Page 1
Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http:// ZZZYLHZVRQLFFRP LQ (QJOLVK RU LQ VSHFL¿F ODQJXDJHV XVLQJ WKH 5HJLRQDO VHOHFWLRQ box in the upper right corner of our website.
Page 2
Compliance Information FCC Statement This device complies with part 15 of FCC Rules. Operation is subject to the follow- ing two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 3
Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this unit near water. Clean with a soft, dry cloth. Do not block any ventilation openings. Install the unit in accordance with the manufacturer’s instructions.
Page 4
Declaration of RoHS2 Compliance This product has been designed and manufactured in compliance with Directive 2011/65/EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Proposed Maximum Substance...
Page 5
Product Registration To fulfill possible future product needs, and to receive additional product information as it becomes available, please visit your region section on ViewSonic’s website to register your product online. The ViewSonic CD also provides an opportunity for you to print the product registration form.
Table of contents Important safety Using the projector in standby mode ..........32 instructions .......2 Adjusting the sound ......32 Introduction......4 Shutting down the projector ....32 Menu operation........33 Projector features ......... 4 Maintenance ....43 Shipping contents......... 4 Controls and functions ......5 Care of the projector ......
Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions Please read this manual before you operate your projector.
Page 8
Do not block the ventilation holes. If the ventilation holes are seriously obstructed, overheating inside the projector may result in a fire. - Do not place this projector on a blanket, bedding or any other soft surface. - Do not cover this projector with a cloth or any other item. - Do not place inflammables near the projector.
Introduction Projector features The projector integrates high-performance optical engine projection and a user-friendly design to deliver high reliability and ease of use. Some of the features may not be available on your projector. Actual performance may vary and subject to model specifications. •...
Controls and functions Projector Lamp Focus ring indicator light Power indicator light Menu Exit Temperature indicator Enter light Source Color Mode Power • Enter • Power Enacts the selected On-Screen Display Toggles the projector between standby (OSD) menu item when the On-Screen mode and Power ON.
Page 11
Remote control COMP1 COMP2 HDMI Auto Source Sync Enter Menu Exit PgUp PgDn Mouse Pattern Blank Audio Color Mode Mode Mode To use the remote mouse control keys • (Keystone keys) (Page Up, Page Down, , and ), see Manually corrects distorted images "Using the remote mouse control"...
Page 12
• Mouse • (My Button) Switches between the normal and mouse Allows user to define a short cut key on modes. the remote control, and the function item is selected in OSD menu. PgUp, PgDn, : active after pressing Mouse. An icon appears on the screen to •...
Page 13
Operating the LASER pointer The Laser Pointer is a presentation aid for professionals. It emits colored light when you press it. The laser beam is visible. It is necessary to press and hold Laser for continuous output. Do not look into the laser light window or shine the laser light beam on yourself or others. See the warning messages on the back of the remote control prior to using it.
Page 14
• To return to the normal mode, press Mouse again or other keys except for the mouse related multi-function keys. Remote control effective range Refer to the illustration about the location of the Infra- Red (IR) remote control sensor(s). The remote control must be held at an angle within 30 degrees perpendicular to the projector's IR remote control sensor(s) to function correctly.
Positioning your projector Choosing a location Your room layout or personal preference will dictate which installation location you select. Take into consideration the size and position of your screen, the location of a suitable power outlet, as well as the location and distance between the projector and the rest of your equipment.
Projection dimensions The "screen" mentioned below refers to the projection screen usually consisting of a screen surface and a support structure. Please see "Projector specifications" on page 65 for the native display resolution of this projector. For models with a 16:9 native aspect ratio •...
Page 17
install it, so as to make allowance for this projector's optical characteristics. This will help you determine the exact mounting position so that it best suits your installation location.
Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. In the connections shown below, some cables may not be included with the projector (see "Shipping contents"...
VGA cable Computer Computer Component Video to VGA A/V device (D-Sub) adapter cable Audio cable Audio Computer (for Component signal) Audio cable A/V device Video cable Video A/V device connector (for Video signal) Audio cable Audio in A/V device Audio Out Speakers Connecting a computer Take the supplied VGA cable and connect one end to the D-Sub output socket of the...
Connecting Video source devices You can connect your projector to various Video source devices that provide any one of the following output sockets: • HDMI • Component Video • Video (composite) You need only connect the projector to a Video source device using just one of the above connecting methods, however each provides a different level of video quality.
