Komatsu WA150PZ-5 Operation & Maintenance Manual

Komatsu WA150PZ-5 Operation & Maintenance Manual

Wheel loader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operation & Maintenance
Manual
Unsafe use of this machine may cause serious injury or
death. Operators and maintenance personnel must read
this manual before operating or maintaining this
machine. This manual should be kept near the machine
for reference and periodically reviewed by all personnel
who will come into contact with it.
NOTICE
Komatsu has had the operating and maintenance in-
structions translated into all the languages of the mem-
ber states in the European Union. Should you wish to
have a version of the operating instructions in another
language, please don't hesitate to ask at your local
dealer's.
© 2005 Komatsu Hanomag GmbH
All Rights Reserved
Printed in Europe 06-05
WA150PZ-
WHEEL LOADER
SERIAL NUMBERS
WARNING
H50051
and up
VEAM420100
5
