page 180 Driving Across an Incline Sooner or later, an off-road trail will probably go across the incline of a hill. If this happens, you have to decide whether to try to drive across the incline. Here are some things to consider: A hill that can be driven straight up or down may be too steep to drive across.
Page 181 Stalling on an Incline If your vehicle stalls when you’re crossing an incline, be sure you (and yo1 passengers) get out on the uphill side, even if the door there is harder to open. If you get out on the downhill side and the vehicle starts to roll over, you’ll be right in its path.
Page 182 Hard packed snow and ice offer the worst tire traction. On these surfaces, it’s very easy to lose control. On wet ice, for example, the traction is so poor that you will have difficulty accelerating. And if you do get moving, poor steering and difficult braking can cause you to slide out of control.
Page 183: Drivingatnight
After Off-Road Driving Remove brush or debris that has collected on the underbody, chassis or under the hood. These accumulations can be a fire hazard. After operation in mud or sand, have the brake linings cleaned and checked. These substances can cause glazing and uneven braking. Check the body structure, steering, suspension, wheels, tires, and exhaust system for damage.
Page 184: Driving In The Rain
Night Vision No one can see as well at night as in the daytime. But as we get older these differences increase. A 50-year-old driver may require at least twice as much light to see the same thing at night as a 20-year-old. What you do in the daytime can also affect your night vision.
Page 185 less traction. It’s always wise to go slower and be cautious if rain starts to fall while you are driving. The surface may get wet suddenly when your reflexes are tuned for driving on dry pavement. The heavier the rain, the harder it is to see. Even if your windshield wiper blades are in good shape, a heavy rain can make it harder to see road signs and traffic signals, pavement markings, the edge of the road, and even people walking.
Page 186: Citydriving
Hydroplaning Hydroplaning is dangerous. So much water can build up under your tires that they can actually ride on the water. This can happen if the road is wet enough and you’re going fast enough. When your vehicle is hydroplaning, it has little or contact with the road.
Page 187: Freeway Driving
Know the best way to get to where you are going. Get a city map and plan your trip into an unknown part of the city just as you would for a cross-country trip. Try to use the freeways that rim and crisscross most large cities. You’ll save time and energy.
Page 188 Once you are moving on the freeway, make certain you allow a reasonable following distance. Expect When you want to leave the freeway, move to the proper lane well in advance. If you miss your exit do not, under any circumstances, stop and back up.
Page 189: Hill And Mountain Roads
Highway Hypnosis Is there actually such a condition as “highway hypnosis’”? Or is it just plain falling asleep at the wheel‘? Call it highway hypnosis, lack of awareness, or whatever. There is something about an easy stretch of road with the same scenery, along with the hum of the tires on the road, the drone of the engine, and the rush of the wind against the vehicle that can make you sleepy.
Page 190 Keep your vehicle in good shape. Check all fluid brakes, tires, cooling system and transmission. These parts can work hard on mountain roads. Know how to go down hills. The most important thing to know is this: let your engine do some of the slowing down. Shift to a lower gear when you go down a steep or long hill.
Page 191: Winter Driving
Winter Driving Here are some tips for winter driving: Have your vehicle in good shape for winter. Be sure your engine coolant mix is correct. You may want to put winter emergency supplies in your vehicle. Include an ice scraper, a small brush or broom, a supply of windshield washer fluid, a rag, some winter outer clothing, a small shovel, a flashlight, a red cloth, and a couple of reflective warning triangles.
Page 192 What’s the worst time for this? “Wet ice.” Very cold snow or ice can be slick and hard to drive on. But wet ice can be even more trouble because it may offer the least traction of all. You can get “wet ice” when it’s about freezing (32°F;...
Page 193 If You’re Caught in a Blizzard If you are stopped by heavy snow, you could be in a serious situation. You should probably stay with your vehicle unless you know for sure that you are near help and you can hike through the snow. Here are some things to do to summon help and keep yourself and your passengers safe: Turn on your hazard flashers.
Page 194: Powerwinches
Run your engine only as long as you must. This saves fuel. When you run the engine, make it go a little faster than just idle. That is, push the accelerator slightly. This uses less fuel for the heat that you get and it keeps the battery (or batteries) charged.
Page 195: Power Take-Off (Pto)
Power Take-Off (PTO) NOTICE: you will be using the PTO while the vehicle remains in one place, drive the vehicle to warm it Don’t the PTO for more than four hours without driving your vehicle again. If you don’t follow these guidelines, your transfer case or transmission could be damaged.
Page 196: Towingatraile R
Engage the power take-off. If you are going to drive the vehicle, shift the transmission into the gear you want. Then shift the transfer case into the range you want, apply the regular brakes and release the parking brake. 5. Release the clutch (and the regular brakes) as you normally would. When you release the clutch, the power take-off will start.
Page 197 NOTICE: Pulling a trailer improperly can damage your vehicle and result in costly repairs not covered by your warranty. To pull a trailer correctly, follow the advice in this section, and see your GM dealer for important information about towing a trailer with your vehicle.
Page 198 Three important considerations Weight of the Trailer How heavy can a trailer safely be? It depends on how you plan to use your rig. For example, speed, altitude, road grades, outside temperature and how much your vehicle is used to pull a trailer are all important.
Page 199 After you’ve loaded your trailer, weigh the trailer and then the tongue, separately, to see if the weights are proper. If they aren’t, you may be able to get them right simply by moving some items around in the trailer. Total Weight on Your Vehicle’s Tires Be sure your vehicle’s tires are inflated to the limit for cold tires.
Page 200 Trailer Brakes your trailer weighs more than 1,000 pounds (450 kg) loaded, then it needs its own brakes and they must be adequate. Be sure to read and follow the instructions for the trailer brakes so you’ll be able to install, adjust and maintain them properly.
Page 201 During your trip, check occasionally to be sure that the load is secure, and that the lights and any trailer brakes are still working. Following Distance stay at least twice as far behind the vehicle aheau as you would when driving your vehicle without a trailer.
Page 202 Making Turns When you’re turning with a trailer, make wider turns than normal. Do this so your trailer won’t strike soft shoulders, curbs, road signs, trees, or other objects. Avoid jerky or sudden maneuvers. Signal well in advance. Turn Signals When Towing a Trailer When you tow a trailer, your vehicle has to have a different turn signal flasher and extra wiring.
Page 203 Parking on Hills really should not park your vehicle, with a trailer attached, on a hill. If something goes wrong, your rig could start to move. People can be injured, and both your vehicle and the trailer can be damaged. But if you ever have to park your rig on a hill, here’s how to do it: I .
Page 204 When You Are Ready to Leave After Parking on a Hill I. Apply your regular brakes and hold the pedal down while you: Start your engine; Shift into a gear; and Release the parking brake. 2. Let up on the brake pedal. 3.
Page 205 Problems On The Road Here you’ll find what to do about some problems that can occur on the road Hazard Warning Flasher Other Warning Devices ........
Page 206: Hazard Warning Flasher
Hazard Warning Flashers Your hazard warning flashers work no matter what position your key is in, and even if the key isn’t in. When the hazard warning flashers are on, your turn signals won’t work. .?.. , ” . . Your hazard warning flashers let you warn others.
