Chapter 2 Description

The DET08CFC(/M) is a ready-to-use, high-speed InGaAs photodetector for use
with FC/PC connectorized fiber optic cables in NIR optical systems. The unit
comes with an FC/PC bulkhead connector, detector, and 12 V bias battery
enclosed in a compact aluminum housing. The FC/PC connector provides easy
coupling to fiber-based light sources. The output uses an SMA jack to minimize
size and maximize frequency response. The maximum bandwidth is 5 GHz and
will operate over the spectral range of 800 - 1700 nm. A visible version, the
DET025AFC(/M), is also available for operation in the 400 - 1100 nm spectral
range.
