Use & Care Guide

For Liquid Propane and Natural Gas

Side Burners and Power Burner

Models:

HTSB1 (LP/NG)

HTSB2 (LP/NG)

HTPB1 (LP/NG)

For Outdoor Use Only

HTSB1

HTSB2

HTPB1

-CONTACT INFORMATION-

HEAT Outdoor Living P.O. BOX 16262, Philadelphia PA 19114

866-876-9959 or

CustomerService@Heat-OutdoorLiving.com

www.Heat-OutdoorLiving.com

Version 1.0

Table of Contents

Need help?

Do you have a question about the HEAT HTSB1 and is the answer not in the manual?

Questions and answers

Summary of Contents for CAMBRIDGE HEAT HTSB1

Page 1 __________________________________ Use & Care Guide For Liquid Propane and Natural Gas Side Burners and Power Burner Models: HTSB1 (LP/NG) HTSB2 (LP/NG) HTPB1 (LP/NG) For Outdoor Use Only HTSB1 HTSB2 HTPB1 -CONTACT INFORMATION- HEAT Outdoor Living P.O. BOX 16262, Philadelphia PA 19114 866-876-9959 or CustomerService@Heat-OutdoorLiving.com www.Heat-OutdoorLiving.com...
Page 2 Congratulations on the purchase of your new HEAT Side Burner. With proper care your appliance will give many years of reliable cooking! IMPORTANT: INSTALLER: Please leave these instructions with the consumer. CONSUMER: Please read this manual carefully before using your HEAT appliance to ensure proper operation, installation, and servicing, as well as reduce the risk of fire, burn hazard and/or other injury.
Page 3: Table Of Contents
Table of Contents Safety Instructions Appliance Models Gas Requirements 8-11 Installing the Appliance 12-14 Pre-Operation Leak Testing Lighting the Appliance Care and Maintenance 17-18 Troubleshooting Your Appliance 19-20 Parts List and Breakdowns 21-23 Product Registration Information 24-25 Warranty Page | 3...
Page 4: Safety Instructions
Safety Instructions WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. General Safety Instructions For Household Outdoor Use Only – DO NOT use indoors or in any type of enclosed area such as a garage, shed or breezeway.
Page 5 21. Turn off the cylinder valve when your appliance is not in use. 22. Ensure the control knobs are in the “OFF” position when not in use. CALIFORNIA PROPOSITION 65 WARNING The burning of gas cooking fuels generates some byproducts which are on the list of substances which are known by the State of California to cause cancer or reproductive harm.
Page 6: Appliance Models
Appliance Models Single Burner HTBS1-LP/NG Model: HTSB1-LP & HTSB1-NG 12-1/2”W x 20”D x 5-1/4”H Dimensions BTU Output 12,000 Total BTU 12,000 Burner 1 Brass Burner Warranty See warranty section for details Double Burner HTSB2-LP/NG Model: HTSB2-LP & HTSB2-NG 14-1/2”W x 24-3/4”D x 11”H Dimensions BTU Output 12,000 per burner X2...
Page 7 Power Burner HTPB1-LP/NG Model: HTPB1-LP & HTPB1-NG 16-1/2”W x 23-3/4”D x 11”H Dimensions 22,000 Outer Ring BTU Output 12,000 Inner Ring Total BTU 34,000 Burner 1 Cast SUS304 Power Burner Warranty See warranty section for details Page | 7...
Page 8: Gas Requirements
Gas Connections NOTE: Always have a qualified service technician perform difficult conversions or modifications. WARNING: Never attach an unregulated gas line to the appliance. Connection to an unregulated gas line can cause excessive heat or fire. Before connecting appliance to gas source, make sure control knobs are in “OFF” IMPORTANT: position.
Page 9 A Type 1 compatible cylinder with a Type 1 cylinder valve has a back-check valve which does not permit gas flow, until a positive seal has been obtained. The cylinder must be arranged for vapor withdrawal. It must also include a collar to protect the cylinder valve.
Page 10 LP (Propane) Gas Supply Cylinder Disconnection 1. Turn the burner valves off. 2. Turn the tank valve off. (Turn clockwise to stop.) 3. Detach the regulator assembly from the tank valve by turning the quick coupling nut counterclockwise. LP (Propane) Tank Removal, Transport, and Storage Turn OFF all control knobs and LP tank valve.
Page 11 Natural Gas Hook-up Always check the rating plate to make sure the gas supply you are hooking up to is the gas type the appliance is manufactured for. This natural gas appliance is designed to operate on natural gas ONLY, at a pressure regulated at 4” water column (W.C.) when equipped with the correct natural gas orifices on the valves and a natural gas regulator on the supply line regulated at the residential meter.
Page 12 Grill Island Cut-Out Dimensions WIDTH DEPTH HEIGHT MODEL WIDTH DEPTH HEIGHT HTSB1 (LP/NG) 17-3/4” 11-1/4” HTSB2 (LP/NG) 11” 22-1/16” 8” 14” 8” HTPB1 (LP/NG) 19-1/2” NOTE: ALWAYS have equipment measured by a licensed contractor before beginning any project. Page | 12...
Page 13 The island must be built out of non-combustible material. In the event it is combustible, the use of an insulation jacket is required. Protection from weather: Keep the appliance protected from adverse weather, including rain and wind. Wind, particularly coming into the rear of the appliance, can affect the exhaust from escaping from the appliance.