Page 207: Other Warning Devices
Other Warning Devices If you carry reflective triangles, you can use them at the side of the road about 300 feet (100 m) behind your vehicle. Jump Starting If your battery (or batteries) vehicle and some jumper cables to start your vehicle. But please follow the steps below to do it safely.
Page 208 To Jump Start Your Vehicle: 1. Check the other vehicle. It must have a 12-volt battery with a negative ground system. NOTICE: If the other system isn’t a 12-volt system with a negative ground, both vehicles can be damage& If you have a diesel engine vehicle with two batteries (or more), you should know before you begin that, especially in cold weather, you may not be able to get enough power from a single battery in another vehicle to start your diesel engine.
Page 209 5. Check that the jumper cables don’t have loose or missing insulation. If they do, you could get a shock. The vehicles could be damaged, too. Before you connect the cables, here are some basic things you should know. Positive negative metal engine part.
Page 210 6. Connect the red positive vehicle with the dead battery. Use a remote positive vehicle has one. Dead Battery (+) 7. Don’t let the other end touch metal. Connect it to the positive terminal of the good battery. Use vehicle has one. 8.
Page 211: Towingyourvehicle
Attach the cable at least 18 inches but not near engine parts that move. The electrical connection is just as good there, but the chance of sparks getting back to the battery is much less. IO. Now start the vehicle with the good battery and run the engine awhile.
Page 212 Whether you can move the shift lever for thc transmission and transfer case, if you have one. If there was an accident, what was damaged. CAUTION: When your vehicle is being towed, have the ignition key off. The steering wheel should be clamped in a straight-ahead position, with a clamping device designed for towing service.
Page 213 Towing From the Front If you have a two-wheel drive ve.hicle, don’t have your vehicle towed on the rear wheels, unless you must. If the vehicle must be towed on the rear wheels, don’t go more than mph (56 km/h) or farther than 50 miles (80 km) or your transmission will be damaged.
Page 214: Engine Overheating
Towing From the Rear Engine Overheating You will find a coolant temperature gage o n your vehicle instrument panel. If you have a diesel engine, you will also find a low coolant light on your instrument panel. 5-10...
Page 215 If Steam Is Coming From Your Engine NOTICE: If your engine catches fire because you keep driving with no coolant, your vehicle can be badly damaged. The costly repairs would not be covered by your warranty. 5- 11...
Page 216 If No Steam Is Coming From Your Engine If you get the overheat warning but see or hear no steam, the problem may not be too serious. Sometimes the engine can get a little too hot when you: Climb a long hill on a hot day. Stop after high speed driving.
Page 217 If the coolant inside the coolant recovery tank is boiling, don’t do anything else until it cools down. NOTICE: Engine damage from running your engine without coolant isn’t covered by your warranty. If there seems to be no leak, start the engine again. See if the fan speed increases when idle speed is doubled by pushing the accelerator pedal down.
Page 218 How to Add Coolant to the Coolant Recovery Tank If you haven’t found a problem yet, but the coolant level isn’t at or above the COLD mark, add a 50/50 mixture of clean water (preferably distilled) and a proper antifreeze at the coolant recovery tank. (See “Engine Coolant” in the Index for more information about the proper coolant mix.) NOTICE: In cold weather, water can freeze and crack the engine, radiator,...
Page 219 When the coolant in the coolant recovery tank is at or above the COLD mark, start your vehicle. If the overheat warning continues, there’s one more thing you can try. You can add the proper coolant mix directly cool before you do it. cooling system the radiator but be sure the 5-15...
Page 220 How to Add Coolant to the Radiator 1. You can remove the radiator pressure cap when the cooling system, including the radiator pressure cap and upper radiator hose, is no longer hot. Turn the pressure cap slowly to the left until it first stops. (Don't press down while turning the pressure cap.) If you hear a hiss, wait for that to stop.
Page 221 3. Fill the radiator with the proper mix, up to the base of the filler neck. 4. Then fill the coolant recovery tank to the COLD mark. Put the cap back on the coolant recovery tank, but leave the radiator pressure cap off.
Page 222 7. By this time the coolant level inside the radiator filler neck may be lower. If the level is lower, add more of the proper mix through the filler neck until the level reaches the base of the filler neck. Cooling System -Diesel Engines ."...
Page 223 CAUTION: If’ your vehicle has air conditioning, the auxiliary electric fan under the hood can start up even when the engine is not running and can injure you. Keep hands, clothing and tools away from any underhood electric fan. If the coolant inside the coolant surge tank is boiling, don’t do anything else cools down.
Page 224 How to Add Coolant to the Coolant Surge Tank If you haven’t found a problem yet, but the coolant level isn’t at the COLD mark add a 50/50 mixture of clean water (preferably distilled) and a proper antifreeze at the coolant surge tank, but be sure the cooling system, including the coolant surge tank pressure cap, is cool before you do it.
Page 225 In cold weather, water can freeze and crack the engine, radiator, heater core and other parts. So use the recommended coolant. 1. You can remove the coolant surge tank pressure cap when the cooling system, including the coolant surge tank pressure cap and upper radiator hose, is no longer hot.
Page 226 Turn the pressure cap slowly to the left until it first stops. (Don’t press down while turning the pressure cap.) If you hear a hiss, wait for that to stop. A hiss means there is still some pressure left. Then keep turning the cap, but now push down as you...
Page 227 While filling the surge tank, watch to see if coolant begins to stream out the air bleed valve. When coolant begins to stream out, close the valve. 5-23...
Page 228: Enginefannoise
Engine Fan Noise Your vehicle has a clutched engine cooling fan. When the clutch is engaged, the fan spins faster to provide more air to cool the engine. In most every day driving conditions the fan is spinning slower and clutch is not fully engaged. This improves fuel economy and reduces fan noise.
Page 229: Changing A Flat Tire
Changing a Flat Tire If a tire goes flat, avoid further tire level place. Turn on your hazard warning flashers. Blocked Tire The equipment you’ll need is located in the rear cargo area. You’ll also find your spare tire there. and wheel damage by driving slowly to a 5 -25...
Page 230 Spare Tire First open the tire cover, if y o u have one. Turn the wing takc and the adapter, off the bolt. Take the tire remove the tire cover. Jack and Tools -Utility Models Your spare tire mounted on the driver side inside cargo area wall, at the rear of the vehicle...
Page 231 Your vehicle may have a pair of emergency gloves secured to the jack. You can use them when changing the tire, or during other emergency situations. Remember to replace them with the jack, so you will have them handy if needed later.
Page 232 Your vehicle may have a pair of emergency gloves secured to the jack. You can use them when changing the tire, or during other emergency situations. Remember to replace them with the jack, so you will have them handy if needed later.
Page 233: Jackstorage
Jack Storage Utility Models 1. Retainer 2. Nut 3. Jack Secure Jack in Vehicle as Shown Jack Storage Wagon Models 1. Retainer 2. Nut 3. Jack Secure Jack in Vehicle as Shown 4. Jack Storage Box 5. Bracket. 4. Jack Storage Box 5.
