CAT990 - NLFREN - v1.0 - 21022017
HANDLEIDING - MODE D'EMPLOI - MANUAL
P.02 Gelieve te lezen en voor later gebruik bewaren
NL
P.09 Veuillez lire et conserver pour usage ultérieur
FR
P.16 Please read and keep for future reference
EN
CAT990 (754751990)
Zandstraalcabine
Cabine de sablage
Sandblast cabinet

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAT990 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MW TOOLS CAT990

Summary of Contents for MW TOOLS CAT990

  • Page 1 CAT990 - NLFREN - v1.0 - 21022017 HANDLEIDING - MODE D’EMPLOI - MANUAL CAT990 (754751990) Zandstraalcabine Cabine de sablage Sandblast cabinet P.02 Gelieve te lezen en voor later gebruik bewaren P.09 Veuillez lire et conserver pour usage ultérieur P.16 Please read and keep for future reference...
  • Page 2 CAT990 - NLFREN - v1.0 - 21022017 Waarschuwingen Lees alle instructies aandachtig voor gebruik. 1. Voorbereiding - De interne diameter van de luchtslang moet groter zijn dan 8 mm. Alle slangen moeten een druk van 125 psi/8,61 bar weerstaan en een afsluiter moet worden gemonteerd zodat de luchttoevoer losgekoppeld kan worden voor onderhoud of reparatie.

  • Page 3: Technische Specificaties

    CAT990 - NLFREN - v1.0 - 21022017 Technische specificaties Vermogen: 220~240 V, 50 Hz, 1210 W Maximale werkdruk: 125 psi / 8 bar Luchtverbruik: 680 l/min / 24 cfm Verlichting: Fluorescentielampen: 4 pcs Afmetingen: φ 16 x 890 Vermogen per lamp: 220~240 V, 50 Hz, 26 W...

  • Page 4: Montage

    It is the responsibility of the user to insure that proper and comprehensive training of operators has been performed and all environmental and safety precautions observed. CAT990 - NLFREN - v1.0 - 21022017 We provides a variety of excellent products to the surface preparation industry, and we are confident that all proficient users, operators and contractors in this industry will continue to use our products in a safe and knowledge manner.
  • Page 5 CAT990 - NLFREN - v1.0 - 21022017 Versterking 2 Versterking 1 Voet B STEP <1> Stap 1 1.Please upend the bracket (#8), use M8*20 hex bolt(match faced washers, spring washers) to pass leg STEP <1> 1. Plaats het frame (8) ondersteboven, gebruik M8x20 zeskant bouten en klemringen om de voeten A (3 stuks) en de A (3pcs), leg B (#10)(1PC), then mount on the bracket as figure showed.
  • Page 6 CAT990 - NLFREN - v1.0 - 21022017 Cabine Voet B Step<3>: Stap 3 1.Please place the upper cabinet on the assembled Step<2> as figure. Please notice that front of upper 1. Plaats de cabine op het frame zoals afgebeeld. De voorkant van de cabine moet zich over de voet B bevinden.
  • Page 7 CAT990 - NLFREN - v1.0 - 21022017 Gebruik 1. Voorbereiding van het werkstuk Het werkstuk moet vrij van olie, vet en vocht zijn. Verzeker u ervan, dat het werkstuk droog is vooraleer u het in de cabine zet. 2. Luchtdruk Werkdruk: van 50 tot 80 psi/3,45 tot 5,51 bar.
  • Page 8 CAT990 - NLFREN - v1.0 - 21022017 5. Slechte zicht - Te veel stof - De luchtinlaat boven de regelaar moet vrij blijven voor de luchttoevoer naar de cabine. - Wanneer de stofvanger vol is, moet deze geleegd en gereinigd worden. Ontgrendel deze aan de onderkant of verwijder de zwarte dop van het afzuigsysteem.
  • Page 9 CAT990 - NLFREN - v1.0 - 21022017 Avertissements Lisez attentivement toutes les instructions avant d’utiliser cet équipement. 1. Préparation - Le tuyau d’arrivée d’air doit avoir un diamètre intérieur supérieur à 8 mm. Tous les tuyaux doivent pouvoir supporter une pression de 125 psi/8,61 bar et une vanne d’isolement doit être installée, pour que l’alimentation en air puisse être débranchée de la machine pour les travaux d’entretien ou de réparation.

  • Page 10: Spécifications Techniques

    CAT990 - NLFREN - v1.0 - 21022017 Spécifications techniques Puissance: 220~240 V, 50 Hz, 1210 W Pression maximale de travail: 125 psi / 8 bar Consommation d’air: 680 l/min / 24 cfm Éclairage: Lampes fluorescentes: 4 pcs Dimensions: φ 16 x 890...
  • Page 11 It is the responsibility of the user to insure that proper and comprehensive training of operators has been performed and all environmental and safety precautions observed. CAT990 - NLFREN - v1.0 - 21022017 We provides a variety of excellent products to the surface preparation industry, and we are confident that all proficient users, operators and contractors in this industry will continue to use our products in a safe and knowledge manner.
  • Page 12 CAT990 - NLFREN - v1.0 - 21022017 Renfort 2 Renfort 1 Pied B STEP <1> Étape 1 1.Please upend the bracket (#8), use M8*20 hex bolt(match faced washers, spring washers) to pass leg STEP <1> 1. Retournez le cadre (8), utilisez des boulons hex M8x20 et des rondelles pour fixer les pieds A (3 pcs), le pied B A (3pcs), leg B (#10)(1PC), then mount on the bracket as figure showed.
  • Page 13 CAT990 - NLFREN - v1.0 - 21022017 Cabine Pied B Step<3>: Étape 3 1.Please place the upper cabinet on the assembled Step<2> as figure. Please notice that front of upper 1. Placez la cabine sur le cadre, comme illustré. L’avant de la cabine doit se trouver du côté du pied B.

