1.

Operating Specifications

Description
serial-Number
year of production
capacity
Dimensions of the
digging head
weights
hydraulics
controls
application
- 4 -
Tree Spade OPTIMAL 2 5 0 0
250021
2004
upper root ball diameter
root ball depth
height
width, gate closed
width, gate open
clearance between open gate
inner diameter of frame
working height
digging head
superstructure
hydraulic working pressure 200-220 bar
oil flow
spade pressure at 200 bar 15000kg/blade
electro-hydraulic valves, double acting,
activated either from
control panel in the driver's cabin by means of levers,
joystick and switch, or
from valve banks at the base frame and the digging head by
means of manual valve levers
for moving and transplanting trees with a trunk diameter of
up to approx. 25 cm (10")
250 cm
150 cm
290 cm
250 cm
304 cm
162 cm
178 cm
303 cm
5750 kg
7800 kg
2900–3190 psi
80–100 l/min 21,1–26,4 GPM
33000lbs/blade
98"
59"
114"
98"
120"
64"
70"
119"