Page 234 UP Marking The ratchet has an UP and a DOWN marking. Start with the jack, the jack handle and the ratchet. If the flat tire is on the rear of the vehicle, you'll need the jack handle extensions a1 so. Attach the jack handle (and jack handle extensions, if needed)
Page 235 That will lift the jack head a little. Before raising the vehicle, do the following things. Put your spare tire near the flat tire. Remove the wheel trim. Be careful; the rim edges may be sharp. Don't try to remove it with your bare hands.
Page 236 Then take the hub cap off. If the wheel has a trim ring, remove it by using the flat end of the wheel wrench. If your vehicle has wheel nut caps, use the wheel wrench and ratchet, with DOWN facing you, to unscrew and take them off.
Page 237 CAUTION: Getting under vehicle when it slips off the jack, you could be badly injured or killed. vehicle Never get under a vehicle when it is supported only by a jack. NOTICE: Raising your vehicle with the jack improperly positioned damage the vehicle or may allow the vehicle to fall off the jack.
Page 238 Rust or dirt on the wheel, or on the parts to which it is fastened, can make the wheel nuts become loose after a time. The wheel could come off and cause an accident. When you change a wheel, remove any rust or dirt from the places where the wheel attaches to the vehicle.
Page 239 CAUTION: Never use oil or grease on studs or nuts. If you do, the nuts might come loose. Your wheel could fall off, causing accident. Front Position Lower the vehicle by rotating the ratchet to the left. Lower the jack completely.
Page 240 Tighten to the Left Tighten the nuts firmly in a criss-cross sequence as shown. Rotate the ratchet to the right with the UP marking facing you. CAUTION: Incorrect wheel nuts or improperly tightened wheel nuts can cause the wheel to become loose and even come off. This could lead an accident.
Page 241 Storing the Jack and Tire Storing the Jack Put the tools into the storage box and close it tightly. Fit the storage box into the bracket with the bolt through the box. Put the jack onto the box. Be sure the jack points in the right direction as shown for your model.
Page 242 Storing the Tire Be sure the J-bolt is hooked properly for your model or tire size Tire Storage -Wagon Model If you have a wagon model, use these locations. 1. I-Bolt 2. J-Bolt 3. Carrier 4. Spare Tire 5 . Adapter 7.
Page 243 Tire Storage -Utility Model If you have a utility model, use these locations. 1. Carrier 2. J-Bolt 3. Adapter 4. Spare Tire 5. Nut Put the cover back on the tire if your vehicle has one. Put the tire into the vehicle, over the bolt. Slide the adapter onto the bolt in the proper location for your model, and put the wing nut on.
Page 244: If You're Stuck: In Sand. Mud. Ice Or Snow
If You’re Stuck: In Sand, Mud, Ice or Snow What you don’t want to do when your vehicle is stuck is to spin your wheels. The method known as “rocking” can help you get out when you’re stuck, but you must use caution. NOTICE: Spinning your wheels can destroy parts of your vehicle as well as the tires.
Page 245 If you ever get stuck in sand, mud, ice or snow, your vehicle may be equipped with recovery hooks. The recovery hooks are provided at the front of your vehicle. You may need need to be pulled to some place where you can continue driving. CAUTION: The recovery hooks, when used, are under a lot of force.
Page 246 NOTICE: Never use the recovery hooks to tow the vehicle. Your vehicle could be damaged and it would not be covered by warranty. 5-42...
Page 247 Service & Appearance Here you will find information about the care of your vehicle . This section begins with service and fuel information. and then it shows how to check important fluid and lubricant levels about your vehicle. and a section devoted to its appearance care . Service .
Page 248 Brake Master Cylinder Replacing Brake System Parts Other Maintenance Items ..........Lubrication .
Page 249: Service
Service Your GM dealer knows your vehicle best and wants you to be happy with it. We hope you’ll go your dealer for all your service needs. You’ll get genuine GM parts and GM-trained and supported service people. We hope you’ll want to keep your GM vehicle all GM. Genuine GM parts have one of these marks: Doing Your Own Service Work If you want to do some...
Page 250: Fuel (Gasoline Engines)
Maintenance Schedule Section 7 of this manual, “Scheduled Maintenance Services”, explains the maintenance your new vehicle needs, and when it should be done. It also has a form that you can use to record the maintenance work done on your vehicle.
Page 251: Diesel Fuel Requirements And Fuel System
Gasolines for Cleaner Air lour use of gasoline with deposit control additives will help prevent deposits from forming in your engine and fuel system. That helps keep your engine in tune and your emission control system working properly. It’s good for your vehicle, and you’ll be doing your part for cleaner air.
Page 252 What Fuel to Use For best results, use number 2-D diesel fuel year-round (above and below freezing conditions) as oil companies blend number 2-D fuel to address climate differences. Numer 1-D diesel fuel may be used in below freezing weather, however, it will produce a power and fuel economy loss. The use of number 1-D diesel fuel in warm or hot climates may result in stalling, poor starting when the engine is hot and may damage the fuel injection system.
Page 253 Water Fuel Sometimes, water can be pumped into your fuel tank along with your diesel fuel. This can happen if a service station doesn’t regularly inspect and clean its fuel tanks, or if it gets contaminated fuel from its suppliers. If this happens, a “WATER IN FUEL”...
Page 254 To drain water: 1. Stop and park the vehicle in a safe place. Turn off the engine and apply the parking brake. 2. Remove the fuel tank cap. 3. Place a fuel-resistant container under the filter drain hose. 5. Start the engine and allow it to idle until clear fuel is observed. 6 .
Page 255 NOTICE: If there is water in your diesel fuel and the weather is warm or humid, fungus and bacteria can grow in the damage your fuel system. You’ll need sterilize your fuel system. Your dealer can advise you if you ever need this.
Page 256 CAUTION: Diesel fuel is flammable. engine parts. You could be burned. Don’t let too much fuel flow from the air bleed valve, and wipe up any spilled fuel with a cloth. Close the air bleed valve. 4. Turn the ignition key to “Start” for 10 to 15 seconds at a time until your engine starts.
Page 257 ..8. With the air bleed valve open, turn your ignition key to START for 10 to 15 seconds. Wait one minute for your starter to cool. Do this until you can see clear fuel coming from the air bleed valve. Unscrew and remove the ring nut from the top...
Page 258 Close the air bleed valve and replace the fuel cap. Start your engine and let it idle for five minutes. Check your fuel filter and air bleed valve for leaks. Fuels in Foreign Countries If you plan on driving in another country outside the U.S. or Canada, unleaded fuel may be hard to find, Do not use leaded gasoline.
Page 259 Be careful not to spill gasoline. Clean gasoline from painted surfaces as soon as possible. See “Cleaning the Outside of Your Vehicle” in the Index. When you put the cap back on, turn it to the right until you hear a clicking noise.
Page 260: Checking Things Under The Hood
Checking Things Under the Hood Hood Release To open the hood, first pull the handle inside the vehicle. Then go to the front of the vehicle and pull up on the secondary hood release, located just to the passenger side of the center of the grill.
Page 261: Cleaning Your Diesel Engine
Before closing the hood, be sure all filler caps are on properly. Pull down the hood and close it firmly. Cleaning Your Diesel Engine NOTICE: If you spray or pour water or any other liquid on your engine when it is warm or hot, or when it is running, you could cause serious damage to it.