  • Page 14: Entretien

    CAT990 - NLFREN - v1.0 - 21022017 Utilisation 1. Préparation des pièces pour le sablage La pièce à travailler doit être exempte d’huile, de graisse et d’humidité. Assurez-vous que la pièce est bien sèche avant de la placer dans la cabine.
  • Page 15 CAT990 - NLFREN - v1.0 - 21022017 5. Faible visibilité - Excès de poussière - L’entrée d’air à l’avant gauche au-dessus du régulateur doit être libre pour laisser l’air entrer dans la cabine. - Quand il est rempli, le collecteur de poussière doit être vidé et nettoyé. Déverrouillez le collecteur dans le bas ou enlevez le couvercle noir du système d’aspiration.

  • Page 16: Important Warning

    CAT990 - NLFREN - v1.0 - 21022017 Important warning Read all instructions before using this equipment. 1. Start up preparation - The I.D. of air line should be more than 8 mm. All hoses should be rated at least 125 psi/8.61 bar and an isolation valve should be installed so that supply air can be turned off and then disconnected from blast machine for servicing.

  • Page 17: Technical Specifications

    CAT990 - NLFREN - v1.0 - 21022017 Technical specifications Rating: 220~240 V, 50 Hz, 1210 W Maximum work pressure: 125 psi / 8 bar Air consumption: 24 cfm / 680 l/min Work light: Fluorescent light: 4 pcs Each dimension: φ 16 x 890...
  • Page 18 It is the responsibility of the user to insure that proper and comprehensive training of operators has been performed and all environmental and safety precautions observed. CAT990 - NLFREN - v1.0 - 21022017 We provides a variety of excellent products to the surface preparation industry, and we are confident that all proficient users, operators and contractors in this industry will continue to use our products in a safe and knowledge manner.
  • Page 19 CAT990 - NLFREN - v1.0 - 21022017 STEP <1> Step 1 1.Please upend the bracket (#8), use M8*20 hex bolt(match faced washers, spring washers) to pass leg STEP <1> 1. Please upend the bracket (8), use M8x20 hex bolt (match faced washers, spring washers) to pass leg A (3 pcs), leg A (3pcs), leg B (#10)(1PC), then mount on the bracket as figure showed.
  • Page 20 CAT990 - NLFREN - v1.0 - 21022017 Step<3>: Step 3 1.Please place the upper cabinet on the assembled Step<2> as figure. Please notice that front of upper 1. Please place the upper cabinet on the assembled Step 2 as figure. Please notice that front of upper cabinet should be cabinet should be put to face leg B.

  • Page 21: Maintenance Instructions

    CAT990 - NLFREN - v1.0 - 21022017 Operating instructions 1. Preparing parts for blasting All parts processed must be free of oil, grease and moisture. Make sure parts are dry before putting into the cabinet for cleaning. 2. Air pressure Operating pressure: from 50 to 80 psi/3.45 to 5.51 bar.

  • Page 22: Air Supply

    CAT990 - NLFREN - v1.0 - 21022017 5. Poor visibility - Excessive dust - Air inlet at front left above regulator, should be free to allow air into cabinet. - Dust container full and needs to be cleaned and emptied. Latch at bottom of dust collector or remove black cover on vacuum.
  • Page 23 CAT990 - NLFREN - v1.0 - 21022017 Onderdelen Pièces détachées Spare parts PARTS DIAGRAM-1...
  • Page 24 CAT990 - NLFREN - v1.0 - 21022017 PARTS DIAGRAM-2 Page 11 of 12...
  • Page 25 CAT990 - NLFREN - v1.0 - 21022017 PARTS LISTING ITEM# DESCRIPTION QUANTITY Upper cabinet Round head cross screws (matched washers) Suction sand hose Left grid Right grid Sealing tape Big funnel Bracket M8*20 Leg B Permanent seat of pneumatic device...
  • Page 26 CAT990 - NLFREN - v1.0 - 21022017 Mounting ring of gloves Glove seats Gloves 1 pair Front operation board /sand board Elements of front opening door Cap of nozzle Nozzle "O" seal ring Gun body Sheath of air jet pipe...
  • Page 27 CAT990 - NLFREN - v1.0 - 21022017 EG conformiteitsverklaring Déclaration de conformité CE EC declaration of conformity Vynckier Tools nv. Fabrikant/Invoerder Fabricant/Importateur Avenue Patrick Wagnon, 7 Manufacturer/Retailer ZAEM de Haureu B-7700 Mouscron - Moeskroen Verklaart hierbij dat het volgende product : Déclare par ceci que le produit suivant :...
