- Page 1 Item # : W60CMC Assembly Instructions For the most current instructions, additional assembly tips, to report damage or request parts, please visit our website at www.walkeredison.com. Revised 03/2018 Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 2 Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved. P. 2...
-
Page 3: Parts List
Parts List Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved. P. 3... -
Page 4: Hardware List
Hardware List Philips head screwdriver required for assembly (not included) Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved. P. 4... - Page 5 Insert wooden dowel (A) into middle cross bar (4). Secure cam bolt (B) to drawer front panels (11,15). Attach knob (G) to drawer front panels (11,15) by using handle screw (H). Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved. P. 5...
- Page 6 Insert wooden dowel (A) into base cross bar (21). Use wrench (S) to secure legs (20) with bolt (J), spring washer (L), washer (M), locking plate (N). Secure cam bolt (B) to legs (20). Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved. P. 6...
- Page 7 Insert the legs (20) into bottom panel (2), then insert and secure cam lock (C) into legs (20) to lock it. Use wrench (S) to secure legs (20) to bottom panel (2) with bolt (K), spring washer (L), and washer (M). Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved. P. 7...
- Page 8 Insert side panels (3) and middle side panel (5,6) into bottom panel (2), then insert and secure cam lock (C) into side panels (3) and middle side panel (5,6) to lock it. Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved. P. 8...
- Page 9 Insert the top panel (1) to side panels (3) and middle side panel (5,6), then insert and secure cam lock (C) into side panels (3) and middle side panel (5,6) to lock it. Step 10 Secure back panels (18,19) with screw (Q) Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved. P. 9...
- Page 10 Insert drawer base panel (17) as per diagram. Insert drawer front panel (11) into drawer side panel (9,10), then insert and secure cam lock (C) to drawer side panel (9,10) to lock it. Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved. P. 10...
- Page 11 Insert drawer base panel (17) as per diagram. Insert drawer front panel (15) into drawer side panel (13,14), then insert and secure cam lock (C) to drawer side panel (13,14) to lock it. Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved. P. 11...
- Page 12 Step 15 Place sticker (T) over holes inside drawers as per diagram. Step 16 Insert the drawer (11,15) carefully as per diagram. Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved. P. 12...
- Page 13 Insert shelf support pins (P) into side panels (3) and middle side panel (5,6). Step 18 Place shelfs (22) on top of the support pins (P). Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved. P. 13...
- Page 14 Attach handle (F) to door (7,8) with handle screw (H). Secure hinge (D) to door (7,8) with door hinge screws (E). Step 20 Secure hinge (D) and door (7,8) to side panels (3) with door hinge screw (E). Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved. P. 14...
-
Page 15: Final Assembly
For security, please remove the drawers and doors and using the Anti-Flip screw (U) set to secure the console against the wall. Step 22 Final Assembly Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved. P. 15...