Page 262: Engine Oil (Except Diesel)
Engine Oil (Except Diesel) It’s a good idea to check your engine oil every time you get fuel. In order to get an accurate reading, the oil must be warm and the vehicle must be on level ground. To Check Engine Oil h l l out the dipstick and clean it with a paper towel or cloth, then push it back in all the way.
Page 263 NOTICE: Don’t add too much oil. If your engine has so much oil that the oil level gets above the upper mark that shows the proper operating range, your engine could be damaged. Just fill it enough to put the level somewhere in the proper operating range. Push the dipstick all the way back in when you’re through.
Page 264 should look for this on the front that display this new symbol. You should also use the proper viscosity oil for your vehicle, as shown in the following chart: LIGHT DUTY EMISSIONS -GAS ENGINES RECOMMENDED SAE VISCOSITY GRADE ENGINE OILS FOR BEST FUEL ECONOMY AND COLD STARTING, SELECT THE LOWEST SAE VISCOSITY GRADE OIL FOR THE EXPECTED TEMPERATURE RANGE.
Page 265 HEAVY DUTY EMISSIONS -GAS ENGINES RECOMMENDED SAE VISCOSITY GRADE ENGINE OILS FOR BEST FUEL ECONOMY AND COLD STARTING, SELECT THE LOWEST SAE VISCOSITY GRADE OIL FOR THE EXPECTED TEMPERATURE RANGE. WEATHER "F "C tlOO + 6 0 + 4 0 - + 4 - - 7 .-18...
Page 266 If you cannot find oils with the new “starburst” symbol on the front of the container, should look for and use oils containing the following three things: S H o r S G “SH” or “SG” must be on the oil container, either by itself or combined with other quality designations, such as “SHKD,”...
Page 267 Engine Oil Additives Don’t add anything to your oil. Your GM dealer is ready to advise if you think something should be added. When to Change Engine Oil See if any one of these is true for you: Most trips are less than 4 miles It’s below freezing outside and most trips are less than 10 miles (16 km).
Page 268: Engine Oil (Diesel Engines)
Used oil can be a real threat to the environment. If you change your own oil, be sure to drain all free-flowing oil from the filter before disposal. dispose of oil by putting it in the trash, pouring it on the ground, into sewers, or into streams or bodies of water.
Page 269 When to Add Oil If the oil is at or below the ADD line, then you must use the right kind. This section explains what kind of oil to use. For crankcase capacity, see “Capacities and Specifications” in the Index. NOTICE: Don’t add too much oil.
Page 270 What Kind of Oil to Use Look for these two things: CF-4/SH C F 4 S H is the best oil for your vehicle. However, if you can not find CF-4/SH oil, you may use CF-4/SG or CE/SH or CE/SG oil. These may be listed as shown or in reverse order, for example SHKF-4.
Page 271 DIESEL ENGINES SELECT THE SAE GRADE OIL BASED THE EXPECTED TEMPERATURE RANGE WEATHER +60 - - + 1 6 COLD WEATHER SAE 15W-40 As shown in the viscosity chart, SAE 15W-40 is best for your vehicle. However, you can use SAE 1OW-30 if it's going to be colder than 32°F (OOC) before your next oil change.
Page 272 This doughnut-shaped logo (symbol) is used on most oil containers to help you select the correct oil. You should look for this on the oil container, and use only those oils that display the logo. GM Goodwrench@ oil (in Canada, GM Engine Oil) meets all the requirements for your vehicle.
Page 273: Aircleaner
Air Cleaner NOTICE: If the air cleaner is off, a backfire can cause a damaging engine fire. And, dirt can easily get into your engine, which will damage it. Always have the air cleaner in place when you’re driving. Refer to the Maintenance Schedule to determine when to replace the air filter.
Page 274: Automatic Transmission Fluid
To remove the air cleaner filter on a 6.5 liter turbocharged diesel, first remove the rubber elbow. Remember to observe the caution about turbocharger blades on the rubber elbow. A utomafic Transmission Fluid When Check and Change A good time to check your automatic transmission fluid level is when the engine oil is changed.
Page 275 NOTICE: Too much or too little fluid can damage your transmission. Too much can mean that some of the fluid could come out and fall hot engine parts or exhaust system, starting a fire. Be sure to get an accurate reading if you check your transmission fluid. Wait at least 30 minutes before checking the transmission fluid level if you have been driving: When outside temperatures are above 90°F (32°C).
Page 276 2. Push it back in all the way, wait three seconds and then pull it back out again. 1. Flip the handle up and then pull out the dipstick and wipe it with a clean rag or paper towel. 3. Check both sides of the dipstick, and read the lower level.
Page 277: Manual Transmission Fluid
How to Add Fluid Refer to the Maintenance Schedule to determine what kind of transmission use. fluid to See “Recommended Fluids and Lubricants” in the Index. If the fluid level is low, add only enough of the proper fluid to bring the level up to the COLD area for a cold check or the HOT area for a hot check.
Page 278: Hydraulic Clutch
Then, follow these steps: 1. Remove the filler plug. 2. Check that the lubricant level is up to the bottom of the filler plug hole. 3. If the fluid level is good, install the plug and be sure it is fully seated. If the fluid level is low, add more fluid as described in the next steps.
Page 279: Rearaxle
When to Check and What to Use See “Owner Checks and Services” and “Recommended Fluids and Lubricants” in the Index. How to check The proper fluid should be added if the level does not reach the bottom of the diaphragm when it’s in place in the reservoir. See the instructions on the reservolr cap.
Page 280: Transfer Case
What to Use the Maintenance Schedule to determine what kind of lubricant to Refer use. See “Recommended Fluids and Lubricants” in the Index. Four- Wheel Drive Most lubricant checks in this section vehicles. However, they have two additional systems that need lubrication. Transfer Case When to Check Lubricant Refer to the Maintenance Schedule to determine how often to check the...
Page 281: Frontaxle
Front Axle When to Check and Change Lubricant Refer to the Maintenance Schedule to determine how often to check the lubricant and when to change the Index. How to Check Lubricant If the differential is cold, add enough lubricant to raise the level to 1/2 inch 2 mm) below the filler plug hole.
Page 282 What to Use Use a mixture of one-half clean wuter (preferably distilled) and one-half antifreeze that meets “GM Specification 6038-M,” which won’t damage aluminum parts. You can also use a recyc1e.d coolant conforming to “GM 6038-M” Specification this mixture, you don’t need to add anything else. NOTICE: If you use an improper coolant mix, your engine could overheat and be badly damaged.
Page 283 Adding Coolant -Gas Engines To Check Coolant When your engine is cold, the coolant level should be at COLD, or a little higher. When your engine is warm, the level should be up to higher. To Add Coolant If you need more coolant, add the proper mix at the coolant recovery tank.
Page 284 Adding Coolant -Diesel Engines " > C C To Check Coolani When your engine is cold, the coolant level should be at the or a little higher. When your engine is warm, the level should be above the COLD mark. To Add Coolant If you need more coolant, add the proper mix ut the surge tank, but only when the engine is cool.
Page 285 Radiator Pressure Cap-Gas Engines NOTICE: Your radiator cap is a 15 psi (105 kPa) pressure-type cap and must be tightly installed to prevent coolant loss and possible engine damage from overheating. Be sure the arrows on the cap line up with the overflow tube on the radiator filler neck. The radiator pressure cap must be tightly installed with the...
