Certifications & Information
• NSF Certified
• cUPC & UPC
• ADA Approved
• Limited Lifetime Warranty
Tools
Gather the necessary tools as shown to complete the installation of this faucet.
The following tools are optional:
Safety Glasses
Configuration
Sir
Faucet
Three-Hole Installation
4" Centerset
* This measurement is only suggestive and may vary
according to the sink model.
Installation Guide
• Lead Free Construction
• WaterSense Certified
Adjustable Wrench
Channel Lock
Installation Guide
Model 701
Single-Handle Bathroom Faucet
GPM
3
2.5
2
1.5
0
Pliers
Connect to water supply lines with TWO
3/8" Compression Faucet Connectors
Flow Rate Chart
0
10
20
30
40
50
60
70
Flashlight
PSI
80
Water
supply
Connector
1
Advertisement
Table of Contents
Related Manuals for MRdirect 701
Summary of Contents for MRdirect 701
- Page 1 Installation Guide Model 701 Single-Handle Bathroom Faucet Certifications & Information Flow Rate Chart • NSF Certified • Lead Free Construction • cUPC & UPC • WaterSense Certified • ADA Approved • Limited Lifetime Warranty Tools Gather the necessary tools as shown to complete the installation of this faucet.
- Page 2 Installation Guide Faucet Installation A. Turn off the water supply. Remove the faucet with the mounting hardware attached from the package. B. Remove all mounting hardware from the shanks. shank washer lock nut C. Insert the shanks of the faucet body into the holes of the sink deck.
- Page 3 Installation Guide Pop-Up Drain Installation A. Remove pop-up drain stopper (6), and flange (7) with top rubber washer (8) from the pop-up assembly. B. Insert drain body (9) from underneath of sink drain hole. Replace flange (7) and top rubber washer (8) back to drain body (9).
- Page 4 www.mrdirectint.com sales@mrdirectint.com 1-877-946-5725 Maintenance & Cleaning The faucet can be cleaned by rinsing with clear water or washing with mild detergents. Dry the faucet with a clean, soft cotton cloth. CAUTION: do not use any cleaning agents containing acids, abrasives, or other harsh chemicals. Simply rinse and dry faucets with a soft towel every week to prevent mineral deposits from forming.