Video source device is turned on and operating correctly. Also check that the signal cables have been connected correctly. VGA-Component adapter (ViewSonic P/N: CB-00008906) Connecting a composite Video source device Examine your Video source device to determine if it has a set of unused composite Video output sockets available: •...
Operation Starting up the projector Plug the power cord into the projector and into a wall socket. Turn on the wall socket switch (where fitted). Press Power to start the projector. As soon as the lamp lights up, a "Power On Ring Tone" will be heard.
Using the menus The projector is equipped with On-Screen Display (OSD) menus for making various adjustments and settings. The OSD screenshots below are for reference only, and may differ from the actual design. Below is the overview of the OSD menu. Main menu icon Highlight Status...
Utilizing the password function For security purposes and to help prevent unauthorized use, the projector includes an option for setting up password security. The password can be set through the On-Screen Display (OSD) menu. For details of the OSD menu operation, please refer to "Using the menus"...
Page 25
Entering the password recall procedure Press and hold Auto Sync on the remote control for 3 seconds. The projector will display a coded number on the screen. Write down the number and turn off your projector. Seek help from the local service center to decode the number.
Switching input signal The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. Be sure the Quick Auto Search function in the SYSTEM menu is On if you want the projector to automatically search for the signals.
The current source information will be displayed in the upper left corner of the screen for 3 seconds. The screen will display ViewSonic logo while auto adjustment is functioning. This function is only available when PC D-Sub input signal (analog RGB) is selected.
Page 28
DISPLAY > Open the OSD menu and go to the Keystone menu. Press Enter. Press to correct keystoning at the top of the image or press to correct keystoning at the bottom of the image. Press to correct keystoning at the right side of the image.
Magnifying and searching for details If you need to find the details on the projected picture, magnify the picture. Use the direction arrow keys for navigating the picture. • Using the remote control Press on the remote control to display the Zoom bar. Press repeatedly to magnify the picture to a desired size.
Anamorphic: Scales a 2.35:1 aspect image so that it fills the screen. The table below demonstrates the effects of the aspect ratio settings on projectors with different native resolutions. Please see "Projector specifications" on page 65 for the native display resolution of your projector. In the pictures below, the black portions are inactive areas and the white portions are active areas.
Page 31
Brightest mode: Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high brightness is required, such as using the projector in well lit rooms. Dynamic mode: Is designed for presentations under daylight environment to match PC and notebook coloring.
Page 32
Adjusting Tint Go to the IMAGE > Advanced > Tint menu and press The higher the value, the more greenish the picture becomes. The lower the value, the more reddish the picture becomes. This function is only available when the input signal is Video, YPbPr or YCbCr. Adjusting Sharpness Go to the IMAGE >...
Page 33
• Red Gain/Green Gain/Blue Gain: Adjusts the contrast levels of Red, Green, and Blue. • Red Offset/Green Offset/Blue Offset: Adjusts the brightness levels of Red, Green, and Blue. This function is only available when a computer input signal is selected. Color Management Only in permanent installations with controlled lighting levels such as boardrooms, lecture theaters, or home theaters, should color management be considered.
Setting the presentation timer Presentation timer can indicate the presentation time on the screen to help you achieve better time management when giving presentations. Follow these steps to utilize this function: • Using the remote control Press on the remote control and press repeatedly or to select a Timer Period.
Creating your own startup screen In addition to selecting the projector preset startup screen from among Black, Blue, or ViewSonic screen, you can make your own startup screen that is a picture projected from your computer or video source. To create your own startup screen: Project the picture you want to use as your startup screen from either a computer or video source.
If the action is successful, you see the message 'Captured Succeeded' on the screen. The captured picture is saved as Screen Capture and have been set as your current startup screen. In the unlikely event that the capturing action fails, change your target picture. When it happens, please set the resolution of the input signal under native resolution and try again.
Using the projector in standby mode Some of the projector functions are available in standby mode (plugged in but not turned on). To use these functions, be sure the cable connections are correctly made. For the connection methods, see the Connection chapter.
Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected. The menu items are available when the projector detects at least one valid signal. If there is no equipment connected to the projector or no signal detected, limited menu items are accessible.