Page 286: Power Steering Fluid
Surge Tank Pressure Cap- Diesel Engines NOTICE: Your surge tank pressure cap is a unique 15 psi (105 kPa) pressure-type cap for use with surge tank cooling systems only. It must be tightly installed to prevent coolant engine damage from overheating. Be sure the arrows on the cap line up with the top tube of the coolant surge tank.
Page 287 How To Check Power Steering Fluid What to Add Refer to the Maintenance Schedule to determine what kind of fluid to use. See “Recommended Fluids and Lubricants’’ in the Index. NOTICE: When adding power steering fluid or making a complete fluid change, always use the proper fluid.
Page 288: Windshield Washer Fluid
Hydro-Boost Brake System (Hydraulic Pump) The power steering pump is also used as the Hydro-boost pump. Refer to “Power Steering System” in this section when checking fluid level or adding fluid. Windshield Washer Fluid To Add NOTICE: When using concentrated washer fluid, follow the manufacturer’s instructions for adding water.
Page 289: Brake Master Cylinder
Brakes Brake Master Cyrinder There are only two reasons why the brake fluid level in your master cylinder might go down. The first is that the brake fluid goes down to an acceptable level during normal brake lining wear. When new linings are put in, the fluid level goes back up.
Page 290 To Check Brake Fluid After work is done on the brake hydraulic system, make sure the levels are above “MIN” and below the top of each window. What to Add When you do need brake fluid, use only DOT-3 brake fluid Delco Supreme 11 sealed container only, and always clean the brake fluid reservoir cap before removing it.
Page 291 Brake Wear Your vehicle has front disc brakes and rear drum brakes. Disc brake pads have built-in wear indicators that make a high-pitched warning sound when the brake pads are worn and new pads are needed. The sound may come and go or be heard all the time your vehicle is moving (except when you are pushing on the brake pedal firmly).
Page 292: Replacing Brake System Parts
Replacing Brake System Parts The braking system on a modern vehicle is complex. Its many parts have to be of top quality and work well together if the vehicle is to have really good braking. Vehicles we design and test have top-quality GM brake parts them, as your vehicle does when it is new.
Page 293 Wheel Nut Torque For vehicles with dual wheels, when the vehicle, wheel or fasteners are new, have the torque set at the first 100, 1,000 and 6,000 miles (160, 1600 and 9600 km). Use the torque specified in the appropriate Specification Chart later in this section.
Page 294: Lubrication
Fluid Leak Check After the vehicle has been parked for a while, inspect the surface under the vehicle for water, oil, fuel or other fluids. Water dripping from the air conditioning system after it has been used is normal. If you notice fuel leaks or fumes, the causes should be found and corrected at once.
Page 295 Your maintenance schedule will tell you how often to lubricate these items. See “Recommended Fluids and Lubricants” in the Index for the proper lubricant to use. Lock Cylinders To be sure your locks operate properly, they must be lubricated. Your vehicle’s maintenance schedule will tell you how often to lubricate them.
Page 296: Bulb Replacement
Bulb Replacement Before you replace any bulbs, be sure that all the lights are off and the engine isn’t running. Sealed Beam Headlights Halogen Bulbs 1. Remove the four screws from the headlight retainer. 2 . Pull the headlight out and remove the retainer.
Page 297 NOTICE: Avoid touching the bulb or letting it come in contact with anything damp. Oil from your skin or moisture on the bulb can cause the bulb explode when it is turned contact with the bulb, clean it with alcohol degreaser and wipe the bulb dry.
Page 298 Front Parkingflurn Signal Lights with Sealed Beam Headlights I . Remove the two screws at the inside edge of the parkingkurn signal light assembly. 2. Remove the light assembly by swinging sliding it out at the outside edge. Squeeze the tab on the side of the light socket while turning the socket to the left.
Page 299 5. Put the new bulb in the socket, gently press in on the bulb and turn it to the right until it 6. Put the socket back into the light assembly and turn it socket to the right until it locks. 7.
Page 300 Put the socket back into the side marker assembly and turn it to the right to tighten it. 6. Replace the parkinghrn signal light assembly and tighten the screws. Roof Marker Lights 3. Put a new bulb into the socket and push it in until it is tight. 4.
Page 301 Center High Mount Stoplamp (CHMSL) Rear Lights 1 . Open the tailgate or rear doors. 2. Remove the two black plastic plugs in the rear light assembly access The individual bulbs in the CHMSL are not replaceable. See your dealer for assistance. 3.
Page 302: Fuses And Circuit Breakers
6. Put in a new bulb and push it in until it is tight. 7. Replace the bulb retainer. Replace the rear light assembly and tighten the screws. You may want to use a magnetic screwdriver when installing the screws. Close the tailgate or rear doors.
Page 303 Power Windows and Other Power Options Circuit breakers in the fuse panel protect the power windows and other power accessories. When the current load is too heavy, the circuit breaker opens and closes. This protects the circuit until the current load returns to normal or the problem is fixed .
Page 304: Exhaust System
some feature of your vehicle that you can get along without-like or cigarette lighter-and use it as soon as you can. See “Fuses and Circuit Breakers” more information. Exhaust System To help prevent damage to your exnaust system, do not continue to drive your vehicle if you notice: Engine misfiring Loss of performance...
Page 305: Loading Your Vehicle
Malfunction Indicator (SERVICE ENGINE SOON) Lamp The Malfunction Indicator (SERVICE ENGINE SOON) Lamp on your instrument panel lets you know when your emission system needs service. The light will come on briefly when you start your engine to let you know that the system is working.
Page 306 Never exceed the GVWR for your vehicle, or the GAWR for either the front axle. rear And, if you do have a heavy load, you should spread it out. Using heavier suspension components to get added durability might not change your weight ratings, Ask your dealer to help you load your vehicle the right way.
Page 307 Trailering Package If your vehicle comes with the Trailering Package, there is also a load rating which includes the weight of the vehicle and the trailer it tows. This rating is called the Gross Combination Weight Rating (GCWR). When you weigh your trailer, be sure to include the weight of everything you put in it.
Page 308: Tires
Tires We don’t make tires. Your new vehicle comes with high quality tires made by a leading tire manufacturer. These tires are warranted by the tire manufacturers and their warranties are delivered with every new vehicle. If your spare tire is a different brand than your road tires, you will have a tire warranty folder from each of these manufacturers.
Page 309 You can operate some vehicles at reduced inflation pressures only when you’ll be carrying reduced loads. On those vehicles, the minimum cold inflation pressures for a typical reduced load are printed on the “Improved Ride Tire Pressure” label located on the driver’s door. Weigh the vehicle to find the load on each tire and see the label for the minimum cold inflation Dressures for that load.
Page 310: Tire Inspection And Rotation
Special Tire Inflation If you have 16 inch tires on your vehicle, and: You’ll be driving for very long at speeds of 66 mph (105 km/h) to 75 mph (120 km/h) where legal, inflate tires to 10 psi (70 kPa) more than the recommended cold inflation pressures.
