Certifications & Information
• NSF Certified
• cUPC & UPC
• ADA Approved
• Limited Lifetime Warranty
Tools
Gather the necessary tools as shown to complete the installation of this faucet.
The following tools are optional:
Safety Glasses
Configuration
9" MAX
9" MAX
Sir
Faucet
Four-hole Installation
* This measurement is only suggestive and may vary
according to the sink model.
Installation Guide
• Lead Free Construction
Phillips screwdriver
Channel Lock
9" MAX
Installation Guide
Model 710
Four-Hole Kitchen Faucet
Adjustable Wrench
Pliers
Connect to water supply lines with TWO
3/8" Compression Faucet Connectors
Spout Flow Rate
1.73gpm at 60PSI
Sprayer Flow Rate
1.06gpm at 60PSI
Flashlight
Water supply
Connector
1
Advertisement
Table of Contents
Related Manuals for MRdirect 710
Summary of Contents for MRdirect 710
- Page 1 Installation Guide Model 710 Four-Hole Kitchen Faucet Certifications & Information • NSF Certified • Lead Free Construction • cUPC & UPC Spout Flow Rate • ADA Approved 1.73gpm at 60PSI • Limited Lifetime Warranty Sprayer Flow Rate 1.06gpm at 60PSI Tools Gather the necessary tools as shown to complete the installation of this faucet.
- Page 2 Installation Guide Faucet Installation Turn off the water supply. Remove the mounting hardware from the remote valve shank. B. From the underside of the sink or mounting surface, attach the gasket and washer, followed by the lock nut, onto the shank.
- Page 3 Installation Guide Faucet Installation Continued G. Insert the side spray hose into the sink hole. From under the sink, securely hand tighten the lock nut. H. Attach side spray hose to the quick connect fitting at faucet base. I. Remove all mounting hardware from soap dispenser.
- Page 4 www.mrdirectint.com sales@mrdirectint.com 1-877-946-5725 Important Turn on the water supply SLOWLY, to test for leaks before completely opening the water lines. Remove the aerator from the end of the faucet by carefully unscrewing it. Let hot and cold water run through both water lines for at least one minute before replacing the aerator.
