  • Page 1 PH15BT - NLFREN - v1.1 - 08052017 TOOLS TOOLS HANDLEIDING - MODE D’EMPLOI - MANUAL PH15BT (757170150) Hydraulic manual press Hydraulische manuele pers Presse hydraulique manuelle P.02 Gelieve te lezen en voor later gebruik bewaren P.04 Veuillez lire et conserver pour consultation ultérieure...
  • Page 2 PH15BT - NLFREN - v1.1 - 08052017 TOOLS BELANGRIJK! Lees die handleiding aandachtig. Noteer de veiligheidsvoorschriften en waarschuwingen. Gebruik het product voorzichtig en voor de bedoeling waarvoor het ontworpen werd. Het niet naleven van die richtlijnen kan materiële en/of lichamelijke schade veroorzaken.
  • Page 3: Voor De Eerste Ingebruikname

    PH15BT - NLFREN - v1.1 - 08052017 TOOLS Assemblage Gebruik de opengewerkte tekening om de pers te assembleren. Leg alle delen tegenover uzelf voor te beginnen. De volgende werkwijze wordt aanbevolen: 1. Bevestig de linker staander (15) aan de basis (11) met behulp van bouten (9), ringen (12), sluitringen (13) en moeren (14), bevestig dan de rechter staander.
  • Page 4: Consignes De Sécurité

    PH15BT - NLFREN - v1.1 - 08052017 TOOLS IMPORTANT ! Veuillez lire attentivement ces instructions. Notez les consignes de sécurité et avertissements. Utilisez le produit correctement et pour l’usage pour lequel il a été conçu. Le non respect de ces consignes peut causer de graves dommages matériels et/ou corporels. Veuillez garder ce manuel d’utilisation dans un endroit sûr pour pouvoir le consulter ultérieurement.
  • Page 5: Avant La Première Mise En Service

    PH15BT - NLFREN - v1.1 - 08052017 TOOLS Assemblage Utilisez la vue éclatée de la presse pour vous guider dans l’assemblage. Posez toutes les pièces devant vous avant de commencer. La procédure suivante est recommandée: 1. Fixez le montant gauche (15) sur la base (11) à l’aide des boulons (9), rondelles (12), rondelles de blocage (13) et écrous (14), puis fixez le montant droit.
  • Page 6: Safety Instructions

    PH15BT - NLFREN - v1.1 - 08052017 TOOLS IMPORTANT Please read these instructions carefully. Note the safety instructions and warnings. Use the product correctly and with care for the purpose for witch it is intended. Failure to do so may cause damage to property and/or serious personal injury. Please keep this instruction manual safe for future use.
  • Page 7: Before First Use

    PH15BT - NLFREN - v1.1 - 08052017 TOOLS Assembly Use the exploded drawing as your guide to assemble the press. Lay all parts and assemblies out in front of you before beginning. The following procedure is recommended: 1. Attach one base section (11) to left post using bolts (9), washers (12), lock washers (13) and nuts (14) then attach another to right post.
  • Page 8 PH15BT - NLFREN - v1.1 - 08052017 TOOLS Onderdelen Pièces détachées Spare parts FRAME - CHÂSSIS - FRAME...
  • Page 9 PH15BT - NLFREN - v1.1 - 08052017 TOOLS FRAME - CHÂSSIS - FRAME Part No. Description Qty. Part No. Description Qty. Screw Bolt Spring Spring Ball Ram Assy’ Heel Block Oil Hose 2 Screw O-Ring Bed Frame Joint Circlip Direct Fitting...
  • Page 10 PH15BT - NLFREN - v1.1 - 08052017 TOOLS POMP - POMPE - PUMP Part No. Description Qty. Part No. Description Qty. Circlip O-Ring Screw Hand Press Lock Washer U Type Limited Big Pump Core Ball Small Pump Core Ball Seat...
  • Page 11 PH15BT - NLFREN - v1.1 - 08052017 TOOLS PISTON - RAM Part No. Description Qty. Screw Cylinder U-Ring PTFE Ring Piston O-Ring Spring Piston Rod Copper Ring Screw Ring Screw...
  • Page 12 PH15BT - NLFREN - v1.1 - 08052017 TOOLS EG conformiteitsverklaring Déclaration de conformité CE EC declaration of conformity Fabrikant/Invoerder Vynckier Tools nv. Fabricant/Importateur Avenue Patrick Wagnonlaan, 7 Manufacturer/Retailer ZAEM de Haureu B-7700 Mouscron - Moeskroen Verklaart hierbij dat het volgende product : Déclare par ceci que le produit suivant :...

This manual is also suitable for:

757170150
