Instrument Cluster
• With Full Message Center
Refer to Message Center in the
Driver Controls chapter on how to
switch the display from Metric to
English.
Trip odometer: Registers the miles (kilometers) of individual journeys.
• With Mini Message Center
Press the SELECT/RESET control
once to switch from the odometer to
the trip odometer. Press the control
again to select Trip 1 and Trip 2 features. To reset the trip, press and
hold the control again until the trip reading is 0.0 miles.
• With Full Message Center
Press and release the message
center INFO button until TRIP
mode appears in the display. Press
the control again to select Trip 1
and Trip 2 features. Press the
RESET button to reset.
Tachometer: Indicates the engine
speed in revolutions per minute.
Driving with your tachometer
pointer continuously at the top of
the scale may damage the engine.
Battery voltage gauge: Indicates
H
the battery voltage when the
ignition is in the ON position. If the
pointer moves and stays outside the
L
normal operating range, have the
vehicle's electrical system checked
as soon as possible.
16
2005 Expedition (exd)
Owners Guide (post-2002-fmt)
USA (fus)
