- Page 1 innovative fastener solutions GO - BR1 GO - BR2 GO - TR1 Cordless Blind Rivet Battery Tool User Manual...
-
Page 2: Table Of Contents
2 | Deutsch 1 | English User Manual: GO-BR1 / GO-BR2 / GO-TR1 Table of contents Page Safety precautions 2 - 4 Daily maintenance & environmental protection 1. Machine overview 1.1 Capacity 1.1 Technical parameters 1.2 Configuration/ Accessories (see fig. A) 5 - 6 1.3 Parts List (see fig. -
Page 3: Safety Precautions
Caution Please keep the packaging boxes and accessories and handle them with care. • The tool and accessories should be placed in the plastic case, stored in a dry place and out of the reach of children. www.goebel-group.com... - Page 4 • Maintenance personnel must have professional skills; only qualified professionals can carry out repairs. If in doubt, please return the unit to the authorised dealer or manufacturer for repair. • Original spare parts must be used during maintenance. www.goebel-group.com...
-
Page 5: Daily Maintenance & Environmental Protection
• If your country or region has regulations, please be sure to take the old battery to a professional company for disposal. • Do not throw old batteries into the trash, fire or water! 1. Machine overview Component name Screw cap Mandrel collector Nosepiece Tool body Front Sleeve Set LED light Function display Trigger Battery Charger www.goebel-group.com... -
Page 6: Capacity
1.1 Capacity / Technical Parameters 9.72 10.2 2.17 1057.6599 21.5 1.89 2.36 1.46 3.62 3.62 2.68 GO - BR2 GO-BR1 / GO-TR1 Model GO-BR1 GO-BR2 GO-TR1 Motor 18V Brushless motor Noise level < 78dB Traction power 2700lbft 4000lbft 2700lbft Stroke 0.83"... - Page 7 TRE-GO 9/32" Front Sleeve Set 2277010410 Push-pin spring 2277010910 Clamping Sleeve 2277010510 Nosepiece for TRE- 2277022110 Ø 3/16" GO 3/16" large 3-jaw set 2277010620 Nosepiece for TRE- 2277022210 Ø 1/4" GO 1/4" Clamping jaw pusher 2277010710 www.goebel-group.com * General configuration...
-
Page 8: Parts List (See Fig. B)
2 | Deutsch 7 | English 1.3 Parts List (fig. B) Fig. B www.goebel-group.com... -
Page 9: Go-Br Series Tool Parts List
*Please note that the shaded parts in the list are wear parts, serial numbers 11, 12, 17 are structural parts, the. Serial Nos. a, b are their own exclusive parts for tools, and the rest are general parts. Serial numbers *27-*31 are optional accessories. List of common parts: GO-BR1, GO-BR2, GO-TR1 Standard Code Parts description Qty. -
Page 10: Preparation Of The Tool
• Replace the three clamping jaws and other parts as shown in the following figure. • According to figure ➃,➄, turn the clamping sleeve and screw cap in the direction of the arrow and tighten them with a spanner, then simply charge the battery. www.goebel-group.com... -
Page 11: Other Spare Parts
Important note: You save energy with the automatic sleep mode, no operation within one minute, the white illumination light LED turns off automatically, the tool goes into automatic sleep mode, press the trigger again to restore power. www.goebel-group.com... -
Page 12: Function Settings
3. Function settings Read the following particularly important notes carefully when you are ready to start using the function settings. Very important: GO-BR1 and GO-BR2 have a stroke setting function, the GO-TR1 does not. The function is set at the factory GO-BR1: Stroke: (B) 0.83 inches ;... -
Page 13: Tool Operation
⑤ After riveting, tilt the tool backwards and allow the residual mandrel to fall into the collecting container. ⑥ If the mandrel collecting container is more than 2/3 full of the mandrels, unscrew the container, remove the mandrels and screw the container back on. www.goebel-group.com... -
Page 14: Charger & Batteries
• The battery has deep discharge protection (ECP) and can be recharged about 1000 times. • Do not use the charger until the battery has cooled down sufficiently. • If the battery's operating time is significantly reduced during normal use, this indicates that the battery should be replaced. www.goebel-group.com... -
Page 15: Faq (Questions / Answers)
6. FAQ English | 14 Questions Answers ▶ ▶ Battery Is it okay not to use them for a long time Charge the battery every 6 months, otherwise it may deteriorate in performance after 6 months. ▶ ▶ Does charging affect the battery life after Suggestion: When the remaining battery is only 25% (a light on the display) or when the battery each use is exhausted, it should be recharged to increase the battery life. -
Page 16: Protection Conditions & Ce Certification
The highest liability for damages is limited to the value of the product itself and does not cover the relevant parts. If you have any questions, please contact your local dealer or GOEBEL directly for assistance immediately.