Page 40
Main menu Sub-menu Options Auto/Projection (Projector Position)/Menu Position/Color Temp./Brightness/Contrast/3D Settings/Screen Color/Splash Screen/ My Button BASIC Message/Quick Auto Search/DCR/Closed Caption/Power Saving/Freeze/INFORMATION/ Aspect Ratio Auto/Off/Frame Sequential/Frame 3D Sync Packing/Top-Bottom/ 3D Settings Side-by-Side 3D Sync Invert Disable/Invert HDMI Format Auto/RGB/YUV HDMI Settings HDMI Range Auto/Enhanced/Normal Normal/Eco/Dynamic/ Lamp Mode...
Page 41
Main menu Sub-menu Options Multi-language OSD Language selection Front Table/Rear Table/ Projector Position Rear Ceiling/Front Ceiling 5 sec/10 sec/15 sec/20 Menu Display Time sec/25 sec/30 sec Menu Settings Center/Top-Left/Top- 6. SYSTEM Menu Position Right/Bottom-Left/ Bottom-Right High Altitude Mode On/Off Quick Auto Search Off/On Change Password Security Settings...
Page 42
Description of each menu Function Description Screen Color "Using Screen Color" on page 26 for details. Aspect Ratio "Selecting the aspect ratio" on page 24 for details. Keystone "Correcting keystone" on page 22 for details. Corner Adj. "Adjusting 4 corners" on page 23 for details.
Page 43
Function Description Color Mode "Selecting a picture mode" on page 25 for details. Brightness "Adjusting Brightness" on page 26 for details. Contrast "Adjusting Contrast" on page 26 for details. "Selecting a Color Temperature" on page 27 "Setting a Color Temp. preferred color temperature"...
Page 44
Function Description Computer Selecting Enable allows the projector to turn on automatically once the VGA signal is fed through the VGA cable. Auto Power On Direct Power On Selecting On allows the projector to turn on automatically once the power is fed through the power cord. Auto Power Off "Setting Auto Power Off"...
Page 45
Function Description Audio Settings "Adjusting the sound" on page 32 for details. Presentation "Setting the presentation timer" on page 29 for details. Timer The projector can display several test patterns. It helps you Pattern adjust the image size and focus and check that the projected image is free from distortion.
Page 46
Function Description 3D Settings "Using the 3D functions" on page 31 for details. HDMI Settings "Changing HDMI input settings" on page 21 for details. Lamp Mode "Setting Lamp Mode" on page 45 for details. Reset Lamp Hours Resets the lamp timer after new lamp is installed. For Lamp Settings changing the lamp, please contact qualified service personnel.
Page 47
Function Description Sets the language for the On-Screen Display (OSD) menus. Language "Using the menus" on page 18 for details. Projector "Choosing a location" on page 10 for details. Position Menu Display Time Sets the length of time the OSD will remain active after your last key press.
Maintenance Care of the projector You need to keep the lens and/or filter (optional accessory) clean on a regular basis. Never remove any parts of the projector. Contact your dealer when any part of the projector needs replacing. Cleaning the lens Clean the lens whenever you notice dirt or dust on the surface.
Page 49
• If your projector is ceiling-mounted or is not easily accessible, pay special attention to your personal safety when replacing the dust filter. Installing the dust filter Be sure to turn off the projector and unplug it from power source. As the arrows shown to the right, fit the filter by aligning and inserting it into the projector slots.
Remember to set Filter Mode to Off in the ADVANCED > Filter Settings menu when using the projector with the dust filter removed. Setting Filter Mode to Off does not reset the filter timer. The timer will continue counting the next time you fit the filter back on and set Filter Mode to Lamp information Getting to know the lamp hour When the projector is in operation, the duration (in hours) of lamp usage is automatically...
Page 51
Setting Power Saving The projector lowers the power consumption if no input source is detected after 5 minutes to prevent unnecessary waste of lamp life. You can further decide if you would like the projector to turn off automatically after a set period of time. Open the OSD menu and go to the POWER MANAGEMENT >...
Page 52
Indicators Light Status & Description Power events Blue Stand-by mode Flashing Powering up Blue Normal operation Blue Blue Normal power-down cooling (3 sec) Flashing Downloading Burn in off Blue Blue Blue Lamp events Blue First Lamp-Lit error cooling (60 sec) Flashing Lamp error in normal operation (30 sec) CW start fail (30 sec)
Troubleshooting The projector does not turn on. Cause Remedy Plug the power cord into the AC inlet on the projector, and plug the power cord into the power There is no power from the power cord. outlet. If the power outlet has a switch, make sure that it is switched on.
Specifications Dimensions 387.7 mm (W) x 169.4 mm (H) x 432.7 mm (D) (Including extrusions) 432.7 387.7 169.4 Unit: mm Ceiling mount installation Ceiling mount screws: M4 x 8 (Max. L = 8 mm) Unit: mm...