Page 311: When It's Time For New Tires
It’s When Time for New Tires You need a new tire if You can see the indicators at three or more places around the tire. You can see cord or fibric showing through the tire’s rubber. The tread or sidewall is cracked, cut or snagged deep enough to show cord or fabric.
Page 312: Buying New Tires
Buying New Tires To find out what kind and size of tires you need, look at the CertificationRire label. The tires installed on your vehicle when it was new had a Tire Performance Criteria Specification (TPC Spec) number on each tire’s sidewall. When you get new tires, get ones with that same TPC Spec number.
Page 313: Wheel Alignment And Tire Balance
Traction A, B, C The traction grades, from highest to lowest are: A, B, and C. They represent the tire’s ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete. A tire marked C may have poor traction performance.
Page 314: Wheel Replacement
Wheel Replacement Replace any wheel that is bent, cracked or badly rusted. If wheel nuts keep coming loose, the wheel, wheel bolts, and wheel nuts should be replaced. If the wheel leaks air, replace it (except some aluminum wheels, which can sometimes be repaired).
Page 315: Tirechains
Tire Chains NOTICE: If your vehicle has LT265/75R16 size tires, don’t use tire chains; they can damage your vehicle. you have a tire size other than LT265/75R16, use tire chains only where legal and only when “S” type chains that are the proper them on the tires of the rear axle.
Page 316: Cleaning The Inside Of Your Vehicle
Never use these to clean your vehicle: Gasoline Benzene Naphtha Carbon Tetrachloride Acetone They can all be hazardous damage your vehicle, too. NOTICE: Don’t use any of these unless this manual says you can. In many uses, these will damage your vehicle: Laundry Soap Bleach Reducing Agents...
Page 317 Using Foam-Type Cleaner on Fabric Vacuum and brush the area to remove any loose dirt. Always clean a whole trim panel or section. Mask surrounding trim along stitch or welt lines. Mix Multi-Purpose Powdered Cleaner following the directions on the container label.
Page 318 Fabric Protection Your vehicle has upholstery and trim carpet that has been treated with Scotchgard Fabric Protector, by repelling oil and water, which are the carriers of most stains. Even with this protection, you still need to clean your upholstery and trim carpet often to keep it looking new.
Page 319 Cleaning Vinyl Use warm water and a clean cloth. Rub with a clean, damp cloth to remove dirt. You may have to do it more than once. Things like tar, asphalt and shoe polish will stain if you don’t get them off quickly.
Page 320: Cleaning The Outside Of Your Vehicle
Glass Glass should be cleaned often. GM Glass Cleaner (GM Part No. 1050427) or a liquid household glass cleaner will remove normal tobacco smoke and dust films. Don’t use abrasive cleaners on glass, because they may cause scratches. Avoid placing decals on the inside rear window, since they may have to be scraped off later.
Page 321 Finish Care Occasional waxing or mild polishing of your vehicle may be necessary to remove residue from the paint finish. You can get GM approved cleaning products from your dealer. (See “Appearance Care and Materials” in the Index Your vehicle may have a “basecoat/clearcoat” paint finish. The clearcoat gives more depth and gloss to the colored basecoat.
Page 322 Weatherstrips Silicone grease on weatherstrips will make them last longer, seal better, and not stick or squeak. Apply silicone grease with a clean cloth at least every six months. During very cold, damp weather more frequent application may be required. (See “Recommended Fluids & Lubricants” in the Index.) Sheet Metal Damage If your vehicle is damaged and requires sheet metal repair or replacement, make sure the body repair shop applies anti-corrosion material to the parts...
Page 323: Appearance Care Materials
Although no defect in the paint job causes this, GM will repair, at no charge to the owner, the surfaces of new vehicles damaged by this fallout condition within I2 months or 12,000 miles (20 000 km) of purchase, whichever comes first.
Page 324: Vehicle Identification Number
Vehicle Identification Number (VIN) This is the legal identifier for your vehicle. It appears on a plate in the front corner of the instrument panel, on the driver’s side. You can see it if you look through the windshield from outside your vehicle. The VIN also appears on the Vehicle Certification and Service Parts labels and the certificates of title and registration.
Page 325 Engine Identification The eighth character in your VIN is the engine code. This code will help you identify your engine, specifications, and replacement parts. - ' - 6-79...
Page 326: Service Parts Identification Label
Service Parts Identification Label You’ll find this label on the inside of the glove box. ooO0ooooooMH)woo VEHICLE IDENTIFICATION ARL A02 A65 B6Y B9A B9K NUMBER K19 K64 LC3 MXl M31 NA5 6BJ 62L 62U 670 671 679 PAINTTECHNOLOGY It’s very helpful if you ever need to order parts. On this label your VIN, the model designation, paint information, and...
Page 327: Specification Charts
Specification Charts Replacement Parts Replacement part numbers listed in this section are based on the latest information available at the time of printing, and are subject to change. If a part listed in this manual is not the same as the part used in your vehicle when it was built, or if you have any questions, please contact your GM truck dealer.
Page 328 Cooling System Capacity ENGINE 5.7L 6.5L 6.5L 7.4L After refill, the level MUST be checked as outlined under “Engine Cooling System” in Section 5. *All quantities are approximate. Crankcase Capacity ENGINE 5.7L 6.5L 6.5L F3‘ 7.4L After refill, the level MUST be checked as outlined under “Engine Oil And Filter Recommendations’’...
Page 329 Service Replacement Parf and Filfer Recommendafions -Gas Engines Engine Oil Filter Air Cleaner Filter PCV Valve Spark Plugs*’ Fuel Filter Radiator Cap I-Four Wheel Drive Vehicle -use *Use AC copper-cored resister type spark plugs Service Replacemenf Parf and FiRer Recommendafions -Diesel Engines Engine Oil Filter Air Cleaner...
Page 330 Fuse Block 7.5 AMP BROWN 10 AMP 15 AMP BLUE 6-84...
Page 331 Fuses and Circuit Breakers CIRCUITS PROTECTED NAME Cruise Control, 4 WD Display Gages Illum. Rear Window Defogger Timer, Aux. Batt. Relay Feed, Safety Belt Buzzer Timer, Cluster Ign. Feed Turn-BAJ Back-up Lamps, Turn Signals T.C.C., Air Diverter, E.S.C., EMC/Ign E.G.R., E.C.M. Ign. R.W.A.L. Brake Switch Inj.
Page 332 Lamp and Bulb Data LAMP OR BULB TRADE HEADLAMPS 2 Headlamp System Halogen (Opt.) 4 Headlamp System Composite LAMP OR BULB EXTERIOR Front Marker Lamp Front Park and Turn Lamp Rear Parking Lamp Rear Stop and Turn Lamp Backup Lamp Roof Marker Lamp* License Plate Lamp Underhood Lamp...
Page 333 LAMP OR BULB INSTRUMENT P ANEL Transmission Indicator (PRNDL) Daytime Running Lights Indicator? Charging System Indicator Lamp Instrument Cluster Illumination -Gage Cluster Instrument Cluster Illumination -Txhometer Cluster Headlamp Beam Indicator Directional Signal Indicator Brake Warning Indicator Safety Belt Warning Check Gages Indicator Malfunction Indicator ("Service Engine Soon") Lamp Upshift Indicator...
