LED INDICATOR GUIDE

1. TANK FULL
SOLID GREEN
Tank full
SOLID RED
Low / No input water
2. SF / GKK CHANGE
SOLID GREEN
SF / GKK is safe to use
BLUE BLINKING
Replace / clean SF^
RED BLINKING
Advance alert to replace GKK
After every 260 hours of pump running
time, post device installation or GKK
replacement.
RED SOLID
Auto-shut o , replace GKK
After every 275 hours
running time, post-device installation
or GKK replacement.
^While the Germkill Kit and the Sediment Filter have a xed replacement schedule, you might be required to clean/change the SF in
the interim depending on the quality of your input water. If the External Sediment Filter is not replaced/cleaned in time (when the blue
blinking happens), it may a ect the performance of the puri er. Blinking for sediment lter will occur to clean/replace sediment lter
after approximately 132 hours of pump running time. You can either clean SF or call Pureit helpline to replace lters at a nominal cost.
* Permeate ow rate and recovery are based on standard test conditions and may vary depending on input water quality, TDS,
pressure and life of Filter elements.
*** Input water quality and TDS content are important determinants of output water quality.
**** If input pressure exceeds 30 PSI, please install a company provided pressure reducing valve at an additional cost. If the pressure
is lesser than 10 PSI then you need to buy 'Pressure enhancing pump' at an additional cost. Device should not be installed in a house
where input pressure is greater than 60 psi.
### After every 275 hours of pump running time the Germkill Kit needs to be
changed. Every 275 hours of pump running time typically gives 6000 liters of puri ed water under test conditions of 10 PSI input
pressure, 750 ppm TDS and 25 °C temperature. Any variations from the test conditions will lead to variations in the ltered life.
3. COPPER CHANGE
SOLID GREEN
Copper is safe to use
RED BLINKING
Advance alert to change Copper
After every 77Hours and 50 minutes of Copper
DSV running time post device installation or
Copper replacement.
RED SOLID
Auto-shut o , replace Copper GKK
After every 78 hours of Copper DSV running
####
time, post device installation or Copper GKK
replacement.
RED, BLUE, GREEN
BLINKING IN SEQUENCE
Electric Fault
4. COPPER RO WATER
YELLOW SOLID
Copper RO water is dispensing
of pump
###
YELLOW BLINKING
Auto-Cleaning Mode,
water cannot be dispensed
RED SOLID
Fault, water cannot be dispensed
5. RO WATER
BLUE SOLID
RO water is dispensing
RED SOLID
Fault, water cannot be dispensed

TECHNICAL SPECIFICATIONS

Pureit Copper + Mineral RO+UV+MF
Height ~447 mm
Width ~350 mm
Depth ~361 mm
Weight ~9.5 kg
Flow rate* Up to 24 litres per hour
Storage tank capacity Upto 8 litres
7 -Stage Purifying Technology PP Melt Blown Pre-Sediment Filter, Pre-RO Carbon Filter,
Mesh Filter, Reverse Osmosis Membrane, UV Reactor,
Post-RO Carbon Filter and Micro Filter Membrane
Membrane type
Pump type Diaphragm pump, 24V dc
% Recovery* Typically 60%
TDS reduction*** 90% (min)
Input water pH range pH range 6.5-8.5, Temperature range 10°C- 40°C
Power rating 60 Watts
Pressure rating 10-30 PSI****
Rated Voltage 100-240V.a.c 50/60 Hz (100-300V.a.c 50/60 Hz)
Material of construction for plastic parts Food safe, non-toxic, engineering grade plastics
Length of Power Cord 1.5 metres
Total Dissolved Solids Upto 2000 mg/lit>
Total hardness 500 mg/lit (max.)
Iron 0.3 mg/lit (max.)
Turbidity 1NTU (max.)
Germkill Kit™
Material of construction Food safe, non-toxic, engineering-grade plastics
Pre-Sediment Filter – 1 No.
Mesh Filter – 1 No.
Germkill Kit™
TDS Modulator – 1 No.
RO Membrane – 1 No.
Copper Germkill Kit™ Copper Module with Harness – 1 Nos
Germkill performance standard Meets stringent international criteria for
microbiologically safe drinking water – e.g.,
Environmental Protection Agency (EPA), USA
#### Every 78 hours of Cu Valve running time typically gives 8000 liters of copper enriched water under ideal condition (10 PSI input
pressure, 750 ppm TDS and 25°C temperature).
# Technical speci cations are subject to change or improvement without prior notice.
> In case the TDS is >1000 PPM, a company provided anti-scalant is recommended to be installed. This has to be purchased at extra
cost.
>>If the iron content in the input water is more, it is recommended to install a company provided iron lter at an additional cost.
7.6 to 8 litres in running water conditions.
$
$
>>
Pre-RO Carbon Filter – 1 No.
Post-RO Carbon Filter – 1 No.
MF Membrane – 1 No.