IR control table Format Byte1 Byte2 Byte3 Byte4 PgDn PgUp Blank Auto sync Down Left Right Color Mode Mute Enter Power ON Presentation Timer Exit D. ECO (Eco mode) Menu Mouse Mouse Left Mouse Right Source Pattern My button HDMI Volume+ Volume- Magnify +...
Timing chart Analog RGB Signal Resolution (dots) Aspect Ratio Refresh Rate (Hz) 640 x 480 60/72/75/85 SVGA 800 x 600 60/72/75/85 1024 x 768 60/70/75/85 1152 x 864 1280 x 768 15:9 WXGA 1280 x 800 16:10 60/75/85 1360 x 768 16:9 Quad-VGA 1280 x 960...
Page 67
HDMI Signal Resolution (dots) Aspect Ratio Refresh Rate (Hz) 640 x 480 SVGA 800 x 600 1024 x 768 1280 x 768 15:9 WXGA 1280 x 800 16:10 1360 x 768 16:9 Quad-VGA 1280 x 960 SXGA 1280 x 1024 WXGA 1366 x 768 16:9...
Page 68
3D (HDMI signal included) Signal Resolution (dots) Aspect Ratio Refresh Rate (Hz) SVGA 800 x 600 60* / 120** 1024 x 768 60* / 120** 1280 x 720 16:9 60* / 120** WXGA 1280 x 800 16:9 60* / 120** for Video Signal Signal Resolution (dots)
Page 69
Component video Signal Resolution (dots) Aspect Ratio Refresh Rate (Hz) HDTV (1080p) 1920 x 1080 16:9 50 / 60 HDTV (1080i) 1920 x 1080 16:9 50 / 60 HDTV (720p) 1280 x 720 16:9 50 / 60 SDTV (480p) 720 x 480 4:3 / 16:9 SDTV (576p) 720 x 576...
Projector specifications All specifications are subject to change without notice. Not all models can be purchased in your region. Product Specification Resolution 0.65” 1080p (1920 x 1080) Throw ratio 0.223 (95"±2% @ 0.468m) Display system 1-CHIP DMD Lamp Type 240 W (RCL-107) Input connector RGB-in Component input...
Page 72
Latin America C= http://www.viewsonic.com/ www.viewsonic.com/la/ soporte@viewsonic.com (Mexico) la/soporte/servicio-tecnico Nexus Hightech Solutions, Cincinnati #40 Desp. 1 Col. De los Deportes Mexico D.F. Tel: 55) 6547-6454 55)6547-6484 Other places please refer to http://www.viewsonic.com/la/soporte/servicio-tecnico#mexico Latin America C= http://www.viewsonic.com/ www.viewsonic.com/la/ soporte@viewsonic.com (Peru) la/soporte/servicio-tecnico Macau www.hk.viewsonic.com T= 853-2840-3687 service@hk.viewsonic.com...
Page 73
IRU ODERU DQG RQH \HDU IRU WKH RULJLQDO ODPS IURP WKH GDWH RI WKH ¿UVW FRQVXPHU purchase. Other regions or countries: Please check with your local dealer or local ViewSonic RI¿FH IRU WKH ZDUUDQW\ LQIRUPDWLRQ Limited One (1) year Heavy Usage Warranty: Under heavy usage settings, where a projector’s use includes more than fourteen...
Page 74
FRQWDLQHG KHUHLQ LQFOXGLQJ WKH LPSOLHG ZDUUDQW\ RI PHUFKDQWDELOLW\ DQG ¿WQHVV IRU D particular purpose. Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based XSRQ LQFRQYHQLHQFH ORVV RI XVH RI WKH SURGXFW ORVV RI WLPH ORVV RI SUR¿WV ORVV RI...
Page 75
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &...
Page 76
Tel: (52) 999-925-1916 Tel: 01(52)95-15-15-22-22 E-Mail: rrrb@sureste.com Fax: 01(52)95-15-13-67-00 E-Mail. gpotai2001@hotmail.com Tijuana: FOR USA SUPPORT: ViewSonic Corporation Av Ferrocarril Sonora #3780 L-C 14035 Pipeline Ave. Chino, CA 91710, USA Col 20 de Noviembre 7HO (QJOLVK 6SDQLVK Tijuana, Mexico E-Mail: http://www.viewsonic.com...