Page 334 Notes...
Page 335 Scheduled Maintenance This section covers the maintenance required for your General Motors vehicle . Your vehicle needs these services to retain it’s safety. dependability and emission control performance A Word About Maintenance Your Vehicle and the Environment ......Recording Maintenance Services Scheduled Maintenance Services Selecting Your Vehicle’s Maintenance Services .
Page 336: A Word About Maintenance
A Word About Maintenance We at General Motors want to help you keep your vehicle in good working condition. But we don’t know exactly how you’ll drive it. You may drive very short distances only a few times a week. Or you may drive long distances all the time in very hot, dusty weather.
Page 337: Scheduled Maintenance Services
If you are skilled enough to do some work on your vehicle, you will probably want to get the service information GM publishes. For information on how to obtain various service publications for your vehicle, see “Service Publications” in the Index. You will find a list of publications and an order form in the back of the book.
Page 338 Engine Emissions Classification Engine Type Fuel System Emissions '"Light Duty Emissions with 8500 GVWR and below or: *"Heavy Duty Emissions with 8501 GVWR and above +Throttle Body Injection Engine Emissions Classification Engine Type Fuel System Emissions Gas Engines Diesel Engines 6.5L Turbo Diesel 6.5L...
Page 339: Maintenance Schedule I
Selecting the Proper Maintenance Schedule Here is how to tell which schedule to follow once you find the proper maintenance chart to use. MAINTENANCE SCHEDULE I Is any one of these true for your vehicle? Most trips are less than 4 miles (6 kilometers.) Most trips are less than 10 miles (1 6 kilometers), and the outside temperatures are below freezing.
Page 340 GASOLINE ENGINES WITH LIGHT DUTY EMISSIONS MAINTENANCE SCHEDULE Item Service Engine Oil Change*-Every 3 Months, or Oil Filter Change*-Every Chassis Lubrication-Every 3 Clutch Fork Ball Stud Lubrication (5-speed manual transmission with deep-low only) 4 Cooling System Service *-Every 24 Months 5 Air Cleaner Filter Replacement* 6 Front Wheel Bearing Repack 7 Transmission Service...
Page 341 GASOLINE ENGINES WITH LIGHT DUTY EMISSIONS MAINTENANCE SCHEDULE THE SERVICES SHOWN ON THIS CHART UP TO 60,000 MILES (100 000 km) ARE TO BE DONE AFTER 60,000 MILES AT THE SAME INTERVALS. T0402/T0902 (continued)
Page 342 GASOLINE ENGINES WITH LIGHT DUTY EMISSIONS MAINTENANCE SCHEDULE ltf An Emission Control Service See “Explanation of Scheduled Maintenance Services” in the Index. $ The California Air Resources Board has determined that the failure to perform this maintenance item will not nullify the emission warranty or limit recall liability prior to the completion of vehicle useful life.
Page 343 GASOLINE ENGINES WITH LIGHT DUTY EMISSIONS MAINTENANCE SCHEDULE l u (continued) THE SERVICES SHOWN ON THIS CHART UP TO 60,000 MILES (100 000 km) ARE TO BE DONE AFTER 60,000 MILES AT THE SAME INTERVALS. T0403aTT0903a...
Page 344 GASOLINE ENGINES WITH HEAVY DUTY EMISSIONS MAINTENANCE SCHEDULE ff An Emission Control Service See “Explanation of Scheduled Maintenance Services” i t A Noise Emission Control Service Applicable only to vehicles sold in the United States To determine the emissions classification of your engine, Maintenance Chart”...
Page 345 GASOLINE ENGINES WITH HEAVY DUTY EMISSIONS MAINTENANCE SCHEDULE (continued) THE SERVICES SHOWN ON THIS CHART UP TO 60,000 MILES (100 000 km) ARE TO BE DONE AFTER 60,000 MILES AT THE SAME INTERVALS. TO405 7-11...
Page 346 GASOLINE ENGINES WITH HEAVY DUTY EMISSIONS MAINTENANCE SCHEDULE / I f An Emission Control Service See “Explanation of Scheduled Maintenance Services” in the Index. A Noise Emission Control Service Applicable only to vehicles To determine the emissions classification of your engine, refer to “Selecting the Proper Maintenance Chart’’...
Page 347 GASOLINE ENGINES W/TH HEAVY DUTY EM/SSIONS MAINTENANCE SCHEDULE lu (continued) THE SERVICES SHOWN ON THIS CHART UP TO 60,000 MILES (100 000 km) ARE TO BE DONE AFTER 60,000 MILES AT THE SAME INTERVALS. TO407...
Page 348: Diesel Engines
DIESEL ENGINES Inspection* Tire Rotation** and Wheel 25 Brake Systems Inspection** Change filter every 15,000 miles (24 000 km), except when operating in dusty conditions. Dusty conditions may require more frequent filter replacement. Extreme dust and dirt operating conditions (off-road), may require the air filter to be checked as often as every 300 miles (483 km) and replaced as necessary.
Page 349: Maintenance Schedule Ti
DIESEL ENGINES MAINTENANCE SCHEDULE (continued) THE SERVICES SHOWN ON THIS CHART UP TO 60,000 MILES (100 000 km) ARE TO BE DONE AFTER 60,000 MILES AT THE SAME INTERVALS. T0409rT0909 7-15...
Page 350 DIESEL ENGINES Item Service Engine Oil Change*-Every 12 Months, or Oil Filter Change*-Every 12 Months, Chassis Lubrication-Every 12 Months, or Clutch Fork Ball Stud Lubrication (5-speed manual transmission with deep-low only) Cooling System Service*-Every 24 Months or Air Cleaner Filter Replacement* Front Wheel Bearing Repack Transmission Service** CDRV System Inspection*...
Page 351 DIESEL ENGINES MAINTENANCE SCHEDULE lw (continued)
Page 352: Explanation Of Scheduled Maintenance Services
Explanation Of Scheduled Maintenance Services Below are explanations of the services listed in the maintenance charts. lne proper fluids and lubricants to use are listed in this section. Make sure whoever services your vehicle uses these. All parts should be replaced and all necessary repairs done before you or anyone else drives the vehicle.
Page 353 7. TRANSMISSION SERVICE? Automatic Transmission 15,000 every miles (25 every 12,000 miles (20 vehicle is mainly driven under one or more of these conditions: In heavy city traffic. Where the outside temperature regularly reaches higher. In hilly or mountainous terrain. Frequent trailer pulling.
Page 354 EGR SYSTEM INSPECTION* as described in the Service Manual. ELECTRONIC VACUUM REGULATOR VALVE (EVRV) INSPECTION* plugging. If required, clean element with a solution of biodegradable soap and water, let dry and reinstall element. ENGINE TIMING CHECK AND DISTRIBUTOR CHECK (SOME MODELS)*$ Adjust timing to underhood label specifications.
Page 355 THERMOSTATICALLY CONTROLLED ENGINE COOLING FAN INSPECTIONAV ducts for proper hook-up. Be sure the valve works properly. EXHAUST PRESSURE REGULATOR VALVE INSPECTION* Check that the valve works properly. Correct any binding. Inspect hoses for cracks, chafing or decay. Replace parts as needed. TIRE AND WHEEL ROTATION AND INSPECTION wear and maximum tire life, rotate tires at the first 6,000 rniles (10 000 kilometers) for Schedule I...