Page 14: Installing The Appliance
the Appliance in a BBQ Island Installing NOTE: Check with City and Fire department for Local Building Codes. A Permit may be required for outdoor kitchen construction. Check your local building codes for the proper method of installation. In the absence of local codes, this unit should be installed in accordance with the National Fuel Gas Code No.
Page 15: Pre-Operation Leak Testing
Pre-Operation Leak Test DANGER: Do not insert any tool into the valve outlet or safety relief valve. You may damage the valve and cause a leak. Leaking propane may result in explosion, fire, severe personal injury, or death. If a leak is detected at any time or you cannot stop a gas leak, immediately close pipeline valve and call an LP gas supplier or your fire department.
Page 16: Lighting The Appliance
Lighting the Appliance DANGER:  Failure to open the lid while igniting the burner, or not waiting 5 minutes to allow the gas to clear if the burner does not light before retrying may result in an explosive flame-up which can cause serious bodily injury or death. WARNING: ...
Page 17: Care And Maintenance
Care & Maintenance CAUTION: All cleaning and maintenance should be done only when appliance is cool and with the fuel supply turned off at the cylinder. If your appliance is set up for use with natural gas, turn off gas supply at the system manual shut off valve.
Page 18 MAINTENANCE GUIDELINES 1. Keep outdoor cooking gas appliance area clear and free from combustible materials, gasoline, and other flammable vapors and liquids. 2. Do not obstruct the flow of combustion and ventilation air. 3. Keep the ventilation opening(s) of the cylinder enclosure free and clear from debris. 4.
Page 19: Troubleshooting Your Appliance
Troubleshooting Your Appliance GENERAL TROUBLE SHOOTING Inspect the burners at least once a year or immediately if any of the following conditions occur: • The smell of gas. • Flames appearing mostly yellow. (Some yellow at the tips is OK.) •...
Page 20 • Check for spider webs or insect nest. • Cold appliance needs to be preheated for 5 minutes on high setting. Flame blows out on low setting • Cold and windy weather will require you to move appliance or has uneven heat distribution away from the wind.
Page 21: Parts List And Breakdowns
Part Breakdown HTSB1-LP/NG Single Side Burner Description Part Number Single Burner Lid Single Burner Main Body Single Burner Insert Front Panel Single Burner Grates Knob Bezel HT-00-020 Control Knob HT-00-013 Single Burner Valve LP HT-SB1-002 Single Burner Valve NG HT-SB1-003 Brass Burner Assembly HT-SB-001 Handle...
Page 22 HTSB2-LP/NG Double Side Burner Description Part Number Double Burner Main Body Double Burner Grates Brass Burner Assembly Double Burner Drip Tray Double Burner Control Panel Frame Double Burner Control Panel Control Knob HT-00-020 Knob Bezel HT-00-013 Double Burner Gas Manifold LP Double Burner Gas Manifold NG SS Corrugated Hose (200mm) SS Corrugated Hose (400mm)
Page 23 HTPB1-LP/NG Power Burner Description Part Number PB Firebox PB Grates - Outer PB Grates - Inner Cast SS Power Burner PB Electrode - Front PB Electrode - Rear Flame Ring PB Drip Tray Control Knob HT-00-013 Knob Bezel HT-00-020 PB Control Panel Frame PB Control Panel Gas Manifold Bracket LP Regulator...
Page 24: Product Registration Information
Locating the Product Serial Number: The serial number for your HEAT appliance is located on the outside of your appliance. You will need this number to properly register your appliance and activate coverage. Write this information in the space provided below for your records.
Page 25 HEAT Product Registration Please take a minute to let us know what you bought. This makes sure we keep you up to date and have your info ready if you ever need warranty help! Name First ________________________________________ Last ________________________________________ Email Phone ______________________________________________________________________________ Street Address ____________________________________________________________________________ Address Line 2 ____________________________________________________________________________ City _________________________________________ State / Province / Region ______________________...
Page 26 This page left intentionally blank Page | 26...
Page 27: Warranty
Warranty Registration You must register your HEAT series grill within 30 days of purchase to validate the warranty and maintain your original receipt to get parts for the appliance. You may register your appliance by filling out page 25 and mailing to the address located at the bottom of the form. The warranty is for original owners only and cannot be transferred to new owners.
Page 28 -CONTACT INFORMATION- HEAT Outdoor Living P.O. BOX 16262, Philadelphia PA 19114 866-876-9959 or CustomerService@Heat-OutdoorLiving.com www.Heat-OutdoorLiving.com Page | 28...
