Chapter 6 Specifications

All measurements are performed with a 50 Ω load unless stated otherwise.
Detector
Active Area Diameter
Wavelength Range
Peak Wavelength
Peak Response
Diode Capacitance
Bandwidth (-3 dB)
Rise Time (20/80%) @1538 nm
Rise Time (20/80%) @1538 nm
NEP (λ ) @ 1550 nm
p
Recommended Maximum Output (50 Ω)
After-Pulse Ringing
Bias Voltage
Dark Current
Output Voltage
Input
Output
Package Size
Ball Lens Diameter
Ball Lens Clear Aperture
Weight
Storage Temp
Operating Temp
Battery
Replacement Battery
Bandwidth and Cutoff Frequency is a defined as boundary at which the output of
the circuit is 3 dB below the nominal output.
b
Measured with specified bias voltage of 12 V
c
Calculated based upon peak responsivity and damage threshold.
d
Outputs higher than this will degrade bandwidth.
TTN020103-D02
Electrical Specifications
b
b
b
λ
λ
p
ℜ( λ
)
p
C
J
d
V
R
I
D
V
OUT
General
FC/PC Fiber Connector
(56.1 mm x 35.6 mm x 20.3 mm)
A23, 12 V
Chapter 6: Specifications
InGaAs PIN
Ø80 um
800 to 1700 nm
1550 nm
0.90 A/W (Typ.)
0.3 pF
5 GHz
<70 ps
<70 ps
-15
2 x 10 W/Hz
1 V
<20% of Maximum
12 V
1.5 nA
0 to 1 V (50 Ω)
SMA (DC Coupled)
2.21" x 1.40" x 0.80"
0.059" (1.50 mm)
∅0.8 mm
0.18 kg
0 to 40 °C
0 to 40 °C
, 40 mAh
DC
Energizer No. A23
1/2
c