Page 356: Owner Checks And Services
25. BRAKE SYSTEM INSPECTION? changed, inspect the lines and hoses for proper hookup, binding, leaks, cracks, chafing, etc. Check the parking brake adjust, and the fluid level in the master cylinder. A low fluid level can indicate worn disc brake pads which may need to be serviced.
Page 357 1. Before you start, be sure you have enough room around 2. Firmly apply both the manual parking brake and the regular brake. See “Brakes” and “Parking Brake” in the Index. Do not use the accelerator pedal. 3. Be ready to turn off the engine immediately if it starts. 4.
Page 358 Lap and Shoulder Belts Condition and Operation including webbing, buckles, latch plates, retractors, guide loops and anchors. Have a belt assembly replaced if the webbing has been cut or otherwise damaged. Body Lubrication Service oil. Also lubricate the tailgate, tailgate handle pivot points, and tailgate mounted spare tire carrier (if equipped).
Page 359: Recommended Fluids & Lubricants
Recommended Fluids & Lubricants NOTE: Fluids and lubricants identified below by name, part number specification may be obtained from your GM Dealer. USAGE Engine Oil Gasoline Engines Engine Oil Diesel Engines Engine Coolant Hydraulic Clutch System Hydraulic Brake Systems Parking Brake Cables Power Steering System Automatic Transmission FLUIDLLUBRICANT...
Page 360 USAGE Manual Transmission: 5-Speed (RPO MG5) Differential: a. Standard (Saginaw) Front and Rear Axle b. Locking Transfer Case Gas Line Column Shift, Transfer Case, Shift Lever, and Propeller Shaft Hood Latch Assembly a. Pivots and spring anchor b. Release Pawl Front Wheel Bearings Propeller Shaft Spline/Universal Joint...
Page 361 USAGE Key Lock Cylinders Chassis Lubrication Windshield Washer Solvent GM and Anti-Freeze Weatherstrip Squeaks Weatherstrip Conditioning Outer Tailgate Handle Pivot Points FLUIDLUBRICANT Engine Oil (GM Part No. equivalent) or a synthetic light weight engine oil (SAE 5W-30). Chassis Lubricant (GM Part No. 12346003 or equivalent) or lubricant meeting requirements of NLGI Grade 2, Category LB or GC-LB.
Page 362: Maintenancerecord
Maintenance Record After each of the preceding Scheduled Maintenance Services is performed, record the date, odometer reading, services performed (list item numbers) and who performed the services in the appropriate column. In addition, retain copies of your receipts. It is suggested that receipts be kept with your Owner’s Manual.
Page 363: Service Station Checks
Service Station Checks It is important for you or a service station attendant to perform these under-hood checks at each fuel fill. Check the engine oil level and add if necessary. Check the engine coolant level in the recovery bottle and add if necessary.
Page 364 Windshield Washer Fluid See Page 6-42. Fuel For gasoline engines, use 87 octane (or higher) unleaded gasoline on I For diesel engines, use at least 1 D diesel fuel. For fuel tank capacity See Page 6-82. Spare Tire Pressure See the Certificationflire label on the inside rear edge of the...
Page 365 Customer Assistance Information Here you will find out how to contact GMC Truck if you need assistance. This section also tells you how to obtain service publications and how to report any safety defects. Customer Satisfaction Procedure . . .
Page 366: Customer Satisfaction Procedure
Vehicle delivery date and present mileage Nature of concern We encourage you to call the toll free number listed previously in order to give your inquiry prompt attention. However, if you wish to write GMC Truck, write to: GMC Truck Customer Assistance 3 1 E.
Page 367: Customer Assistance For The Hearing Or Speech Impaired (Tdd)
General Motors reserves the right to change eligibility limitations and/or to discontinue its participation in this program. Both GMC Truck and your GMC Truck dealer are committed to making sure you are completely satisfied with your new vehicle. Our experience has...
Page 368: Reporting Safety Defects To The United States Government
AUTO LINE, but you may contact the BBB at any time. The BBB will attempt to resolve the complaint by serving as an intermediary between you and GMC Truck. If this mediation is unsuccessful, an informal hearing will be scheduled where eligible customers may present their case to an impartial third-party arbitrator.
Page 369: Reporting Safety Defects To The Canadian Government
In addition to notifying NHTSA (or Transport Canada) in a situation like this, we certainly hope you’ll notify us. Please call 1-800-GMC-TRUCK (1-800-462-8782) GMC Truck Consumer Relations 3 I E. Judson Street 1607-04 Pontiac, MI 48342-2230 In Canada, please call us at 1-800-263-3777 (French).
Page 370: Roadside Assistance
We also provide dealer information at no charge such as location of the nearest GMC Truck dealer and their hours of operation. Roadside Assistance is available 24 hours a day, seven days a week, 365 days a year, including weekends and holidays.
Page 371: Service Publications
PSP’s Individual If you don’t want to buy all the PSP’s issued by GMC Truck for all models in the model year, you can buy individual PSP’s, such as those which may pertain to a particular model. To do this, you will first need to see our index of PSP’s.
Page 372 What You’ll Find in the Index: A list of all PSP’s published by GMC Truck in a model year. PSP’s covering all models of GMC light trucks are listed in the same index. Ordering information so you can buy the specific PSP’s you may want.
Page 373 Notes...
Page 374 Above Subscription With Binder Binder Only Prices subject to change without notice. ORDERING INFORMATION tell how to operate and service your vehicle. GMC Truck Service Publications Post Office Box 436006 Pontiac, MI 48343 Ask for form number 15958965-it Number & P/G Models 20.00...
Page 375 . . - .
Page 376 Index ........... . . Aircleaner .
Page 377 Capacities and Specification ............Charts .
Page 378 Driving (continued) ............Braking .
Page 379 ............FanNoise Filter Replacement Chart Finish...
Page 380 HalogenBulbs Hazard Warning Flashers HeadRestraints Headlights Composite High Beam Indicator Light High-LowBe am Reminder Replacement SealedBeam Heating System (with A/C) Rear(WagonMode1s) Rear Window Defogger System Heating System (without A/C) FanKnob FunctionLever Rear Window Defogger Temperature Lever HighwayHypnosis Hitches Hood LatchesandHinge .
Page 381 ............Lights Brake System Warning .
Page 382 ............Odometer Off-Road Driving (See ”Driving”) Off-Road Recovery...
Page 383 Safety Belts (continued) ........... . Extender .
Page 384 ........... . . Tachometer .
Page 385 Warning Lights. Gages and Indicators (Also See "Lights..)Devices. Other Wheels Alignment and Tire Balance Aluminum CapsNheel Nut Caps NutTorque Replacement ..........Used Replacement Windows .
Page 386 X-9409 WE SUPPORT VOLUNTARY TECHNICIAN CERTlFlCATlON THROUGH National institute AUTOMOTIVE SERVICE EXCELLENCE Keep with vehicle times. Contains Important Operating, Safety, and Maintenanc.e Instructions. ""'I TRUCK THE STRENGTH OF EXPERIENCE.
